ABOUT THIS MANUAL

This manual contains information concerning the installation, operation and maintenance of the Badger Meter® ER-9 Digital

Resettable Totalizer and Rate of Flow Indicator (ER-9). To ensure proper performance, the instructions given in this manual

should be thoroughly understood. Keep this manual for future reference.

Installation, wiring and programming of the unit is fairly simple and straightforward. This manual is designed to provide you

with a step-by-step guide for this purpose.

Examples are provided only to facilitate programming. Your specific application will most likely require a different set of

numbers for proper programming.

The troubleshooting section lists the most common problems that can be encountered, their most likely cause and the

recommended solution. See “Troubleshooting” on page 12.

PRODUCT DESCRIPTION

The ER-9 is an external or battery powered indicator that displays rate of flow and total flow. The ER-9 also has a scalable pulse

output. It has independent programmable scale factors for rate and totalization, allowing you to program these displayed

values in different but meaningful engineering units, such as gallons per minute and total gallons.

The supertwist LCD display with 8 digits for total, and 4 digits plus legend for rate, provides easy viewing at a glance. For

conditions where ambient light is poor, the display can be backlit by connecting an external DC (10…28V DC) power supply.

A single unit can accept NPN or dry contact inputs for low or high speed applications.

The ER-9 is powered by two replaceable 3V lithium batteries. You can install a new battery before removing the old one,

thereby retaining count total and program data. A low battery indicator appears on the screen about two weeks before the

end of the battery life. See “Battery Installation/Replacement” on page 6. The unit operates in battery mode for at least six

months. To extend battery life to five years, connect the unit to an external DC power source.

Setup is quick and easy as the two front panel keys are used to scroll through and preset values in all program mode choices.

User Manual

Page 5August 2018 REG-UM-00836-EN-12

INSTALLATION

Panel Installation

Place the unit in the panel through a 33 mm x 68 mm cutout. Slide the included gasket over the rear of the unit, then slide

the panel mount bracket into place so that the 4 tabs catch in the grooves on the top and the bottom of the unit (the bracket

should be oriented so that the tabs are on the side nearest the panel). Use the provided panel mount screws to tighten the

bracket until there is a secure seal against the gasket. Do not over tighten.

72 mm

68 mm

33 mm

36 mm

Mounting

Bracket

Gasket

Tabs

Figure 1: Panel installation

Battery Installation/Replacement

OTE:N If the low battery indicator is flashing, replace batteries before they are completely exhausted to retain programming

and indicated volume. If two batteries are present, remove and replace one battery at a time. If only one battery is

present, install a new battery in the open slot before removing/replacing the old battery.

The ER-9 is shipped with two batteries. Remove the battery cover by pushing inward and down. Install batteries in the two

slots. Once the batteries are in place, the unit goes into a self-test mode, and all the segments on the LCD display illuminate.

To exit the self-test mode, press the Reset/Select Rkey. The unit then displays the model number 9for the ER-9. Press the

Reset/Select Rkey again to ready the unit for operation.

Battery

Figure 2: Battery installation

Industrial Registers, Model ER-9 Digital Resettable Totalizer

Page 6 August 2018REG-UM-00836-EN-12

WIRING INSTRUCTIONS

Wiring Terminals

Figure 3: Wiring terminals

Terminal Function Operation

1 DC common —

2Count input NPN signal, 280 Hz max or

Dry contact, 95 Hz max

3 — Not used

4 Remote reset Resets count value when switched to common.

5 Front panel program enable Allows access to program mode when connected to common.

6 Solid-state relay Pulse output (+)

7 Solid-state relay Pulse output (–)

8 DC supply input 10…28V DC for backlighting and/or powering the output.

Table 1: Wiring terminals

Transmitter Connections

For connecting to Badger Meter transmitters, refer to the literature for your specific transmitter and to Table 2 below. The

Connections column refers to the wires on the transmitter. The numbers in parentheses refer to the terminal numbers on the

ER-9. Connect the wire coming from the transmitter to the corresponding terminal number for the ER Remote models.

Connecting to a Generic Reed Switch

To connect a generic reed switch to the ER-9, connect one of the wires to terminal 1 and the remaining wire to terminal 2.

Connecting to a Generic NPN Transmitter

To connect a generic NPN transmitter to the ER-9, connect the emitter to terminal 1. Connect the collector to terminal 2.

Transmitter Connections Transmitter Connections

FT-1 (1/2 in. OP) Black (1) Black (2) PFT-2 White (1) White (2)

FT-1 White (1) White (2) PFT-2E Black (1) Green (2)

FT-1E Black (1) Green (2) PFT-3E Black (1) Green (2)

FT-2 White (1) White (2) PFT-3 White (1) White (2)

FT-420 Black (1) White (2) PFT-420 Black (1) White (2)

MS-E1 Black (1) Red (2) PFT-420/2 Black (1) White (2)

MS-E5 Black (1) Red (2) PFT-4E Term 6 (1) Term 5 (2)

PFT-1E Term 6 (1) Term 5 (2) PM-5 Black (1) Red (2)

Table 2: Transmitter connections

User Manual

Page 7August 2018 REG-UM-00836-EN-12

OPERATION

Display Types

34675890

R2345

Figure 4: Total display Figure 5: Rate display

Total Display

Total Display indicates the present count value, which is equal to the number of pulses received (since the last reset)

multiplied by the Totalizer Scaler Value in program mode 1.

Rate Display

Rate Display indicates the rate value, which is equal to the input frequency multiplied by the Rate Prescale Value in program

mode 4. (If no pulses are received for 2 seconds, the rate value goes to zero.)

Control Keys

Down arrow key

Normal operating mode

When you press the Down Arrow key during normal operation, the ER-9 toggles the display of the Flow Total and the

Flow Rate. The letter Ron the left of the screen indicates that the Flow Rate is being displayed.

Programming mode

The Down Arrow key toggles the unit between the Total Display and the Rate Display. When the program input is active,

press the Down Arrow key to scroll through the menu items. After choosing a menu item for editing, press the Down

Arrow key again to set the value for the currently selected (flashing) digit.

Reset key

While the Total Value displays, press the Reset Rkey to reset the value to zero. The front panel Reset function works only

when Program Mode 7 is preset to enable.

When the program input is active (see “Wiring Instructions” on page 7), press the Reset Rkey to select a menu item

for editing.

Industrial Registers, Model ER-9 Digital Resettable Totalizer

Page 8 August 2018REG-UM-00836-EN-12

PROGRAMMING

MPORTANTI

You must connect terminals 1 and 5 together to enable the programming mode. After all programming is complete, remove the

connection between terminals 1 and 5 to prevent the unit from being reprogrammed by mistake.

To access the programming screens, press repeatedly until the Program Mode (1 through 7) you want displays on

the screen.

1. Once you select a program, press Rto either cause the left digit of that value to ash (scale factors modes 1, 4 & 6), or

to change the parameters for the other programming modes (Decimal Point Position and Totalizer Reset).

2. On program modes 1, 4 & 6, use Rand in combination to choose individual digits and change their value.

OTE:N On program modes 1, 4 & 6, you can advance to the next program mode only if a digit is not flashing. Press R

until the display stops flashing.

1.01.000

Mode 1: Totalizer Scaler multiplies the input pulses by this number (programmable from 0.0001 to 99.9999)

and displays the results as the totalizer value.

2. oFF

Mode 2: Totalizer Decimal Point sets the decimal point on the totalizer display from no decimal

(OFF) to 0.00000.

3. 1.000

Mode 3: Rate Scale Factor Decimal Point sets the decimal in Rate Scale Factor number, from no

decimal to 0.000.

4. 9999

Mode 4: Rate Scale Factor multiplies the input pulses by this number, which can be programmed

in conjunction with the Rate Decimal Point for a number from 0.001 to 9999.

5. oFF

Mode 5: Rate Decimal Point sets the decimal point on the Rate of Flow display from no decimal

(off) to 0.0000. You can program the display to have a dead zero (----0), for a 5-digit display with the

least significant digit always being 0.

6.0.9999

Mode 6: Pulse Output Scale Factor multiplies the input pulses by a number from 0.0001 to 0.9999

and sends them to output terminals 6 & 7.

7. on

Mode 7: Front Panel Reset Enable When set to ON, press Rto reset the totalizer to zero. When

set to OFF, the totalizer can only be reset through the remote reset input

(see “Wiring Instructions” on page 7).

8. on

Mode 8: Pulse Output Enable When set to ON, the solid-state relay output will pulse to

re-transmit input pulses. If set to OFF, it will not activate. Use the OFF setting to conserve battery

life if not using the output.

User Manual

Page 9August 2018 REG-UM-00836-EN-12

Totalizer Programming

Totalizer values can be expressed in any engineering unit of measure such as gallons, quarts, or liters. For each unit, a unique

scale factor must be programmed.

Totalizer scale factor

To determine the Totalizer Scale Factor (Program Mode 1), use the following formula:

Totalizer Scale Factor = 1/(Transmitter pulses per unit X Decimal Factor)

where:

Transmitter Pulses per Unit is the number from the chart at the right, or the literature for your particular transmitter/

meter combination. The chart is expressed in gallons and liters. If you wish to read in other units, use the appropriate

conversion factor.

Decimal Factor (from 1.0 to .001) determines the resolution of the reading. If you wish to read to the nearest 1/10 unit, the

Decimal Factor would be 0.1.

Example: You have a model 35 RCDL meter with a PFT-2 transmitter that has a pulse output of 126.7 pulses per gallon. You

wish to read the totalizer to the nearest tenth gallon.

1/(126.7 X 0.1) = 0.0789 (scale factor)

1. Set the Totalizer Scale Factor (Program Mode 1) to 0.0789.

2. Set the Totalizer Decimal Point Factor (Program Mode 2) to 0.0 (one decimal place).

Rate of Flow Programming

Rate of flow can be expressed in any engineering unit of measure for any time base such as gallons/minute, liters/second,

barrels/hour.

Rate scale factor

To determine the Rate Scale Factor (Program Mode 4), use the following formula:

Rate Scale Factor = (Seconds / Transmitter Pulses per Unit)

where:

Seconds is the number of seconds in the rate time unit. If you wish to read flow in units per minute, seconds would equal 60.

If you wish to read flow in units per hour, seconds would equal 3600.

Transmitter Pulses per Unit is the number from the chart to the right or the literature for your particular

transmitter/meter combination. The chart is expressed in gallons and liters. If you wish to read in other units, use

the appropriate conversion factor.

Before you program the Rate Scale Factor, you must set the Rate Decimal Point position (Program Mode 3). This decimal point

will correspond to the decimal in the Rate Scale Factor number.

Example: You have a model 35 RCDL meter with a PFT-2 transmitter that has a pulse output of 126.7 pulses per gallon. You

wish to read rate of flow in gallons per minute.

60 seconds /126.7 pulses per gallon = 60/126.7 = 0.473(rate scale factor)

1. Set the Rate Scale Factor Decimal Point (Program Mode 3) to X.XXX.

2. Set the Rate Scale Factor (Program Mode 4) to 0.473.

3. Since we are reading in whole gallons, set Rate Decimal Point (Program Mode 5) to o.

Industrial Registers, Model ER-9 Digital Resettable Totalizer

Page 10 August 2018REG-UM-00836-EN-12

Autres manuels pour ER-9

Table des matières

Autres manuels Badger Meter Instrument de mesure

Badger Meter

Badger Meter Recordall Series Manuel utilisateur

Badger Meter

Badger Meter Hedland EZ-View Manuel utilisateur

Badger Meter

Badger Meter Dynasonics TFX-5000 Manuel utilisateur

Badger Meter

Badger Meter Blancett B2800 Standard Manuel utilisateur

Badger Meter

Badger Meter Blancett 1100 Series Manuel utilisateur

Badger Meter

Badger Meter Dynasonics TFX-500w Manuel utilisateur

Badger Meter

Badger Meter Impeller Data Industrial 228PV Series Manuel utilisateur

Badger Meter

Badger Meter Blancett B2900 Manuel utilisateur

Badger Meter

Badger Meter Orion AL Series Manuel utilisateur

Badger Meter

Badger Meter Industrial Oval Gear Series Manuel utilisateur

Badger Meter

Badger Meter Blancett B290-901 Manuel utilisateur

Badger Meter

Badger Meter ORION Mobile Read Guide d'installation

Badger Meter

Badger Meter ORION Manuel utilisateur

Badger Meter

Badger Meter Data Industrial 3000 Series Manuel utilisateur

Badger Meter

Badger Meter FMS-3 Manuel utilisateur

Badger Meter

Badger Meter Orion 64989-002 Manuel utilisateur

Badger Meter

Badger Meter HR-LCD 4-20 Manuel utilisateur

Badger Meter

Badger Meter M5000 Manuel utilisateur

Badger Meter

Badger Meter M-series Manuel utilisateur

Badger Meter

Badger Meter Blancett B220-880 Manuel utilisateur

Badger Meter

Badger Meter Blancett B3100 Series Manuel de référence

Badger Meter

Badger Meter FC-5000 Manuel utilisateur

Badger Meter

Badger Meter LM-OG-P2 Advanced Manuel utilisateur

Badger Meter

Badger Meter Blancett B2800XP Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
