STANDARD FEATURES

OPTIONS & ACCESSORIES

CERTIFICATIONS

SPECIFICATIONS

Counter top electric deck oven features two Cordierite ceramic

hearth baking decks, each 17 3/4” wide (451 mm) by 17 1/2” deep

(445 mm) in a single bake chamber. 3” decks heights make these

ovens ideal for pizza, pretzels, flat breads and bakery products

baked directly on the hearth deck, pans, baking sheets or screens.

Top and bottom heat is provided by three heavy duty Incoloy steel

tubular heating elements total 1800 watts @ 120V or 2850 watts

@ 208-240V. Thermostat ranges from 300° to 650° F (149° to

343° C). The 120V model is recommended for par baked products

only.

Exterior front, sides, top and door is constructed of type 430

stainless steel and measures 22 1/4” wide (572 mm) by 17 1/2”

tall (445 mm). Door handle is constructed of tubular stainless steel.

Baking chamber is fabricated of high heat aluminized steel and

welded to form a single unit. Entire oven, including door, is

insulated with 1 1/2” (38 mm) thick industrial grade insulation.

The P18S features a continuous ring timer with manual shut off, a

6 foot line cord (1830 mm), and limited one year parts and labor

warranty.

Two hearth baking decks

3 1/4” deck heights

Top and bottom heat

1800 watts @120V or 2850 watts @ 208-240V

Stainless steel exterior

High-heat aluminized steel baking chamber

1 1/2” (38 mm) thick industrial grade insulation throughout

Continuous ring timer with manual shut-off and volume

control

6 foot (1830 mm) line cord

One year limited parts and labor warranty

4” (102 mm) adjustable legs

Double pane thermo-glass window in door

Stainless steel stand with or without casters

Stacking kit

BAKERS

PRIDE

qModel P18S

COUNTER TOP

ELECTRIC

DECK OVEN

BAKERS

PRIDE

Continuous product improvement is a policy of Bakers Pride Oven Company.

Therefore, specifications and design are subject to change without notification

BAKERS PRIDE OVEN COMPANY, INC.

30 Pine Street, New Rochelle, NY 10801

914/576-0200 • 1-800-431-2745 • fax 914/576-0605

Model P18S

Job ____________ Item # ___________

ELECTRIC DECK OVENS

CANADIAN GAS ASSOCIATION

BAKERS

PRIDE

Continuous product improvement is a policy of Bakers Pride Oven Company.

Therefore, specifications and design are subject to change without notification

TS:04/02

BAKERS PRIDE OVEN COMPANY, INC.

30 Pine Street, New Rochelle, NY 10801

914/576-0200 • 1-800-431-2745 • fax 914/576-0605

SHIPPING INFORMATION

Model

P18S 125 1027 29 22

57 .28

686 737 559

Shipping Weight Crate SizeCarton Dimensions

Lbs. Cubic

Feet

Inches

Width Depth Height

Inches Inches

Kilos Cubic

Meter

mm mm mm

POWER SUPPLY

Model

P18S

1800

2850

120

208-240

5-15P

6-15P BS1363A

5-20P

6-20P CEE7-VII

VOLTAGEWATTS PHASE AMPS

Under 500 lbs = Shipping Class # 70

FRONT VIEW

TOP VIEW

SIDE VIEW

Each oven requires a separate electrical connection.

MINIMUM CLEARANCES

Left Side

Right Side

Rear

* In European Community Countries and North America. In NON-COMBUSTABLE locations only.

** In European Community Countries only in COMBUSTIBLE locations. NOT for North America.

Inches Inches

Non-Combustible Construction* Combustible Construction**

mm mm

NEMA Plug #

USA Canada UK Europe

1 1/2"

(38 mm)

9 1/2"

(241 mm)

3 1/4 (83 mm)

6 3/4"

(171 mm)

9 1/4"

(235 mm)

23"

(584 mm)

17"

(432 mm)

25"

(635 mm) 18 3/4"

(476 mm)

19 1/4"

(489 mm)

BAKERS PRIDEBAKERS PRIDE

400 350

300

250

200

150

450

500

550

°F

°C

100

120

140

160

180

200

220

240

260

280

0MINUTESMINUTES 1

10 98

BS 1363 A CEE 7-VII

6-20P

5-15P 5-20P

6-15P
