Index 2

Safety information 6

The Traffic Assist 8

Use 8

Navigation 8

Music 8

Pictures 8

Video 8

Telephone 8

Unpacking the Traffic Assist 9

Checking the delivery 9

Delivery contents 9

Complaints procedure 10

Handling the packaging 10

Description of unit 10

Traffic Assist - basic unit 10

Cable for power supply from

cigarette lighter 11

Mains adapter 11

Battery 11

SD memory card 11

USB connection cable 12

Unit bracket 12

Accessories 12

External GPS antenna 12

Headset 12

Information about

documentation 13

Quick start guide 13

Operating instructions 13

Registration 13

Repairs 13

Emissions and disposal 13

Overview Traffic Assist 14

Maintenance and care 19

Battery quality declaration 20

Display quality declaration 20

Start-up 20

Memory card 20

Inserting memory card 21

Ejecting memory card 21

Power supply 22

Using the battery 22

Connecting to socket 22

Connecting up to power supply 22

Removing power supply 23

Connecting to the cigarette lighter 23

Unit bracket 23

Fitting the unit bracket 24

On the windscreen 24

Adjusting the unit bracket 25

Vertical 25

Horizontal 25

Attaching the Traffic Assist 25

Removing the Traffic Assist 25

TMC antenna 26

Installation of the TMC antenna 26

Connecting the TMC antenna 26

GPS-antenna 27

Unit antenna 27

Connecting up external

antenna 27

Additional connections 27

Connecting the telephone mute

function 28

Connecting the audio signal 28

Connecting USB storage media 28

Switching the Traffic Assist on/off 29

Switching on 29

Switching off 29

Basic information about the

touch screen 30

Operation 30

Calibration 30

Basic information about the menus 30

The main menu 30

Entries made with the entry menu 30

Entering characters 31

Adopting suggestions 31

Scrolling through the lists 31

Special characters and umlauts 32

Entering numbers 32

Switching between upper and

lower case 33

Deleting characters 33

Inserting spaces 33

The back key 33

Sensor button 34

Index

INDEX >>>

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Button lock 34

Activating the button lock 34

Deactivating the button lock 34

Volume control 34

More maps 35

Installation program 35

Transferring files 35

Transferring using the SD card reader 35

Transferring using the USB port 35

Transferring maps 36

Transmitting music tracks, pictures

and videos 36

Faults 36

Navigational mode 37

What is navigation? 37

Selecting navigation 38

Aids for navigation 38

Fast access mode 38

Navigation menu 38

Map display 38

Rapid access 38

Structure of rapid access 38

Navigation menu and map display 38

The list of destinations 39

Icons used 39

Operating rapid access 39

Starting using an existing destination 39

Scrolling in the destinations memory 39

Displaying or editing destination 40

The Navigation menu 41

Structure of the navigation menu 41

Address 41

Point of interest 41

Select on map 41

Enter coordinates 41

Route planning 41

Settings 41

Navigation menu: Address 42

Selecting a country 42

Select address and start 42

Cancelling navigation 48

Navigation menu: Point of interest 48

Point of interest: Near GPS position 48

Point of interest: nationwide 49

Navigation menu: Select on map 51

Navigation menu: Route planning 52

Route list 52

Using a route 53

The New button 53

The Edit key 54

The Calculate key 54

The Start key 55

Navigation menu: Enter coordinates 55

Navigation menu: Settings 56

The Auto mode key 56

The Map info key 57

The Routing options key 58

The Route info key 59

The Format key 59

The Speed key 60

The Time Zone key 61

The Smart Speller button 61

The Junction info button 62

The Home address button 62

The TMC button 63

The Volume key 64

The Dimmer button 64

The button Load map 64

The Factory settings key 65

What is dynamic route guidance? 65

Displaying TMC messages on

the map 66

Using TMC 66

Reading a message 67

Display the relevant road in the map 67

Updating announcements 67

Taking announcements into

consideration when calculating routes 67

Automatic recalculation 67

Manual recalculation 68

Map display 68

Configuration of map display 69

Map display without route guidance 69

Map display with route guidance 69

Map display with reality view 70

Map display with toolbar 70

Using the map display 71

Repeat the last voice prompt 71

Changing the announcement volume 71

Additional information 72

Position information 72

>>> INDEX

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Zooming and the map (toolbar) 72

Display route (toolbar) 72

Displaying TMC messages (toolbar) 73

Change display (toolbar) 73

Point northwards (toolbar) 73

Available POIs along the route

(toolbar) 73

Move map (toolbar) 75

Calling up the options menu (toolbar) 75

Playback of MP3 files during an

active navigation 76

Telephone mode 77

Calling up telephone mode 77

Telephone fast access mode 77

Configuration of fast access mode 77

Number list 78

Icons used 78

Operating in fast access mode 78

Dialling an existing number 78

Scrolling through the number list 78

Displaying or editing entries 79

Telephone menu 79

Dialling a number 80

Telephone book 80

Connecting a mobile phone 81

Opening the device list 81

Connecting automatically 82

Searching for a mobile phone 82

Connecting from the device list 83

Telephone/Bluetooth settings 83

Switching Bluetooth on/off 83

Visibility of the Traffic Assist 83

Device name 84

Setting telephone and ringtone volume 84

Telephone calls 84

Establishing a call 84

Answering a call 85

Ending a call 85

When route guidance is active 85

Without route guidance 85

Music operations 86

Selecting music playback 86

The MP3 player 86

Operating the MP3-Players 86

Track skip 86

Play 87

Pause 87

Cancelling playback 87

Folder overview 87

Track repeat/random play function 88

Setting volume 88

Activating FM transmitter 89

Navigation during MP3 player

operation 89

Shutting down the MP3-Player 89

Pictures mode 90

Selecting pictures display 90

The Picture Viewer 90

Operating the Picture Viewers 90

Scrolling 90

Slideshow 90

Full screen 91

Shutting down the Picture Viewer 91

Folder viewing mode 91

Operating folder viewing mode 92

Subfolders 92

Scrolling 92

Selecting a picture 92

Changing folder levels 92

Closing folder viewing mode 92

Setting the volume 92

Video mode 93

Selecting video playback 93

The video player 93

Operating the video player 93

Opening and playing videos 93

Showing the button bar while

video is playing 94

Pausing and resuming playback 94

Fast forward/reverse 94

Setting the volume 94

INDEX >>>

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Settings 95

Selecting the settings 95

The setting menu 95

Operation 95

Selection possibilities 95

Closing the setting menu 95

The individual menu points 95

Energy 95

Displaying the energy supply 95

Ending the status display 96

Day/night display 96

Calibration 96

Starting calibration 96

Language 97

Calling up language selection 97

Turn the page 97

Selecting the language 97

Cancelling the language selection 97

Moodlight 97

Tones 98

Automatic on/off 98

Switching the function on / off 98

FM transmitter 98

Storing frequencies 99

Information 100

Specialist words 101

Keywords 103

Technical Data 106

NOTICE 107

EU Declaration of Conformity 107

Disposal 108

The information and data contained in

these documents are subject to change

without prior notice.

No part of these documents may be repro-

duced or transmitted for any purpose

without express written permission from

HARMAN/BECKER Automotive

Systems GmbH . All technical informa-

tion,drawingsetc.aresubjecttocopyright

law.

Automotive Systems GmbH

>>> SAFETY INFORMATION

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Safety information

!Safety information

• The unit may only be operated if the traffic situation allows for this and if you are absolutely certain that you yourself,

your fellow passengers or other road users will not be put at risk, encumbered or disturbed by this.

• The rules of applicable road traffic acts must be observed at all times. Destinations may only be input when the vehicle is

stationary.

• The navigational system is only an aid. The data/details provided may in some cases be incorrect. The driver must always

decide whether to follow the details given or not. We accept no liability for the navigational system issuing incorrect

details. As a result of traffic routing changes and deviating data, inaccurate or incorrect instructions may be given. Drivers

should always pay attention to the actual road signs and traffic control. In particular, the navigational system cannot be

used as a means of orientation in cases of poor visibility.

• The unit may only be used for its intended purpose. The volume of the navigational system should be set so that noises

outside the vehicle can still be heard.

• The unit should be switched off immediately if faults occur (e.g. development of smoke or smells).

• For safety reasons, the unit may only be opened by a specialist. Please contact your local stockist if you require repairs.

SAFETY INFORMATION >>>

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

• The SD memory card can be removed. Caution! Small children could swallow it.

• The mains voltages (V) indicated on the mains charger, the car charger adapter and the unit must not be exceeded. Failure

to observe this can result in destruction of the unit and the charger as well as explosion of the rechargeable battery.

• Never open the unit or the rechargeable battery. Any modification to the unit is also impermissible and renders the type

approval invalid.

• Use only genuine BECKER original accessories. This will ensure that all the relevant regulations are complied with and

damage to health and property is avoided. Dispose of defective units and the rechargeable battery according to the

applicable legal requirements.

• No warranty is granted in the case of improper use. These safety instructions also apply to genuine BECKER original

accessories.

>>> THE TRAFFIC ASSIST

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

The Traffic Assist

Use

The Traffic Assist is a powerful PND

(Personal Navigation Device) for use in

vehicles and closed spaces. The unit

should be protected from dampness and

dirt.

The Traffic Assist can be used as:

• navigational unit

• MP3 (device for playing music)

• JPEG picture viewer

• Video player

• Canbeusedasa veryconvenienthands-

free unit via Bluetooth®

Navigation

Thanks to GPS = Global Positioning Sys-

tem, you no longer need to spend hours

searching through road atlases.

Once outside buildings, the receiver an-

tennaintegrated in the unitgivesyoucon-

tinuous access to navigational possibili-

ties. Depending on reception, you may

not be able to use the navigational func-

tion inside buildings. When used in vehi-

cles,you may not be able to adequately re-

ceive GPS data depending on how the

Traffic Assist is installed. In such cases,

you will have to connect up an external

antenna (does not fall within the scope of

supply).

The Traffic Assist with TMC is equipped

with TMC, which gives you the option of

receiving traffic announcements via the

TMC antenna provided. Traffic an-

nouncements are transmitted when the

TMC is active. The system plans an alter-

nativerouteautomaticallyoronrequestto

avoid traffic problems, depending on the

setting.

Music

ThankstotheintegratedMP3-Player,you

canlistentoyourfavouritetrackswhenon

the go.

Pictures

The Traffic Assist has a Picture Viewer of-

fering many functions for viewing pic-

tures.

Video

Traffic Assist features a video player for

playing videos.

Telephone

Your Traffic Assist is equipped with Blue-

tooth® wireless technology. You can con-

nect a mobile phone equipped with Blue-

tooth® wireless technology to it via

Bluetooth. Your Traffic Assist the serves

as a very convenient hands-free unit.

THE TRAFFIC ASSIST >>>

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Unpacking the Traffic Assist

Checking the delivery

Before the Traffic Assist is started up, the

delivery should be checked to ensure that

it is complete and in the correct condition

(see also page 14).

>Carefully unpack the content of the

package and check it.

Delivery contents

1Traffic Assist, the mobile navigation

system with integrated MP3 player,

video player, picture viewer and ex-

tremely convenient Bluetooth®

hands-free unit.

2Docking station

3Memory card (SD memory card) with

pre-installed map data

4USB cable

5Mains adapter for power supply via

the 230 V mains

6Unit holder

7TMC antenna

812V car power adapter for cigarette

lighter socket

9DVD with installer for map data, ac-

tual map data and operating instruc-

tions (not illustrated).

Note:

Your Traffic Assist is supplied in stable

packaging.Donot unpacktheunitinfull

if you discover any serious damage to the

packaging or its content. If this happens,

please contact your local stockist.

>>> THE TRAFFIC ASSIST

> D

> GB

> F

> I

> E

> P

> NL

> DK

> S

> N

> FIN

> TR

> GR

> PL

> CZ

> H

> SK

Complaints procedure

Please contact your local stockist if you

have any complaints. The unit can also be

sentdirectlytoHarman/Beckerinitsorig-

inal packaging.

Handling the packaging

Keepthe originalpackagingin adryplace,

at least for the warranty period.

Description of unit

The Traffic Assist consists of the basic

unit Traffic Assist and the accessories in-

cluded in the delivery.

You will find photos of the individual

parts under:

• "Overview Traffic Assist" on page 14

Traffic Assist - basic unit

The basic unit contains all the electronics:

• an integrated antenna,

• a TMC receiver for the reception of

traffic messages,

• a touchscreen,

• sensor buttons for operation,

• an integrated loudspeaker for the out-

put of messages during navigation and

for MP3 files and phone calls,

• a microphone.

On the sides of the unit, there are also

light bars as well as various connections

and ports.

You will find more details of the unit

under:

• "Technical Data" on page 106

Note:

Thepackaging should bedisposedof cor-

rectlyin accordancewith nationaldispos-

al guidelines. The packaging must not be

burnt. Depending on the country to

which the unit is supplied, it may be pos-

sible for local stockists to accept packag-

ing.

Note:

The basic unit and accessories must not

be opened or modified in any way.

Table des matières

Autres manuels Becker GPS

Becker

Becker TRAFFIC STAR NAVIGATION Manuel utilisateur

Becker

Becker TRAFFIC ASSIST HIGHSPEED Manuel utilisateur

Becker

Becker Traffic Assist Z 099 Manuel utilisateur

Becker

Becker Traffic Assist Z 102 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST 7977 Manuel utilisateur

Becker

Becker Traffic Assist Pro Z 250 Instructions d'utilisation et d'installation

Becker

Becker TRAFFIC ASSIST 7827 Manuel utilisateur

Becker

Becker READY 45 LMU Manuel utilisateur

Becker

Becker active.5s EU Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker Traffic Assist Z 098 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST Manuel utilisateur

Becker

Becker Highspeed 7934 Manuel utilisateur

Becker

Becker Traffic Assist Z 201 Manuel utilisateur

Becker

Becker Ready 50 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO Manuel utilisateur

Becker

Becker Active 43 Series Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO 7929 Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker Traffic Assist 7927 Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Becker

Becker GPS Navigator Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
