BEC 8920AC

Ultimum®

The Ultimate Residential Gateway

with 802.11ac

VDSL2/ADSL2+/Bonded/FTTH

Quick Start Guide

BEC 8920AC The Ultimate Residential Gateway w/ 802.11ac

Package Contents

BEC 8920AC The Residential Gateway with 802.11ac * 1

This Quick Installation Guide * 1

CD containing User Manual * 1

Vertical Stand * 1

RJ-45 Ethernet Cable * 1

Y-Cable for xDSL bonded operation * 1

Detachable Antenna * 1

Power adapter * 1



Warning

Do not use the router in high humidity or high temperatures.

Do not place the router next to high-temperature appliance, e.g. a heater or stove, or

cover it up with tablecloths, curtain, etc.

Do not use the same power source for the router as other equipment.

Do not open or repair the case yourself. If the router is too hot, turn off the power

immediately and have it repaired at a qualified service center.

Avoid using this product and all other accessories outdoors.

Attention

Place the router on a stable surface.

Only use the power adapter that comes with the package. Using a different voltage

rating power adapter may damage the router.

PLEASE READ THE QUICK START GUIDE AND FOLLOW THE

STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU

INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.

IF YOU NEED MORE INFORMATION ON THIS SOFTWARE

CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON

CD-ROM.

Quick Start Guide

Front Panel LEDs

LED

STATUS

DESCRIPTION

PWR

(Power)

Red

System failure or in emergency mode

Green

System is up and ready

Off

Device has no power.

Gigabit

EWAN /

ETH 5

(Ethernet)

Can be configured to be WAN port for broadband connectivity

Green

Ethernet LAN : Connected to an Gigabit (1000Mbps)

Ethernet device

Ethernet WAN: Successfully connected with a broadband

connection device

Orange

LAN port is connected to an 10/100Mbps Ethernet device

Blinking

Data being transmitted/received

Off

No device is connected to the Ethernet port

Gigabit

ETH 1~4

(Ethernet)

Green

LAN port is connected to an 1000Mbps Ethernet device

Orange

LAN port is connected to an 10/100Mbps Ethernet device

Blinking

Data being transmitted/received

Off

No device is connected to the Ethernet port

Wireless

2.4GHz /

5GHz

Green

Wireless connection established

Blinking

Data being transmitted / received

Off

Wireless being turned off

WPS

Green

Wireless device(s) being connected successfully via WPS

mode

Blinking

WPS is enabled and trying to establish a WPS connection.

Off

WPS being turned off

DSL1 /

DSL2

Green

Successfully connected to an ADSL DSLAM (Line Synced).

Off

DSL cable is unplugged

INET

(Internet)

Green

IP received and traffic is passing thru the device.

Blinking

Data being transmitted / received

Red

BEC 8920AC is unable to get a public (WAN) IP address

Off

BEC 8920AC is either in bridged mode or WAN (DSL)

connection is not ready

BEC 8920AC The Ultimate Residential Gateway w/ 802.11ac

Rear Panel Connectors

PORT

MEANING

1. Power ON/OFF

Power ON/OFF switch

2. PWR (Power)

Connect the supplied Power Adapter to this port.

3. WPS /

Wi-Fi On/Off

By controlling the pressing time, users can achieve two

different effects:

(1) WPS*: Press &hold the button for less than 6 seconds to

trigger WPS function.

(2) Wireless ON/OFF button: Press & hold the button for

more than 6 seconds to On/Off the wireless.

* For WPS configuration, please refer to the WPS section in the User

Manual.

4. Reset

Push and hold the reset button for five (5) seconds to restore

to its factory default settings (this is used when you cannot

5. E (Gb EWAN)

Connect to Fiber/ Cable/ xDSL Modem with a RJ-45 cable, for

broadband connectivity.

Note: LAN 5 automatically becomes an EWAN port when EWAN

internet interface is being selected in the GUI

6. Gb LAN

Ethernet (1~5)

Connect PCs, Laptops or any other office/home LAN devices

with the supplied RJ-45 Ethernet cable (Cat-5 or Cat-5e) to

any of the five LAN ports.

Note: Port 5 is a LAN / WAN Configurable Port

7. USB

Connect with a 3G or 4G/LTE USB adapter/dongle for mobile

connectivity.

8. DSL

Connect the device to an ADSL/VDSL telephone jack or

splitter using a RJ-11 telephone cable / Y-Cable for xDSL

bonded

Quick Start Guide

Hardware Connection

xDSL Connection –Single Pair

xDSL Connection –Bonding

BEC 8920AC The Ultimate Residential Gateway w/ 802.11ac

FTTH / Broadband Connection

The Ethernet 5 is an interchangeable

LAN/WAN port. Refer to the User Manual

to change this port to EWAN interface to

connect with your Fiber, Cable, or xDSL

modem.

Automatic WAN Failover

The automatic failover ensures uninterrupted

operation and 24/7 Internet availability. When

Primary WAN connection fails, the Secondary

connection will back up the Internet connection

seamlessly.

Quick Start Guide

Hardware Installation

1. Attach the Vertical Stand to the 8920AC

Setup your 8920AC in a vertical position using the stand provided in the package and place

it on a stable surface for proper operation.

To correctly insert the vertical stand to the 8920AC, left up the router with PWR (Power

LED) facing upward then slide it into the stand by attaching the wider side of the vertical

stand to the top casing (BEC Logo) and shorter side on the back of the 8920AC

2. Power Connection

Plug in the supplied power adapter to the wall jack, the other side to the 8920AC then power

ON the 8920AC by pressing the Power On/Off button.

BEC 8920AC The Ultimate Residential Gateway w/ 802.11ac

3. LAN Connection

Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other side

to the PC’s Ethernet interface.

4. WAN Connection

A. xDSL Interface

For single line xDSL, please connect the supplied Y-Cable or a regular RJ-11 phone cable to

the DSL port and the other side to the phone jack on the wall.

Quick Start Guide

For bonded xDSL, please connect the supplied Y-cable to the DSL port, and the other two

ends (both pairs) to the phone jacks on the wall.

B. EWAN Interface

Connect RJ-45 Ethernet cable to the EWAN port, and connect the other side to another

alternative broadband device, such as Cable Modem, VDSL, Fiber Modem or PON optic

lines. <Please refer to User Manual for detailed instruction.>
