Barracuda F100 Manuel utilisateur

Barracuda CloudGen Firewall

Barracuda NG Firewall F100 / F101 1 / 4

Barracuda NG Firewall F100 / F101

https://campus.barracuda.com/doc/6979608/

Opening your Barracuda Networks appliance or removing its warranty label unless instructed to

do so by Barracuda Networks support will void your warranty and hardware support.

Barracuda Networks Appliance Safety Instructions

General

Revision A Revision B

Front

Back

Default Port Conﬁguration

Label OS Notation Speed/Type (Revision A) Speed/Type (Revision B) Management Port

1 port1 10/100 MBit RJ45 10/100/1000 MBit RJ45 X

2 port2 10/100 MBit RJ45 10/100/1000 MBit RJ45

3 port3 10/100 MBit RJ45 10/100/1000 MBit RJ45

4 port4 10/100 MBit RJ45 10/100/1000 MBit RJ45

Hardware Speciﬁcations

Component Revision A Revision B

CPU VIA 500 MHz VIA 500 MHz

Memory 1 GB 2 GB

Flash Disk 4 GB 4 GB

USB 2x USB 2.0 2x USB 2.0

Form Factor Desktop Desktop

Dimensions (W/D/H) 36 x 19 x 5 cm 37.5 x 19x 5 cm

Barracuda CloudGen Firewall

Barracuda NG Firewall F100 / F101 2 / 4

When planning to deploy this model with the Barracuda 19" Rackmount Shelf Kit, please take into

consideration, that the overall height exceeds one rack unit (1 RU).

Net Weight 3,5 kg 3,5 kg

Power Supply Input Voltage 100 - 240 V, AC 100 - 240 V, AC

Power Supply Output Voltage 12 V, DC 12 V, DC

Power Supply Voltage 47 Hz - 63 Hz 47 Hz - 63 Hz

Power Supply Watts 60 W 60 W

Storage Temperature -20 °C - +70 °C -20 °C - +70 °C

Operation Temperature 0 °C - 40 °C 0 °C - 40 °C

Relative Humidity 5% - 95%, non-condensing 5% - 95%, non-condensing

Certiﬁcations CE, FCC, ROHS CE, FCC, ROHS

WiFi (F101 only) 802.11 b/g or better extended

range WiFi adapter

802.11 b/g/n up to 150 Mbps

single antenna extended range

The hardware speciﬁcations list was valid at the time this manual was published. The listed

components are subject to change at any time, as Barracuda Networks may change hardware

components due to technological progress. Therefore, the list may not reﬂect the current

hardware conﬁguration of the Barracuda Networks NG Firewall or NG Control Center appliance it

was delivered with.

Status LED

Your appliance is equipped with a variety of LEDs. One of them is the Status LED. It is either

labeled with a heart symbol or the term Status. It indicates the appliance’s operational state by

changing colors between green, orange and red and by changing between blinking and steady

glowing. The table below shows the diﬀerent meanings of the diﬀerent glowing states.

Color Glowing

State Meaning installation

Meaning Normal Operation or

Active Recovery Technology

Operation

Oﬀ Oﬀ

Appliance is powered oﬀ or

installation has not initialized far

enough for LED control when

installation is started.

Appliance is powered oﬀ.

Green Blinking Normal installation. Appliance is either booting, shutting

down or performing a system update.

Barracuda CloudGen Firewall

Barracuda NG Firewall F100 / F101 3 / 4

Green Steady

Installation was completed

successfully, appliance is halted for

reboot or installation was not yet

initialized far enough for LED

control.

Barracuda NG Firewall is up and running.

Red Blinking Error during installation.

An error has appeared preventing

Barracuda NG Firewall from entering the

up state.

If no orange light available: appliance is

in ART mode.

Red Steady - Appliance is halted and may be

disconnected.

Orange Blinking - -

Orange Steady - Appliance is in ART mode.

Not all appliances support orange and/or red LED colors. Depending on the appliance type, the

status LED might be on by default and it might take some time during boot and installation to

start either blinking or changing the color. Furthermore, the status LED might blink at diﬀerent

frequencies.

Serial Console Port

In order to establish a console connection to the appliance using a serial cable (Revision A: DB9,

Revision B: RJ45), you need to conﬁgure the serial port on the terminal using the following

parameters:

Parameter Value

Baud 19200

Bits 8

Stop bit 1

Parity None

Handshake None

Barracuda CloudGen Firewall

Barracuda NG Firewall F100 / F101 4 / 4

Figures

F100-A-Front.png1.

F100-B-Front.png2.

F100-A-Back.png3.

F100-B-Back.png4.

portion of this document may be copied, distributed, publicized or used for other than internal documentary purposes without the written consent of

an oﬃcial representative of Barracuda Networks Inc. All speciﬁcations are subject to change without notice. Barracuda Networks Inc. assumes no

responsibility for any inaccuracies in this document. Barracuda Networks Inc. reserves the right to change, modify, transfer, or otherwise revise this

publication without notice.
