BARCO PROJECTION

UNIVERSAL LAMP FOR 6000 SERIES

PROJECTORS

R9841550

INSTALLATION NOTE

18042002 R5976453/01

Barco nv Intelligent Displays

Noordlaan 5, 8520 Kuurne

Phone: +32 56.36.82.11

Fax: +32 56.35.86.51

E-mail: [email protected]

Visit us at the web: www.barco.com

Printed in Belgium

1. Safety

1. SAFETY

1.1 Safety

Safety Warnings

The procedures in this manual are intended for use only by qualified service technicians who have been trained and authorized by

BARCO !

Switch the projector to stand by and let it cool down for at least 15 minutes before starting with the lamp replacement. These lamps

consist of a quartz arc tube operating at very high temperature and high pressure which may explode suddenly. There is a risk of

personal injury and property damage from hot quartz arc tube particles if handled incorrectly.

Power down the projector and unplug the power cord from the wall outlet. Once the projector is cooled down and the power is off,

continue with the replacement procedure.

Do not exceed the indicated maximum total lifetime of the lamp for safe operation in normal power mode. Do not use it longer !

Always replace the lamp with the BARCO lamp kit for 6500 projectors.

R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002 1

1. Safety

2R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002

2. Introduction

2. INTRODUCTION

2.1 Lamp specifications

Universal Lamp for 6500, 6400i & SIM6 HB projectors.

This lamp is designed to be used in two different configurations of the projector:

• table mount

• ceiling mount

The mechanical design allows to shift the lamp unit by means of two adjustments, hereby insuring the best optical performances of

the lamp in both projector configurations.

The following procedures are intended for use only by qualified service technicians who have been trained

and authorized by BARCO !

R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002 3

2. Introduction

4R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002

3. Access to the lamp unit

3. ACCESS TO THE LAMP UNIT

3.1 Removing the protection cover

What has to be done ?

• The lamp house door has to be opened and removed.

• The lamp protection cover has to be removed.

Make sure that the projector is turned off ! Never open the lamp house when the projector is on!

Necessary tools

flat screwdriver of 5 mm

How to remove the lamp door ?

1. Turn with a screwdriver the door lock screw a quarter turn counter clockwise. (image 3-1)

2. Open the door a little.

3. Unhook the door from its fixing points. (image 3-2)

Image 3-1

R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002 5

3. Access to the lamp unit

Image 3-2

How to remove the protection cover

1. Loosen with a screwdriver the 3 indicated bolts. (image 3-3)

2. Pivote the plate a little downwards. (image 3-4)

3. Take out the protection cover.

Image 3-3

Image 3-4

Hot surface !

Do not touch the fan blades.

High pressure lamp may explode if improperly handled. Refer servicing to qualified service personnel.

6R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002

4. Removing the lamp unit

4. REMOVING THE LAMP UNIT

4.1 Extracting the lamp unit

Necessary tools

No tools.

How to remove the lamp unit ?

1. Slide the lamp unit backwards. (image 4-1)

2. Take the sides of the lamp connector between thumb and finger.

3. Unlock the connector by pushing at the same time on both lock parts and separate the connectors.

4. Extract the lamp from the housing and put it on a table.

Image 4-1

R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002 7

4. Removing the lamp unit

8R5976453 UNIVERSAL LAMP FOR 6000 SERIES PROJECTORS 18042002
