Becker TRAFFIC ASSIST HIGHSPEED Manuel utilisateur

Operating instructions GB

Index

The Traffic Assist Highspeed 6

Operating guide content 6

Use 6

Navigation 6

Music 7

Pictures 7

Unpacking the Traffic Assist

Highspeed 7

Checking the delivery 7

Delivery contents 7

Complaints procedure 8

Handling the packaging 8

Description of unit 8

Traffic Assist Highspeed - basic unit 8

Cable for power supply from

cigarette lighter 9

Battery 9

SD memory card 9

USB connection cable 9

Unit bracket 9

Accessories 10

Mains power supply unit 10

External GPS antenna 10

Headset 10

Information about

documentation 10

Quick start guide 10

Operating instructions 10

Registration 11

Repairs 11

Disposal 11

Emissions 11

Overview Traffic Assist

Highspeed 12

Maintenance and care 16

Battery quality declaration 17

Display quality declaration 17

Start-up 17

Memory card 17

Inserting memory card 18

Ejecting memory card 18

Power supply 19

Using the battery 19

Connecting to socket 19

Connecting up to power supply 19

Removing power supply 19

Connecting to the cigarette lighter 20

TMC antenna* 20

GPS-antenna 20

Unit antenna 20

Connecting up external

antenna 21

Switching the Traffic Assist

Highspeed on/off 21

Switching on 21

Switching off 22

Unit bracket 22

Fitting the unit bracket 23

On the windscreen 23

On the dashboard 23

Adjusting the unit bracket 24

Vertical movements 24

Horizontal movements 24

Adding the Traffic Assist Highspeed 24

Basic information about the

touch screen 25

Operation 25

Calibration 25

Basic information about the menus 25

The main menu 25

Entries made with the entry menu 25

Entering characters 26

Adopting suggestions 26

Scrolling through the lists 26

Special characters and umlauts 27

Entering numbers 27

Deleting characters 27

Inserting spaces 27

The back key 28

More maps 28

Map loaded 28

Installation program 28

Transferring files 28

Transferring using the SD card reader 28

Transferring using the USB port 29

Transferring maps 29

Transferring pieces of music and

pictures 29

Faults 30

*Applies only to the Traffic Assist Highspeed II

Index

Navigational mode 31

What is navigation? 31

Selecting navigation 32

Aids for navigation 32

Rapid access 32

Navigation menu 32

Map display 32

Rapid access 32

Structure of rapid access 33

Navigation menu and map display 33

The list of destinations 33

Icons used 33

Operating rapid access 34

Starting using an existing

destination 34

Scrolling in the destinations

memory 34

Displaying or editing destination 34

Change to map display 35

Displaying current position 35

Calling up Navigation menu 35

TheNavigation menu 35

Structure of the navigation menu 36

Address 36

Point of interest 36

Select on map 36

Route planning 36

Settings 36

Navigation menu: Address 36

Selecting a country 37

Select address and start 37

Stopping navigation 41

Navigation menu: Point of interest 42

Point of interest: Near GPS

position 42

Point of interest: nationwide 43

Navigation menu: Select on map 44

Navigation menu: Route planning 45

Route list 45

Scrolling through the list of routes 45

Using a route 46

The New route button 46

The Edit key 47

The Calculate key 47

The Start key 48

Navigation menu: Settings 48

The button GPS 49

The Map info key 49

The Route info key 49

The Signpost info key 50

The Routing options key 50

The Volume key 51

The Speed key 52

The Automode key 53

The TMC button* 54

The Route planning key 54

The Time Zone key 55

The button Load map 55

The Format key 55

The Factory settings key 56

The Smart Speller button 56

What is dynamic route guidance?* 56

Displaying TMC messages on

the map* 57

Using TMC* 57

Updating the announcement list* 58

Taking announcements into

consideration when calculating

routes* 58

Automatic recalculation* 58

Manual recalculation* 58

Map display 59

Map layout 59

Map display without driving

guidance 59

Map display with driving guidance 60

Map display with toolbar 60

Using the map display 61

Repeat the last voice prompt 61

Setting announcement/music

volume 61

Information rows 62

Zooming and the map (toolbar) 62

Display route (toolbar) 62

Position and display mode

(toolbar) 62

Displaying TMC messages

(toolbar)* 63

Daytime - Night-time design

(toolbar) 63

Change display (toolbar) 64

Point northwards (toolbar) 64

*Applies only to the Traffic Assist Highspeed II

Index

Move map (toolbar) 64

Call Options menu 65

Position information (toolbar) 66

Playback of MP3 files during

an active navigation 66

Music operations 67

Selecting music playback 67

The MP3 player 67

Operating the MP3-Players 68

Track skip 68

Play 68

Pause 68

Folder overview 69

Opening the next folder 69

Repeat current track 69

Setting volume 70

Navigation during MP3 player

operation 70

Shutting down the MP3-Player 70

Pictures mode 71

Selecting pictures display 71

The Picture Viewer 71

Operating the Picture Viewers 71

Scrolling 71

Slideshow 71

Full screen 72

Shutting down the Picture Viewer 72

Folder viewing mode 72

Operating folder viewing mode 73

Subfolders 73

Scrolling 73

Selecting a picture 73

Changing folder levels 73

Closing folder viewing mode 73

Adjusting the music volume 73

Settings 74

Selecting the settings 74

The setting menu 74

Operation 74

Selection possibilities 74

Closing the setting menu 74

The individual menu points 74

Energy 74

Displaying the energy supply 74

Ending the status display 75

Brightness 75

Calibration 75

Starting calibration 75

Language 76

Calling up language selection 76

Turn the page 76

Selecting the language 76

Cancelling the language selection 76

Moodlight 76

Information 77

Specialist words 78

Keywords 80

Technical Data 82

FACT SHEET 83

The information contained herein may

be changed at any time without prior no-

tification. This manual nor any parts the-

reof may not be reproduced for any

purpose whatsoever without the express

written consent of HARMAN/BECKER

Automotive Systems GmbH.

BECKER Automotive Systems GmbH

*Applies only to the Traffic Assist Highspeed II

!Safety information

• The unit may only be operated if the traffic situation allows for this and if you are absolutely certain that you

yourself, your fellow passengers or other road users will not be put at risk, encumbered or disturbed by this.

• The rules of applicable road traffic acts must be observed at all times. Destinations may only be input when the

vehicle is stationary.

• The navigational system is only an aid. The data/details provided may in some cases be incorrect. The driver must

always decide whether to follow the details given or not. We accept no liability for the navigational system issuing

incorrect details. As a result of traffic routing changes and deviating data, inaccurate or incorrect instructions

may be given. Drivers should always pay attention to the actual road signs and traffic control. In particular, the

navigational system cannot be used as a means of orientation in cases of poor visibility.

• The unit may only be used for its intended purpose. The volume of the Navigationsgerätes should be set so that

noises outside the vehicle can still be heard.

• The unit should be switched off immediately if faults occur (e.g. development of smoke or smells).

• For safety reasons, the unit may only be opened by a specialist. Please contact your local stockist if you require

repairs.

• The SD memory card can be removed. Caution! Small children could swallow it.

• The mains voltages (V) indicated on the mains charger, the car charger adapter and the unit must not be

exceeded. Failure to observe this can result in destruction of the unit and the charger as well as explosion of the

rechargeable battery.

• Never open the unit or the rechargeable battery. Any modification to the unit is also impermissible and renders

the type approval invalid.

• Use only genuine BECKER original accessories. This will ensure that all the relevant regulations are complied

with and damage to health and property is avoided. Dispose of defective units and the rechargeable battery

according to the applicable legal requirements.

• No warranty is granted in the case of improper use. These safety instructions also apply to genuine BECKER

original accessories.

The Traffic Assist Highspeed

Operating guide content

The two devices Traffic Assist High-

speed and Traffic Assist Highspeed II

are described in this operating guide. All

the descriptions, with the exception of

those marked with an asterisk (*), apply

to both devices.

The sections of the operating guide

marked with an asterisk (*) apply specif-

ically to the Traffic Assist Highspeed II.

Use

The Traffic Assist Highspeed is a po-

werful PND (Personal Navigation De-

vice) for use in vehicles and closed

spaces. The unit should be protected

from dampness and dirt.

The Traffic Assist Highspeed can be

used as:

• navigational unit

• MP3 (device for playing music)

• JPEG picture viewer

Navigation

Thanks to GPS = Global Positioning

System, you no longer need to spend

hours searching through road atlases.

Once outside buildings, the receiver an-

tenna integrated in the unit gives you

continuous access to navigational possi-

bilities. Depending on reception, you

may not be able to use the navigational

function inside buildings. When used in

vehicles, you may not be able to adequa-

tely receive GPS data depending on how

the Traffic Assist Highspeed is installed.

In such cases, you will have to connect

up an external antenna (does not fall

within the scope of supply).

The Traffic Assist Highspeed II is equip-

ped with TMC*, which gives you the op-

tion of receiving traffic announcements

via the TMC antenna provided. Traffic

announcements are transmitted when

the TMC is active. The system plans an

alternative route automatically or on re-

quest to avoid traffic problems, depen-

ding on the setting.

3012

*Applies only to the Traffic Assist Highspeed II

The Traffic Assist Highspeed

Music

Thanks to the integrated MP3-Player,

you can listen to your favourite tracks

when on the go.

Pictures

The Traffic Assist Highspeed has a Pic-

ture Viewer offering many functions for

viewing pictures.

Unpacking the Traffic Assist

Highspeed

Checking the delivery

Before the Traffic Assist Highspeed is

started up, the delivery should be che-

cked to ensure that it is complete and in

the correct condition (see also page 12).

!Carefully unpack the content of the

package and check it.

Delivery contents

Note:

Your Traffic Assist Highspeed is sup-

plied in stable packaging. Do not un-

pack the unit in full if you discover any

serious damage to the packaging or its

content. If this happens, please contact

your local stockist.

4010

The Traffic Assist Highspeed

Complaints procedure

Please contact your local stockist if you

have any complaints. The unit can also

be sent directly to Harman/Becker in its

original packaging.

Handling the packaging

Keep the original packaging in a dry

place, at least for the warranty period.

Description of unit

The Traffic Assist Highspeed consists of

the basic unit Traffic Assist Highspeed

and the accessories included in the deli-

very.

You will find photos of the individual

parts under:

• "Overview Traffic Assist High-

speed" on page 12

Traffic Assist Highspeed - basic

unit

The basic unit comprises the entire elec-

tronics, an integrated antenna for GPS

signal reception, a touch screen for com-

munication, an integrated loudspeaker

for the output of messages during navi-

gation as well as for MP3 files, illumina-

ted strips along the sides of the unit and

various connections and interfaces.

You will find more details of the unit

under:

• "Technical Data" on page 83

Note:

The packaging should be disposed of

correctly in accordance with national

disposal guidelines. The packaging

must not be burnt. Depending on the

country to which the unit is supplied, it

may be possible for local stockists to

accept packaging.

Note:

The basic unit and accessories must not

be opened or modified in any way.

The Traffic Assist Highspeed

Cable for power supply from

cigarette lighter

This cable allows the unit to be connec-

ted up to the car's cigarette lighter.

The power supply must satisfy the follo-

wing requirements:

• DC current 12 volts

0.5 amps

Battery

When depleted, the integrated recharge-

able battery can be recharged by connec-

ting the Traffic Assist Highspeed to the

power supply.

For this purpose, connect the unit to a

computer via the USB connecting cable,

connect it to a 12 V socket in a vehicle

using the car power adapter, or charge it

using the optional mains power supply

unit connected the 230 V grid.

SD memory card

A memory card is used as a storage me-

dium for road maps, music tracks and

images.

The card supplied with the unit can hold

one set of roadmaps. If you intend to lis-

ten to music using the Traffic Assist

Highspeed or want to view images, you

must save these to a separate card (not

included).

When not in the unit, the memory card

must be stored in a protected dry place

away from direct sunlight in the pa-

ckaging supplied. Avoid touching or dir-

tying the contact strip.

You will find more details about the me-

mory card under:

• "Technical Data" on page 83

USB connection cable

The USB connection cable can be used

to connect the unit to a standard personal

computer by means of the USB port.

You can charge the Traffic Assist High-

speed using the USB cable. However, to

use the data on the PC, you will first

have to install the free "Active Sync"

software from Microsoft®.

Unit bracket

The Traffic Assist Highspeed can be

mounted in the vehicle using the unit

bracket.

Note:

Playback of music while an active navi-

gation is in progress is only possible if

a memory card with a higher storage ca-

pacity is used (available separately).

This can be used to store additional map

material as well as music tracks.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Becker GPS

Becker

Becker BE A00 Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Becker

Becker Highspeed 7934 Manuel utilisateur

Becker

Becker Traffic Assist Pro Z 250 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO Manuel utilisateur

Becker

Becker TRAFFIC ASSIST Manuel utilisateur

Becker

Becker Traffic Assist Z 099 Manuel utilisateur

Becker

Becker MR 109 Series Manuel utilisateur

Becker

Becker Active 43 Series Manuel utilisateur

Becker

Becker BE7977 Manuel utilisateur

Becker

Becker Traffic Assist Z 201 Manuel utilisateur

Becker

Becker Traffic Assist Z 200 Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Becker

Becker TRAFFIC ASSIT 7928 Manuel utilisateur

Becker

Becker Traffic Assist Z 098 Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker Highspeed II Manuel utilisateur

Becker

Becker TRAFFIC ASSIST 7977 Manuel utilisateur

Becker

Becker Z 302 Instructions d'utilisation et d'installation

Becker

Becker Traffic Assist Z 112 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO 7929 Manuel utilisateur

Becker

Becker Traffic Assist 7927 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST Z101 Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
