Baumatic ISL5SS Manuel utilisateur

I SL5 SS 9 0 cm Glass

island cooker hood

User M anual for your Baum at ic

I SL5 SS

Cooker Hood

9 0 cm Glass island cooker hood in

st a in le ss st ee l

N OTE: Th is Use r I n st r u ct ion M a nu al con t ain s im por t ant

in for m a t ion, in cludin g sa fe t y & in st alla t ion poin t s, w h ich w ill

ena ble you t o get t h e m ost ou t of your applia nce. Plea se kee p it

in a safe place so tha t it is e asily ava ila ble for fut ure re fe rence; for

you or any per son not fam iliar w it h t h e oper at ion of the applia nce.

DD 08/ 05/ 09

Con t ent s Pa ge

Environmentalnote 4

I M PORTAN T SAFETY I N FORM ATI ON 5 – 7

Spe cifica t ion s of you r cook er h ood 8

Usin g you r Ba um a t ic cook e r hood 9 - 10

Beforefirstuse 9

To use your cooker hood 9 – 10

Cle an in g y our Ba um a t ic cook e r hood 10

The grease filters 10

Maintenance 11 - 14

Rem oving and cleaning t he grease filters 11 - 12

Changingalightbulb 12-13

Fitt ing t he carbon filt er 13 - 14

Installation 14 - 22

Electricalconnection 15

Before beginning inst allat ion 16

Positioning 17-18

I nst alling your cooker hood 18 - 22

Supplied inst allat ion com ponents 19

Ex t r a ct ion m od e or r ecir cu la t ion m od e? 22

Externalducting 22

Troubleshooting 23 - 24

Contactdetails 25

EN V I RON M EN TAL N OTE

N ot e : Be for e disca r ding a n old a pplia nce , sw it ch of f a nd

disconnect it from the pow e r su pply. Cut off a nd render a ny

plu g use le ss. Cu t t he ca ble of f dir e ct ly be h in d t he a pplia n ce t o

pr eve nt m isuse . This should be u nde rt a k en b y a com pe t ent

pe rson.

CON FORMI TY TO W .E.E.E. DI RECTI VE

I MPORTAN T SAFETY I N FORMATI ON

Your safet y is of t he ut m ost im portance t o Baum at ic.

Please m ake sure t hat you read this inst ruct ion booklet

be fore at t em pt ing t o inst all or use t he appliance. I f

you are unsure of any of t he inform at ion contained in

this booklet, please contact t he Baum at ic Advice Line.

I M PORTAN T: An y in st a lla t ion w or k m u st b e

ca r rie d out b y a q ua lifie d e le ct r icia n or

com p et en t pe r son.

oThe hood m ust be installed in accordance with the installation

inst ruct ions and all m easurem ent s followed.

oI f t he cooker hood is installed for use above a gas appliance t hen

the provision for vent ilat ion m ust be in accordance with the Gas

Safet y Codes of Pract ice BS.6172, BS.5440 & BS. 6891 ( Nat ural

Gas) and BS.5482 ( LP Gas) 1994, t he Gas Safet y ( I nst allat ion &

Use) Regulations, the Building Regulations issued by t he

Departm ent of t he Environm ent, t he Building Standards

( Scot land) ( Consolidat ed) Regulat ions issued by the Scot t ish

Developm ent Depart m ent .

oI t is dangerous to alt er t he specificat ions or t o m odify this

product . Do not t am per with it or at tem pt to m odify the

appliance in any way.

oWhen installing t he hood, ensure t hat t he following

recom m ended dist ances are observed between the highest point

on t he hob top (including the bur ner s) and t he bot t om of t he

cooker hood:

¾Ele ct r ic cook er s: 7 0 0 m m

¾Ga s cooke rs: 7 0 0 m m

¾Coal/ oil cooke rs: 8 0 0 m m

I M PORTAN T: DO N OT SET YOUR COOKER HOOD LESS

THAN 7 0 0 m m ABOVE YOUR COOKER.

oWhen installed between adj oining wall cabinet s, t he cabinet s

m ust not overhang the hob.

oThe edges of t he cooker hood are sharp – be m indful of t his as

you handle your appliance, especially during inst allat ion and

cleaning. D O N OT CLEAN I N BEH I N D THE GREASE FI LTERS!

oI f t he room where the cooker hood is t o be used contains a fuel

burning appliance such as a central heat ing boiler then it s flue

m ust be of the sealed or balanced flue t ype.

oI f ot her t ypes of flue or appliances are fit t ed, ensure that t here is

an adequat e supply of air in t he room .

oWhen t he hood is being used in it s ex t ract or funct ion, ensur e

that the duct ing is fire ret ardant and that t here are no bends

sharper t han 90 degrees as t his will reduce t he efficiency of the

hood.

oEnsure the duct ing for t he ext ractor funct ion has t he sam e

diam eter as t he out let hole all t he way t hrough.

oKeep young children from using, playing wit h

or t am pering wit h t he cooker hood. Older

children and infirm persons should be

supervised if t hey are using the cooker hood.

oYour cooker hood is for dom est ic use only.

oPlease dispose of t he packing m at erial carefully – children are

especially vulnerable to it .

oDirt y oil is an even great er fire risk.

oAlways put lids on pots and pans when cooking

on a gas cooker.

oThe m anufacturer refuses t o accept any responsibility for

dam ages arising to t he hood or it cat ching on fire, from a failure

to observe the fire safet y advice contained in this inst ruct ion

booklet .

oRem em ber t hat when in ext ract ion m ode, your cooker hood is

rem oving air from your room . Ensur e t hat pr oper vent ilat ion

m easures are being observed.

oN ot e t h a t it r e m ov es odou rs fr om y ou r room , n ot st e am .

oW ar ning - Alw a ys ensur e t h at t h e cook er

hood ha s be en discon ne ct e d f rom t h e

pow e r supply be for e ca rrying out a ny w ork

on t he hood, in clu din g replacing light bulbs.

oDo not connect t he duct ing syst em of this appliance to any

exist ing ventilat ion syst em which is being used for any other

purpose.

oDo not install above a cooker wit h a high level grill.

oNever leave frying pans unattended during use

as overheat ed fat s and oils m ight catch fire.

oThe lights on t his appliance should only be used

during operat ion of t he cooker hood. They should not be left on

perm anent ly and used as a light ing source.

oThe cooker hood should not be exposed t o a direct heat source

from t he cooking device underneath it , i.e. naked flam e from a

gas burner or heat from elect ric hob zones w it h ou t a pan on

them .

oDo not at tem pt t o use the cooker hood if it is dam aged in any

way. Never at tem pt to use it without t he gr ease filt er s fit t ed or

if t he filt ers are excessively greasy!

oNever flam bé cook under t his cooker hood.

TH E M AN UFACTURER DECLI N ES ALL

RESPON SI BI LI TY I N TH E EVEN T OF FAI LURE TO

OBSERVE TH E I N STRUCTI ON S GI V EN HERE, FOR

I N STALLATI ON , M AI N TEN AN CE AN D SUI TABLE

USE OF TH E H OOD .

Spe cifica t ions of your cook e r h ood

Con gr at u la t ion s on pu rch a sin g a Ba um a t ic cook e r hood!

PRODUCT DI M EN SI ON S

Height : 690 m m * – 1190 m m

Widt h: 900 m m

Depth: 600 m m

D I M EN SI ON S OF CHI M N EY SECTI ON

270 m m x 285 m m

oSuperior ext ract ion t angent ial m ot or

oElect ronic pushbut t on operat ion

o3 Speeds

o2 Met allic grease filt ers

o4 Halogen light s

oEx t r a ct ion ca pa cit y : 7 5 0 m ³ / hr

oOpt ion a l e x t ra : 1 x SQ1 Ca rbon filt e r re quir ed for

r ecir cu la t ion m od e

* I M PORTAN T: Ple ase se e t he posit ion in g

in st r uct ion s on pa ge s 1 7 - 1 8 t o ob t ain pr e cise

in for m a t ion on t he h eigh t r equ ir e m e nt s f or t his

pr oduct .

Using your Baum a t ic cooke r hood

Be fore fir st use

I MPORTAN T: TH I S PROCESS MUST BE FOLLOW ED

BEFORE TH E COOKER HOOD I S USED FOR THE FI RST

TI ME.

oYou should use a good quality st ainless st eel cleaner and polish

on ALL of the st ainless steel areas of your cooker hood, before it

is used for t he first t im e.

oThis will help t o leave a silicone w at er - resist ant film t o pr ot ect

the st ainless steel surfaces.

To use your cook e r hood

oMake sure that it has been inst alled by a suit ably qualified

person, as per the inform at ion contained in Baum atic’s

inst allation inst ruct ions.

oFind t he cont rol panel, which is locat ed at t he front right of t he

canopy.

oThere are several butt ons on the control panel, which perform

separat e funct ions.

oA = Speed select ion butt ons

= Low speed

= Medium speed

= High speed

oB = Light on/ off but t on

I MPORTAN T: I D EALLY YOU SH OULD TURN ON YOUR

H OOD TEN M I N UTES BEFORE YOU START TO COOK,

OR AT THE VERY LEAST W HEN YOU BEGI N COOKI N G.

YOU SH OULD ALSO RUN YOUR H OOD FOR TEN

M I N UTES AFTER YOU H AV E FI N I SH ED COOKI N G.

Clea ning your Ba um a t ic cooker hood

I M PORTAN T: BEFORE CLEAN I N G, ALW AYS

EN SU RE TH AT YOU H AV E SW I TCH ED YOUR

COOKER HOOD OFF AT TH E OM N I - POLAR

SW I TCH , SET AT TH E W ALL FROM TH E CABLE.

Cleaning

oClean the ext ernal part s of your cooker hood wit h m ild liquid

det ergent and a new dam p cloth.

oNever use abrasive powder, corrosive solvents or brushes.

oYou should use a good quality st ainless st eel cleaner and polish

on ALL of the st ainless steel areas of your cooker hood

oNever inser t point ed obj ect s int o the m otor’s prot ect ive grid.

oOnly clean the cont rol panel and grease filt er grill wit h m ild liquid

det ergents and a new dam p clot h.

oI f you are using t he appliance in recirculat ion m ode, t hen be

sure to replace t he carbon filt er at t he recom m ended interval

( see sect ion on “ Fitt ing the carbon filt er” ) . A build up of grease

could cause a fire hazard.

oNever at t em pt t o clean the area above t he grease filters.
