Barco Evo22sxplus Manuel

Evo22sx+

high resolution business presentation projector



The evo22sx+ has been designed for

businessusersandcorporations.WithSXGA+

resolutionDLP®technologyandunmatched

compatibility,itworkswithvirtuallyanything

you connect it to. No more nervous

presenters or support calls when you can’t

getanimageprojected.Withalmostdouble

the workspace of regular XGA, SXGA+

provides very wide compatibility, from high

resolutionnotebookandlaptopcomputersto

graphicsworkstations.

RealColorcolormanagementsuite

TheRealColorcolormanagementsuiteensuresperfectcolorreproductionand

allowstheusertodefineadesiredwhitepoint,ormatchthecolorsfromthe

projectortothepictureonthescreenoraprintfortruecolorimaging.Product

presentationsandcorporateprofileslookasgoodastheydoinreallifeandon

printed paper. In the evo22sx+, RealColor makes further use of VIDI™ lamp

technologytoenhancecolors,andsustainimagequalityovertime.

Professionalqualityvideo

With builtin high performance video processing, the evo22sx+ provides

professionalqualityvideoinallsettings,bothwithanaloganddigitalsources.

Greatimagequality

Themostimportantthingaboutyourpresentationishow you communicate

yourmessage,andhowitisperceivedbytheaudience.ThankstotheVIDI™

lamp and RealColor color management technologies, the evo22sx+ provides

outstandingcolors,andpictureaccuracy.

Lowoperatingnoise

Evo22sx+

high resolution business presentation projector

Inmanychallengingenvironments,thenoiseofaprojectorcanbedisturbing

butthisisnotthecasewiththeevo22sx+.Itisbuiltentirelyfrommagnesium

andexoticmaterialslikeceramicstogive low noise. Thechassisisusedfor

heatdissipation,andallmovingpartsaredecoupledfromthechassisinorder

tomaketheleastnoise.

Simpleandsecureassetmanagement

Builtinnetworkingallowsremoteassetmanagementthroughasimpleweb

interface, or through our dedicated ProNet.Manager asset management

software. It also allows easy integration into IP and RS232C based control

systems.Familiar,4digitpincodepasswordprotectionpreventsunauthorised

use.

Highperformanceoptics

Theprecisiongroundzoomlensfeatureslensshiftfordistortionfreeimaging,

excellentsharpnessandfocusfrom one of the world’s leading lens makers.

Front access lamp replacement reduces maintenance needs and operating

costsinanyinstallation.

Perfectlyfitforawiderangeofapplications

Not only is the evo22sx+ perfectly fit for business presentations, it is also

perfect for detailed presentations, such as financial models, product

visualisation, database management, engineering and R&D, as well as any

graphicallydemandingwork.



Productspecifications Evo22sx+

Technology singlechipDLP™projectorwithVIDIandBrilliantColortechnologies

Concept verticallensshiftdesign

Colorwheel HighBrightness

Resolution SXGA+(1400x1050)

Brightness Upto3000lumens

Contrast Upto2500:1((on/off))

AspectRatio 4:3(SXGA+)

Displaycolors 30bitRGB

Latency ~22mswithgraphicsinputs

Computergraphicsformats 1920x1080640x480pixelresolution

Horizontalscanfrequencies 15150kHz(resolutiondependant)

Verticalscanfrequencies 48190Hz(resolutiondependant)

Videoformats HDTV(1080p,1080i,720p)NTSC,PAL,SECAM

Lensoperation Focus,ShiftandManualzoom

Lenses Standardprojectionlens

⋅Lensnumber:F2.6/503007500

⋅Focusrange:1.510.0m

⋅Throwratio⋅1.732.39:1(SXGA+)

Imagewidth 0.75.5m

Lightsource 220WUHPlamp

Lamplifetime Upto2250hours(Fullpower)Upto3000hours(Ecomode)

Computerinputs 1xDVID1xHDMI1.3a1xVGA

VideoInput 1xHDMI1.3a1xYPbPr1xSvideo

AudioInput 1xComposite

Controlpossibilities 1xRJ45TCP/IP1x9pinDSUBRS2321xUSB

Dimensions 278x94x234mm(WxHxD)

Weight 2.9kg

Powerrequirements 3.01.3A~100240V,5060Hz

Conformances CE,FCCClassA,UL,cULandcCSAus

Operatingtemperature 040°C

Storagetemperature 2060°C

Operatinghumidity 2080%RH

Storagehumidity 1090%RH

Color Blackmetallic

Warranty 3yearsstandardwarranty,500hoursor90daysonlamp(whichevercomesfirst),

conditionsapply

BTUperhour

Generatedon:10Apr2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
