Cisco S190 Manuel utilisateur
Cisco Systems, Inc.
www.cisco.com
Cisco S190 Web Security Appliance
Quick Start Guide
• Welcome
• Before You Begin
• Document Network Settings
• Plan the Installation
• Install the Appliance in a Rack
• Plug In the Appliance
• Temporarily Change Your IP Address for Remote Access
• Connect to the Appliance
• Power Up the Appliance
• Log In to the Appliance
• Run the System Setup Wizard
• Check for Available Upgrades
• Configure Network Settings
• Configuration Summary
• Additional Configuration
2
• Where to Go from Here
• Cisco Notification Service
Welcome
Thank you for choosing the Cisco S190 Web Security Appliance (Cisco S190).
The Cisco S190 helps organizations secure and control web traffic.
This guide describes how to physically install the Cisco S190 appliance and use
the System Setup Wizard to configure basic settings. You can also refer to the
AsyncOS for Cisco Web Security Appliances User Guide.for information about
how to configure appliance settings.
Before You Begin
Before you begin the installation, make sure that you have the items needed. The
following items are included with the Cisco S190 Web Security Appliance:
• Rails and adaptor kit
• Power cable
• Ethernet cable for connecting the appliance to your network
• Regulatory Safety and Compliance Information
You will need to provide the following items yourself:
• Rack cabinet enclosure (if rack-mounting the appliance)
• Phillips-head screwdriver for assembling rails
• 10/100 Gigabit Base-T TCP/IP LAN
• Desktop or laptop computer
• Web browser (or SSH and terminal software)
• Network and administrator information for the “Document Network
Settings” section on page 3 and “go live” configuration
3
Document Network Settings
Before you begin, write down the following information about your network
and administrator settings.
Deployment Options
• Web Proxy
–
Transparent with L4
–
Switch Transparent with
WCCP Router
–
Explicit Forward Proxy
• L4 Traffic Monitor
–
Simplex tap/Span
port
–
Duplex tap/Span
port
Network Context
Is there another proxy on the
network:
Yes
Other Proxy IP Address:
Other Proxy Port:
Network Settings
Default System Hostname:
DNS Servers: Use the Internet root DNS
servers.
Use the following DNS
servers (maximum 3):
1.
2.
3.
Network Time Protocol (NTP)
Server:
Time Zone Region:
Time Zone Country:
Time Zone GMT Offset:
4
Interface Settings
Management Port
IP Address:
Network Mask:
Hostname:
Data Port (Optional, see Note)
IP Address:
Network Mask:
Hostname:
Note The Web Proxy can share the management interface. If
configured separately, the Data interface IP address and
the management interface IP address cannot share the
same subnet.
Routes
Internal Routes for Management
Default Gateway:
Static Route Name:
Static Route Destination
Network:
Static Route Gateway:
Internal Routes for Data
Default Gateway:
Static Route Name:
Static Route Destination
Network:
Static Route Gateway:
5
Transparent Routing Device
Device Type: • Layer 4 Switch or No
Device
• WCCP Router
–
Enable standard
service ID
(web-cache).
–
Router Addresses:
_________________
–
Enable router
security.
Password:
_________________
Note When you connect the appliance to a WCCP router, you
might need to configure the Web Security appliance to
create WCCP services after you run the System Setup
Wizard.
Administrative Settings
Administrator Password:
Email System Alerts To:
SMTP Relay Host: (Optional)
AutoSupport: Enable
SenderBase Network
Participation:
Enable
• Limited
• Standard
6
Plan the Installation
Decide how you are going to configure the Cisco S190 Web Security Appliance
within your network.
The Cisco S190 appliance is typically installed as an additional layer in the
network between clients and the Internet. Depending on how you deploy the
appliance, you may or may not need a Layer 4 (L4) switch or a WCCP router to
direct client traffic to the appliance.
Deployment options include:
• Transparent Proxy—Web proxy with an L4 switch
• Transparent Proxy—Web proxy with a WCCP router
• Explicit Forward Proxy—Connection to a network switch
• L4 Traffic Monitor—Ethernet tap (simplex or duplex)
–
Simplex Mode: Port T1 receives all outgoing traffic, and port T2
receives all incoming traffic.
–
Duplex Mode: Port T1 receives all incoming and outgoing traffic.
Security Services
L4 Traffic Monitor: • Monitor only
• Block
Acceptable Use Controls: Enable
• IronPort URL Filters
• Cisco IronPort Web
Usage Controls
Web Reputation Filters: Enable
Malware and Spyware Scanning: • Enable Webroot
• Enable McAfee
• Enable Sophos
Action for Detected Malware: • Monitor only
• Block
IronPort Data Security Filtering: Enable
7
Note To monitor true client IP addresses, the L4 traffic monitor should
always be configured inside the firewall and before NAT (Network
Address Translation).
If your installation includes multiple Cisco Web Security Appliances (S-Series)
or Cisco Email Security Appliances (C-Series), you may want to also use a Cisco
Content Security Management Appliance (M-Series) to manage them, as shown
in the following network diagram:
8
Install the Appliance in a Rack
Install the Cisco S190 Web Security Appliance using either the slide rails or fixed
rack mount brackets. For information about these installation options, see the
Cisco x90 Series Content Security Appliances Installation and Maintenance
Guide.
Appliance Placement in a Rack
• Ambient Temperature—To prevent the appliance from overheating, do not
operate it in an area that exceeds an ambient temperature of 104°F (40°C).
• Air Flow—Be sure that there is adequate air flow around the appliance.
• Mechanical Loading—Be sure that the appliance is level and stable to avoid
any hazardous conditions.
9
Plug In the Appliance
Plug the female end of the power cable into the power supply on the back panel
of the appliance. Plug the male end into an electrical outlet.
Temporarily Change Your IP Address for Remote
Access
To remotely configure the Cisco S190 using the network connection, you must
temporarily change the IP address of your computer. Alternatively, you can use
the serial console to configure the Cisco S190, without changing the IP address.
If you use the serial console, proceed to section 8 below.
Note Make a note of your current IP configuration settings because you will
need to revert to these settings after you finish the configuration.
For Windows
Step 1 Connect your laptop to the primary Management Port (labeled M1)
using the cross over or Ethernet cable included in the system box. The
Cisco S190 appliance uses the M1 Management port only.
Step 2 Go to the Start menu and choose Control Panel.
Step 3 Double-click Network and Sharing Center.
Step 4 Click Local Area Connection and then click Properties.
Step 5 Select Internet Protocol (TCP/IP) and then click Properties.
Step 6 Select Use the Following IP Address.
10
Step 7 Enter the following changes:
• IP Address: 192.168.42.43
• Subnet Mask: 255.255.255.0
• Default Gateway: 192.168.42.1
Step 8 Click OK and Close to exit the dialog box.
For Mac
Step 1 Launch the Apple menu and choose System Preferences.
Step 2 Click Network.
Step 3 Select the network configuration with the green icon. This is your active
connection. Then click Advanced.
Step 4 Click the TCP/IP tab and, from Ethernet settings, choose Manually
from the drop-down list.
Step 5 Enter the following changes:
• IP Address: 192.168.42.43
• Subnet Mask: 255.255.255.0
• Router: 192.168.42.1
Step 6 Click OK.
