Baumatic BHI100 Manuel utilisateur

BHI100

Freestanding 1 zone

induction hob

User Manual for your Baumatic

BHI100

Freestanding 1 zone induction

hob

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 14/02/12

Contents

Environmental note 4

Important safety information 5 – 7

Specifications 8 -10

Productdimensions 8

Productspecifications 8

Electricaldetails 8

Ceramic hob surface layout 9

Controlpanellayout 9-10

Usingtheinductionhob 10-14

Beforefirstuse 10

Cooking on the induction zone 10

Heatlevelsettings 11-12

Usingthetimer 12

Turning off the induction zone after cooking 12

Cookware that is suitable for an induction hob 13

Hobguidelines 13-14

Cleaning and maintenance 14-15

Cleaning the ceramic hob top 14

Aftereachuse 15

Using a specialist ceramic hob cleaner 15

Installation 15-16

Positioning 15

Electrical connection (UK only) 15-16

Electrical connection (European countries) 16

My appliance isn’t working correctly 17-18

Errorcodes 17

General troubleshooting 17-18

Contactdetails 19

Environmental note

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of

the utmost

importance to

Baumatic. Please

make sure that

you read this

instruction

booklet before attempting to

install or use the appliance. If

you are unsure of any of the

information contained in this

booklet, please contact the

Baumatic Customer Care

Department.

General Information

oThis appliance is designed

for domestic household

use and for the cooking

and frying of domestic

foodstuffs.

oYour new appliance is

guaranteed against

electrical or mechanical

defects, subject to certain

exclusions that are noted

in Baumatic’s Conditions

Of Guarantee. The

foregoing does not affect

your statutory rights.

oThe use of this appliance

for any other purpose or

in any other environment

without the express

agreement of Baumatic

Ltd. will invalidate any

warranty or liability claim.

oYou should not use this

appliance to store items

on or as a work surface.

oNo modifications to the

appliance are permitted

by Baumatic Ltd.

oYou should not store or

place flammable or highly

flammable

liquids/materials on top of

or near the appliance.

Items made from

aluminium, plastic or

plastic film should also be

kept away from the

appliance, as they may

fuse to the surface.

oRepairs may only be

carried out by Baumatic

Service Engineers or

their authorised service

agent.

Child Safety

oBaumatic strongly

recommend that babies

and young children are

prevented from being near

to the appliance and

should not be allowed to

touch the appliance at

any time.

oIf it is necessary for

younger family members

to be in the kitchen,

please ensure that they

are kept under close

supervision at all times.

oOlder children should only

be allowed to utilise the

appliance when

supervised.

General Safety

oIf you notice any

scratches, splits or cracks

in the ceramic glass, you

should immediately switch

off the appliance and

disconnect it from your

mains supply. Otherwise

there is the risk of electric

shock occurring.

oDO NOT insert any

foreign objects into, or

block, the air ventilation

openings.

During use

oAny film or stickers that

are present on the hob

surface when it is

delivered should be

removed before use.

oCare should be taken

when utilising the

appliance, otherwise there

is a risk of burns being

caused.

oThe induction hob can not

withstand abnormally

heavy weights. Take care

not to overload the hob.

oYou should not allow the

electrical connection

cables to come into

contact with the hob

surface when it is hot or

any hot cookware.

oThe electrical connection

cable should not hang

over the edge of the table

or counter.

oIf fat and oil overheats,

then it can ignite

extremely quickly. For this

reason, when cooking with

fat and oil the appliance

should not be left

unattended.

oMake sure that the

appliance is switched off

after use.

oThe appliance surfaces will

become hot during use

and retain heat

afterwards. Care should

be taken to avoid burns

from touching the hob

surface when it is still hot.

oIMPORTANT: This

ceramic induction hob

fully complies with

current legislation

regarding electro-

magnetic interference

and is designed not to

interfere with other

electronic appliances

providing these comply

with the same

legislation.

oAs the hob generates

magnetic fields in its

immediate vicinity,

pacemakers and active

heart implants must be

designed to comply

with relevant

regulations. If in doubt,

you should consult the

manufacturer of your

device or your Doctor.

In this respect,

Baumatic can only

guarantee the

conformity of our own

product.

oIf an object made of

metal, (e.g. saucepan

lid, knife, fork or

spoon) is placed on a

cooking zone that is

switched on, it can get

hot.

oDo not place the

induction hob onto a

surface made from

iron, stainless steel or

aluminium during use

as this could cause the

surface to heat up.

Cleaning

oCleaning of the hob should

be carried out on a regular

basis.

oIMPORTANT: Before

attempting to clean the

appliance, it should be

disconnected from the

mains and allowed to cool.

oGreat care should be

taken whilst using this

appliance and when

following the cleaning

procedure.

oYou should not use a

steam jet or any other

high pressure cleaning

equipment to clean the

appliance.

Declaration of conformity

This appliance complies with the

following European Directives:

-2006/95/CE General

regulations / Low tension

-1935/2004/CE 90/128/EEC

This appliance is suitable to

come in contact with food

-2004/108/CE

Electromagnetic compatibility

oThe manufacturer declares

that the hob is built using

certified materials. This

appliance must be used by

a trained person for

domestic purposes only.

To avoid damaging your

appliance

oThe ceramic glass can be

damaged by objects

falling onto it.

oThe ceramic glass edge

can be damaged by

knocks from cookware.

oCast iron and cast

aluminium cookware with

damaged bases may

scratch the ceramic

surface if they are

dragged across it.

oPans should be lifted on

and off the hob surface

and not dragged.

oThe cooking zone should

not be switched on

without cookware placed

on it. Also the cookware

should not be empty.

oFood or liquid that has

high sugar content may

damage the hob top, if it

comes into contact with

the ceramic hob surface.

Any spillages should be

wiped up immediately,

however this may not

prevent the hob surface

from becoming damaged.

Specifications

Product dimensions

Depth: 345 mm

Width: 280 mm

Height: 60 mm

Product specifications:

o1 x 2.00 kW standard induction zone (Ø 190 mm)

oFront touch control operation

oElectronic timer

Electrical details

Rated Voltage: 220 - 240 Vac 50/60 Hz

Supply Connection: 13 A (double pole switched fused

outlet with 3mm contact gap)

Max Rated Inputs: 2.00 kW

Mains Supply Lead: 3 core x 1.5 mm²

For future reference please record the following information which can

be found on the rating plate and the date of purchase which can be

found on your sales invoice. The rating plate of your hob is located on

the underneath of the appliance.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Ceramic hob surface layout

Control panel layout

1. ON/STANDBY button

2. Power light

3. Heat button

4. Heat “W” light

5. LED display

6. Temperature light

7. Temperature button

8. Timer button

9. Minus button

10. Timer “min” light

11. Plus button

Using the induction hob

Before first use

IMPORTANT: You should clean the ceramic hob surface (see

“Cleaning and maintenance” section).

oYou should switch on the hob for 5 minutes at the maximum

setting. This will help to eliminate any new smell that exists and

evaporate any humidity that has formed on the heating elements

during transit.

oYou must place a saucepan filled half full with cold water on the

zone as you burn it off. Otherwise the induction zone will not

operate.

Cooking on the induction zone

oWhen the appliance is first connected to the

electrical supply, the power light (2) will flash to

indicate that the hob is in a standby state.

oPress the ON/STANDBY button (1). A buzzer will sound and the

power light (2) will turn on.

oPlace a suitable pan on the cooking zone. Make sure that the

bottom of the pan and the surface of the cooking zone are clean

and dry.

oPress the plus button (11) and the heat “W” light (4) will turn

on to indicate that the hob is heating up.

oThe hob will be set at the default heat setting of

3. You can change the heat level by using the

plus and minus buttons.

oYou can adjust the heat setting at any time

during the cooking process.

Autres manuels pour BHI100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Baumatic Plaque

Baumatic

Baumatic BT18.5SS Manuel utilisateur

Baumatic

Baumatic BHS600.5-SS Manuel utilisateur

Baumatic

Baumatic Pythagora P61SS Manuel utilisateur

Baumatic

Baumatic B46.1SS Manuel utilisateur

Baumatic

Baumatic BHG112SS Manuel utilisateur

Baumatic

Baumatic BSIH64-ANZ Manuel utilisateur

Baumatic

Baumatic PVC2SS Pythagora Manuel utilisateur

Baumatic

Baumatic BTC2.1SSS Manuel utilisateur

Baumatic

Baumatic BHG610SSL Manuel utilisateur

Baumatic

Baumatic BHG300.6SS Manuel utilisateur

Baumatic

Baumatic BHI300 Manuel utilisateur

Baumatic

Baumatic BHG300.5SS Manuel utilisateur

Baumatic

Baumatic B47 Manuel utilisateur

Baumatic

Baumatic BHTP400SS Manuel utilisateur

Baumatic

Baumatic BE2SS Manuel utilisateur

Baumatic

Baumatic AS6.2 Manuel utilisateur

Baumatic

Baumatic B47SS Manuel utilisateur

Baumatic

Baumatic BHI900SS Manuel utilisateur

Baumatic

Baumatic BHG631SS Manuel utilisateur

Baumatic

Baumatic BHG300SS Manuel utilisateur

Baumatic

Baumatic Studio Solari AS26SS Manuel utilisateur

Baumatic

Baumatic AS4.1 Mode d'emploi

Baumatic

Baumatic PHC620SS Manuel utilisateur

Baumatic

Baumatic BHS320.55SS Manuel utilisateur

Manuels Plaque populaires d'autres marques

Siemens

Siemens EX875KYV1E Fiche technique

AEG

AEG CERAMIC HOB 6010 K Manuel utilisateur

VALERA

VALERA CT 70A Manuel utilisateur

Zanussi

Zanussi ZGF 6420 Manuel utilisateur

Gaggenau

Gaggenau CI 273 Manuel utilisateur

G3 Ferrari

G3 Ferrari Energy Manuel utilisateur

Pkm

Pkm IN4B Manuel utilisateur

Award

Award H903BG Manuel utilisateur

Zanussi

Zanussi VCH 5005 RZ Manuel utilisateur

Miele

Miele KM 523 Manuel utilisateur

Hotpoint

Hotpoint IS67V8CCXT/E Manuel utilisateur

AEG

AEG HK854870XB Manuel utilisateur

Cookology

Cookology SEP600BK Manuel utilisateur

Bauknecht

Bauknecht Hob Manuel utilisateur

Zanussi

Zanussi ZGM 782 Manuel utilisateur

dipo INDUCTION

dipo INDUCTION DIBK218S Manuel utilisateur

Miele

Miele KM 5987 Manuel utilisateur

Miele

Miele KM 360 G Manuel utilisateur
