SHARK® DSP110

www.behringer.com

Version 1.1 June 2000

Technical Specifications

ENGLISH

DSP110

SHARK®

Easy-to-use automatic FEEDBACK DESTROYER with additional learn function for reliable feedback suppression

sVariable delay line with up to 2.5 seconds of delay, adjustable in msec, meters or feet

sUltra-musicalcompressorwithadjustabledensityandspeedparameter

sExtremely fast automatic noise gate with learn function and optional manual setting

sMusicallow-cutfilterwithadjustablecut-offfrequency

sUltra-lownoisemicrophonepre amp with 60 dB gain control and +48 Vphantompower

sLevelconversionfromlinetomicrophone levelandviceversa

sStatus LED’s for all 12 filters

sTwo24-bitA/D and D/A converters

sServo-balancedinputs and outputs with XLR and 1/4" phoneconnectors

sRuggedexternalpowersupply for maximum signal integrity and headroom

s6-segmentcliplevelmeterwithclippingindicator

s4-digitmulti-functiondisplay

s19"rack-mountingkit for 5 SHARKs (optional)

sManufacturedunder ISO9000 certfied managementsystem

SPECIFICATIONS

AUDIOINPUTS

Connectors XLRand 1/4"phone

Type RFfiltered, servo-balancedinput

Impedance 6 kΩbalanced, 3 kΩunbalanced

NominalOperatingLevel microphoneorline level source (switchable)

Max.Input Level +19 dBu at microphone level and line level

AUDIOOUTPUTS

Connectors XLRand 1/4"phone

Type electronicallyservo-balanced outputstage

Impedance 60 Ωbalanced,30Ωunbalanced

NominalOperatingLevel microphonelevelsourceor+4dBu (switchable)

Max.Output Level +20 dBuat +4 dBu nominal level, -12 dBu at microphone level

SYSTEMSPECIFICATIONS

FrequencyResponse 10 Hz to 21 kHz

Noise > 92 dB at line level, unweighted, 22 Hz to 22 kHz

> 89 dB at microphone level, unweighted, 22 Hz to 22 kHz

THD 0.007 % typ. @ +4 dBu, 1 kHz, gain 1

DIGITALPROCESSING

Converters 24-bitSigma-Delta, 64/128-times oversampling

SamplingRate 46.875 kHz

DISPLAY

Type 4-digitnumeric LED display

POWERSUPPLY

MainsVoltages USA/Canada 120 V ~, 60 Hz, PSU DSP110UL

U.K./Australia 240 V ~, 50 Hz, PSU DSP110UK

Europe 230 V ~, 50 Hz, PSU DSP110EU

Japan 100 V ~, 60 Hz, PSU DSP110JP

Generalexport model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz

PHYSICAL

Dimensions (H * W * D) app. 2 .2" (56 mm) x 3.5" (88 mm) x 5.1" (130 mm)

NetWeight app. 0.5 kg

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time

to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.

The information contained in this sheet is subject to change without notice. No part of this sheet may be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any

purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.

BEHRINGER,SHARKandFEEDBACK DESTROYERare registeredtrademarks. ALLRIGHTS RESERVED.

BEHRINGERSpezielleStudiotechnik GmbH, Hanns-Martin-Schleyer-Str.36-38, 47877 Willich-Münchheide II,Germany

Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
