INSTALLATION AND OPERATING INSTRUCTIONS

Dante SERIES

GAS CHAR BROILERS

Models: FL, CT and LC

INTENDED FOR OTHER THAN HOUSEHOLD USE

RETAIN THIS MANUAL FOR FUTURE REFERENCE

BROILER MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES

IMPORTANT INSTRUCTIONS

After the gas supply has been connected to your unit, it is extremely important to check piping for

possible leaks. To do this, use soap and water solution or solutions which are expressly made for

this purpose. DO NOT USE matches, candles, flames, or other sources of ignition since these

methods are extremely dangerous.

Post in a prominent location instructions to be followed in the event you smell gas. Obtain these

instructions from your local gas supplier.

! !

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

! !

WARNING

Improper installation, adjustment, alteration, service or maintenance

can cause property damage, injury or death. Read the Installation,

Operating and Maintenance Instructions thoroughly before installing or

servicing this equipment.

4/01 Form # U4159A

Bakers Pride Oven Co., Inc.

30 Pine Street

New Rochelle, NY 10801

(914) 576-0200 Phone (800) 431-2745 US & Canada

(914) 576-0605 Fax www.bakerspride.com Web Address

INDEX

I. INSTALLATION INSTRUCTIONS

SECTION ITEM PAGE

1 Installation 3

2 Clearances 4

3 Gas Connection 4

4 Burners, Heat Deflectors 5

5 Radiant Units 5

6 Glo-Stone Units 5

7 Drip Pans, Grease Drawer 6

8 Griddle Plate 6

9 Smoker Boxes 6

10 Lighting Instructions 6

11 Additional Instructions 8

12 Installation with Casters 8

II. OPERATING INSTRUCTIONS

SECTION ITEM PAGE

1 Lighting Procedure 8

2 Broiling 8

III. MAINTENANCE

SECTION ITEM PAGE

1 Service 9

2 Care and Cleaning 9

3 Cleaning Tools 10

IV. INTERNATIONAL DISTRIBUTION & SERVICE CENTERS

SECTION ITEM PAGE

1 Illustrations 11

2 International Distribution & Service Centers 12

(FL,CT,LC)B-XX(R,GS) 243036424854606672

Number of Burners 3 4 5 6 7891011

G20 & G25 Gas 17.58 23.45 29.31 35.17 41.03 46.89 52.75 58.61 64.47

G30 & G31 Gas 15.82 21.11 26.38 31.65 36.93 42.20 47.48 52.75 58.03

Net Heat Input in kw (Europe)

17.58 23.45 29.31 35.17 41.03 46.89 52.75 58.61 64.47

19.53 26.06 32.57 39.07 45.59 52.10 58.60 65.11 71.63

G20 & G25 Gas

G30 & G31 Gas

Gross Heat Input in kw (Europe)

XX = 24, 30, 36, 42, 48, 54, 60, 66 or 72 (Overall width in inches)

FL = Floor Model CT = Counter Top Model LC = Low Profile Model

B = Broiler with Rear Gas Connection R = Radiant Type GS = Glo-Stone Type

Model Definition

NOTE:

Description of Model Numbers and Definition of Prefixes used in this manual are shown below.

I. INSTALLATION INSTRUCTIONS

1. INSTALLATION:

(i) Installation of this broiler must conform with the latest edition of ANSI Z223.1 National Fuel Gas

Code in USA (CAN/CGA-B-149.1 or 2 Installation Code in Canada) and/or local codes.

(ii) This appliance must be installed by a competent person in accordance with the rules in force. In

U.K. Corgi registered installers (Including the regions of British Gas) undertake to work to safe and

satisfactory standards. This appliance must be installed in accordance with the current Gas Safety

(Installation and Use) Regulations and the relevant Building Regulations / IEE Regulations. Detailed

recommendations are contained in the British Standards Code of Practice BS 6172, BS 5440:Part 2

and BS 6891.

(iii) Use this Broiler only with an adequately sized exhaust hood. The room in which this broiler is

installed must be suitably vented in accordance with the National and/or local codes.

(iv)This broiler when installed must be electrically grounded in accordance with local codes, and/or

the latest edition of the National Electrical Code ANSI/NFPA No. 70 in the USA (Canadian Electrical

Code CSA Standard C22.1, Part 1 in Canada).

In Europe, the appliance must be connected by an earthing cable to all other units in the complete

installation and thence to an independent earth connection in compliance with EN 60335-1 and/or

local codes.

2. ACCEPTABLE CLEARANCES:

Due to intense heat generated by radiation, above the grate level only non-combustible construction

should be provided. In USA and Canada these broilers should be installed in non-combustible

locations only.

(i) Minimum Clearance from Non-Combustible Construction (in European Community

Countries and North America).

Right

Left

Back

Floor

4" (100 mm)

(ii) Minimum Clearance from Combustible Construction (in European Community Countries

Only)

Right

Left

Back

Floor

250 mm

150 mm

3. GAS CONNECTION:

The gas pressure regulator supplied must be installed at the gas inlet of each broiler. Each

regulator is adjusted to yield a pressure of 3.5" water column (9 mbar) for natural Gas or 10" water

column (25 mbar) for Propane or Butane gas. No pressure regulator is required for propane gas in

Canada.

Recommended minimum gas supply lines are listed below for units with:

7 Burners or less:

3/4" (19 mm)

8 Burners and more:

1" (25.4 mm)

Gas supply pressures in the European Community Countries should be as shown below:

Gas Type Supply Pressure

G20 20 mbar

G25 25 mbar

G20/25 20/25 mbar

G30 30 or 50 mbar depending on country

G31 30, 37 or 50 mbar depending on country

A shut-off valve in a readily accessible location must be installed on the gas supply line before

connecting it to the unit.

When making gas pipe connections, only pipe joint compound resistant to the action of liquefied

petroleum gases should be used.

The broiler and its individual manual shut-off valve must be physically disconnected from the gas

supply piping system during any pressure testing of that system at test pressure in excess of ½ psig

(3.45 kpa).

The broiler must be isolated from the gas supply piping system by closing its individual manual

shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to

or less than ½ psig (3.45 kpa).

4. BURNERS, HEAT DEFLECTORS:

Air-Mixer caps on the front of all burners are adjusted, tightened and sealed before the unit leaves

the factory. If it is necessary to adjust the Air-Mixer caps, the adjustment must be done by a Factory

Authorized technician only, who should seal the adjustment screw after the adjustment.

(i) Position the slot on the front end of the burner over the pin on the front support, keeping the rear

end slightly raised up.

(ii) Place the front venturi end of the burner into valve assembly by fitting the center hole of the Air-

Mixer cap over the brass orifice.

(iii) Drop the rear end of the burner over the pin on the burner support in the rear of the chamber.

(iv) Mount the ‘A’ shaped Heat Deflectors between the burners, supporting them on the locating

slots in the front and rear burner supports.

5. RADIANT UNITS:

(i) Mount ‘A’ shaped radiants over the burners with each end mounted on supports on the front and

rear of the chamber. One radiant should be mounted over each burner assembly.

(ii) Place the top grates, wider flange toward the back, over the radiants until the whole broiling area

is covered. Flipping Top Grates upside down and choosing between two supports in the rear, four

positions are possible for different slopes desired.

6. GLO-STONE UNITS:

(i) Mount angular bottom grate supports over the burners with each end mounted on

supports located on the front and rear of the chamber. One bottom grate support should be

mounted over each burner (small pilot shield towards the front).

(ii) Place the Stainless Steel expanded metal Bottom Grate(s) on the angular support above the

Burners.

(iii) Spread one layer of Glo-Stones covering all of the Bottom Grate(s).

! !

IMPORTANT NOTES

Do not use more than one layer of glo-stones, as that will

reduce the amount of heat reaching the top grates and can

cause overheating and permanent damage to the unit.

(iv) Place Top Grates, wider flange toward the back, over the Glo-Stones until the whole broiling

area is covered. Flipping Top Grates upside down and choosing between two supports in the rear,

four positions are possible for different slopes desired.

7. DRIP PANS, GREASE DRAWER:

(i) Depending on the size of the unit, one or more Drip Pans are provided to hold any grease that

drips down while broiling. Water is usually added to the Drip Pans to reduce flare-ups and flash-

back.

(ii) A Grease Drawer is provided at the left of the Drip Pan to collect the grease from the grease

drain above.

(iii) One Grease Deflector is provided to prevent burning matter from falling into the Grease Drawer

and igniting the accumulated grease there. To install the Grease Deflector, clip its bottom edge to

the left side of the Drip Pan next to the Grease Drawer, push down all the way, then slide the Drip

Pan back into place.

(iv) Grease Drawer, Grease Deflector and Drip Pans should be cleaned daily or more frequently if

necessary.

8. GRIDDLE PLATE (Optional):

The Griddle plate should not cover more than 50% of the broiling area. The Griddle Plate should be

placed on top of the top grates, which for this purpose should be in the flat position.

9. SMOKER BOX (Optional):

(i) This consists of a Smoker Box Housing and a Wood Chip Drawer. For this option you will not

need the Heat Deflectors and the locating slots thus vacated are used to position the Smoker

Boxes.

(ii) From above, mount the Smoker Box Housing between the burners, supporting it on the locating

slots in the front and rear burner supports. From below in the front, slide the Wood Chip Drawer into

the Housing.

10. LIGHTING INSTRUCTIONS:

Each burner has a standing pilot burner which must be lit before the burners can be lit. To light the

Pilot Burners for:

(a) UNITS WITHOUT SAFETY PILOTS

(Not available for European Community Countries).

(i) Turn all broiler valves to ‘OFF’ position.

(ii) Open main gas shut-off valve(supplied by the customer).

(iii) Allow air to bleed from the gas line through the Pilot Burners.

(iv) Light each Pilot Burner using a lit taper.

Adjustment screws for the Pilot Valves are sealed at the factory after adjustment to provide a ½" (13

mm) flame. If adjustment is required, it should be done by a factory authorized technician only, and

the screws must be sealed after the adjustment.

(v) Turn the burner control valves to ‘ON’ to light the burners.

If any burner fails to light, turn that burner valve to ‘OFF’, wait five minutes then repeat the above

procedure.

(vi) After all burners have been lit, turn all burner valves ‘OFF’ and make sure that the pilot burners

stay lit.

Each burner may now be adjusted to the desired flame size by turning the individual burner valve

handle.

TO SHUT DOWN THE UNIT, TURN ALL VALVES ‘OFF’. WAIT FIVE MINUTES BEFORE

ATTEMPTING TO RE-LIGHT.

NOTE: The Pilot Burners will stay lit until the Gas Supply to the unit is turned ‘OFF’.

(b) UNITS WITH SAFETY PILOTS

(i) Turn all broiler valves to ‘O’ position.

(ii) Open main gas shut-off valve (supplied by the customer).

(iii) For each burner, press, turn counter clockwise and hold down that burner control knob at the

pilot burner ignition position.

(iv) Using a lit taper, light that pilot burner.

(v) Release the knob after 30 seconds. Pilot burner should stay lit.

IF THE PILOT BURNER DOES NOT STAY LIT, WAIT FIVE MINUTES AND REPEAT STEPS (iii)

AND (iv). THIS TIME HOLD DOWN THE KNOB LONGER BEFORE RELEASING.

Adjustment screws for the Pilot Burner are sealed at the factory after adjustment to provide a ½" (13

mm) flame. If adjustment is required, it should be done by a Factory Authorized technician only, and

the screws must be sealed after the adjustment.

Each burner may now be adjusted to the desired flame size by turning the individual burner valve

knob

TO SHUT DOWN A BURNER, TURN THAT CONTROL KNOB CLOCKWISE TO THE PILOT

BURNER IGNITION POSITION.

TO SHUT DOWN THE PILOT BURNER AS WELL, PRESS THAT CONTROL KNOB AND TURN

CLOCKWISE TO THE ‘O’ POSITION.

WAIT FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT.

11. ADDITIONAL INSTRUCTIONS:

(i) Keep the area around the broiler free and clear of all combustible material.

(ii) Provision of adequate air supply to your broiler is essential. Provide for sufficient outside air to

enter the broiling area and assure that this air flow is not obstructed.

(iii) Air enters the burner area from the front of your broiler only. Assure that this area is kept open

and unobstructed.

(iv) Servicing is accomplished through the front and top of the broiler. Assure that this area is kept

unobstructed for proper servicing and operation.

12. INSTALLATION WITH CASTERS:

THIS IS AVAILABLE FOR FLOOR MODELS ONLY.

Four casters (two with wheel brakes) and the mounting hardware are packed and included in the

shipment, if ordered that way.

Install casters with wheel brakes on the front of the unit.

Installation of the unit should be made with a connector that complies with the latest edition of the

Standard for Connectors for Movable Gas Appliances ANSI Z21.69, in the USA (CAN CGA-6.16 in

Canada) and a quick disconnect device that complies with the latest edition of the standard for

quick disconnect devices for use with gas fuel ANSI Z21.41 in the USA (CAN 1-6.7 in Canada.)

Adequate means must be provided to limit the movement of the appliance without depending on the

connector and any quick disconnect device or its associated piping to limit the appliance movement.

The restraint should be attached to the right side of the back of the unit close to the gas inlet pipe.

If disconnection of the restraint is necessary, the supply gas line should be disconnected first, then

the restraint. When returning it to its position, the restraint should be reconnected first, before the

gas line is reconnected.

II. OPERATING INSTRUCTIONS

ONLY QUALIFIED PERSONNEL, PROPERLY TRAINED AND FAMILIAR WITH THIS

EQUIPMENT SHOULD OPERATE THIS BROILER.

1. LIGHTING INSTRUCTIONS:

See Section 10 of Installation Instructions.

Once the Pilot Burners are lit, the Main Burners of the broiler may be turned ON or OFF by

turning the control knobs.

2. BROILING:

BROILER TOP GRATES MUST BE HOT ENOUGH TO MAKE BLACK CHAR MARKS WHEN

STARTING TO BROIL.

Adequate preheating time is necessary for the food to cook properly and to release from the broiler

grates. Before Broiling, allow Radiant type units to preheat for 10-15 minutes and Glo-Stone type

units for 20-25 minutes.

(i) Do not press the juice out of the meat as that will dry the meat.

(ii) After Broiling, allow the meat to sit covered on a heated platter for 2-5 minutes before cutting.

This will allow the juices to ‘settle’ and the meat will be more moist.

(iii) Do not use forks or other sharp objects to poke holes in the meat or to cut the meat as it cooks.

(iv) Thick pieces of meat require longer broiling time with less flare-up. Reduce flare-up by trimming

excess fat for a longer broil time without burning.

(v) Keep the unit clean. Food caught in the grates will not allow hot air to rise around the product.

This will result in uneven heating, increase the cooking time and cause overheating of the Broiler

which may result in permanent damage.

III. MAINTENANCE

1. SERVICE:

ALL SERVICING SHOULD BE PERFORMED BY A FACTORY AUTHORIZED TECHNICIAN

ONLY.

Shut off the main gas supply before attempting any maintenance or service on the unit. If required,

contact your dealer, a local service company or the factory to obtain a qualified technician for the

required maintenance/service. A list of Dealer and Service locations is part of this manual.

2. CARE AND CLEANING:

(A) FOR ALL MODELS.

The ventilation system must be inspected every six months, more frequently if necessary, and

maintained clean and free of obstruction.

(i) TOP GRATES: The top grates should be cleaned daily with a stiff wire brush or steel wool. The

rods specially the underside need only to be scraped clean of all accumulated food and fat. A light

coat of oil should be applied to the rods after cleaning.

(ii) OUTER SIDES AND THE FRONT: These are stainless steel surfaces. Stainless Steel Cleaner

or any similar cleaner can be used.

(iii) INNER COOKING AREA: These are stainless steel surfaces. Make sure that all the residue is

removed before cooking is resumed.

(iv) HEAT DEFLECTORS: These should be removed and cleaned frequently. These are stainless

steel surfaces. Stainless Steel Cleaner or any similar cleaner can be used.

(v) SMOKER BOXES: The Wood Chip Drawer should be removed and cleaned every day or more

frequently if necessary.

Smoker Box Housing should be removed and cleaned frequently so that drippings do not

accumulate.

(vi) INNER PANELS: These are made of Aluminized steel. Use hot soapy water and soft nylon

scrub pads to clean the surfaces.

(vii) DRIP PAN: Drip Pan and the Grease Drawer should be cleaned daily or more often if

necessary.

(B) FOR RADIANT MODELS.

RADIANTS: These should be removed and cleaned frequently. These are stainless steel surfaces.

Stainless Steel Cleaner or any similar cleaner can be used.

(i) CARE OF GLO-STONES: On a weekly basis, the top grates should be removed and the Glo-

Stones mixed about to break away any carbon deposit so that it falls through the bottom grates.

Spread the Glo-Stones evenly and add only the amount necessary for a single layer.

(ii) CARE OF BOTTOM GRATES: Periodically push all the Glo-Stones to one side and inspect the

bottom grates. If necessary brush the grates with a wire brush.

(iii) BOTTOM GRATE SUPPORT: Frequently clean the Bottom Grate Support with a stiff wire

brush.

CAUTION

Clean the unit only when it is cold.

When cleaning, be sure to rub the metal along grains.

Do not use abrasive pads for cleaning.

Do not use caustic cleaning compounds on aluminized surfaces.

! !

3. CLEANING TOOLS:

Several models of specially designed top grate brushes and grease drain scrapers are available

from Bakers Pride. Contact your local dealer or Bakers Pride for more information.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bakers Pride Gril

Bakers Pride

Bakers Pride Dante FLB-24GS Manuel utilisateur

Bakers Pride

Bakers Pride DANTE XX Manuel utilisateur

Bakers Pride

Bakers Pride SGBR Manuel utilisateur

Bakers Pride

Bakers Pride CH Dante Series Manuel utilisateur

Bakers Pride

Bakers Pride CH-10J Manuel utilisateur

Bakers Pride

Bakers Pride DANTE LCB-24R/GS Manuel utilisateur

Bakers Pride

Bakers Pride Gas Char Broiler F-60R Manuel utilisateur

Bakers Pride

Bakers Pride Dante XXE-10 Manuel utilisateur

Bakers Pride

Bakers Pride DANTE XXE Manuel utilisateur

Bakers Pride

Bakers Pride Dante XXE-10 Manuel utilisateur

Bakers Pride

Bakers Pride COUNTERTOP GAS RADIANT XX-10 Manuel utilisateur

Bakers Pride

Bakers Pride XX-4BG Manuel utilisateur

Bakers Pride

Bakers Pride COUNTERTOP GAS RADIANT XX-10 Manuel utilisateur

Bakers Pride

Bakers Pride Dante SGBR-2 Manuel utilisateur

Bakers Pride

Bakers Pride Dante CTB-36GS Manuel utilisateur

Bakers Pride

Bakers Pride Dante FLB-48R/GS Manuel utilisateur

Bakers Pride

Bakers Pride Dante FLB-72GS Manuel utilisateur

Bakers Pride

Bakers Pride Dante CTB-60GS Manuel utilisateur

Bakers Pride

Bakers Pride C-24GS Manuel

Bakers Pride

Bakers Pride Dante CH-10 Manuel utilisateur

Bakers Pride

Bakers Pride Dante Series XX & CH Manuel utilisateur

Bakers Pride

Bakers Pride Dante FLB-60GS Manuel utilisateur

Bakers Pride

Bakers Pride Dante FLB-36GS Manuel utilisateur

Bakers Pride

Bakers Pride DANTE Series Manuel utilisateur

Manuels Gril populaires d'autres marques

Orbegozo

Orbegozo GR 2300 Manuel utilisateur

bora

bora PT11 Manuel utilisateur

Klarstein

Klarstein 10031664 Manuel utilisateur

Garland

Garland MWE3W Manuel utilisateur

Char-Broil

Char-Broil 463722714 Manuel utilisateur

Nexgrill

Nexgrill 720-0830HK Manuel utilisateur

Kenmore

Kenmore 415.16123800 Manuel utilisateur

Camp Chef

Camp Chef PG24CLAU Manuel utilisateur

Tucker Barbecues

Tucker Barbecues GTR Series Instructions de montage

Monogram

Monogram ZGG540NCP1SS Manuel utilisateur

Equipex

Equipex Sodir Savoy Manuel utilisateur

Gaggenau

Gaggenau VR 414 610 Manuel utilisateur

Miele

Miele KM 408-1 Manuel utilisateur

George Foreman

George Foreman GGR50B Manuel utilisateur

AOG

AOG T series Manuel utilisateur

Gorenje

Gorenje TG2000CB Mode d’emploi

Weber

Weber Genesis Silver-B Permamount NG 051701 Manuel utilisateur

Glen

Glen SA 3037 Manuel utilisateur
