Configuration Guide for Aztech HW550–3G Router

Configuration Manual

Aztech HW550-3G

4-Port Wireless N Router plus HSPA Support for 3G Mobile Broadband

Configuration Guide for Aztech HW550–3G Router

Table of Contents

1. Manual Configuration –Internet Settings ........................................................................................3

2. Connecting to the Internet......................................................................................................................3

3. Wireless Configuration for optimum performance .......................................................................6

4. Router Firmware Upgrade....................................................................................................................... 7

5. Setting Administration Password for Router..................................................................................9

Configuration Guide for Aztech HW550–3G Router

1. Manual Configuration –Internet Settings

1.1 Connect an Ethernet Cable to your router’s WAN port and other end of the

cable to Etisalat ONT Port (Internet).

1.2 Connect the power cable to the router’s power jack and plug it in to the wall

socket.

2. Connecting to the Internet

To Connect to the Internet via the Web User Interface:

2.1 Open your Internet web browser, type http://192.168.2.1 in the address bar

and press enter. This opens the login authentication page

2.2 Type your Username and Password. Your default Username and Password is

admin/admin.

Configuration Guide for Aztech HW550–3G Router

2.3 Click the Wizard Tab, then Follow the step-by-step guide on how to setup the

router. Click next to continue.

2.4 Select the Language and Time zone from the drop down box then click next

to continue.

Configuration Guide for Aztech HW550–3G Router

2.5 Select the Internet Connection type as WAN and then click Next to Continue.

2.6 Choose the Connection Method as PPPoE and input your e-Life account

credentials from your e-Life card as indicated below and click next.

2.7 Click the check boxes to enable Wireless and SSID broadcast, input SSID &

Password of your choice for your Wi-Fi Network.

Configuration Guide for Aztech HW550–3G Router

2.8 Click Next and Apply the configuration to your router.

3. Wireless Configuration for optimum performance

3.1 Click on Advanced Mode and proceed to Wireless tab:

3.2 Set the following below under Wireless -> Settings:

i. Wireless Mode : 11b/g/n mixed mode

ii. Channel: Auto

3.3 Set the following below under Wireless -> Security:

Configuration Guide for Aztech HW550–3G Router

a. Security Mode as WPA / WPA2

b. WPA Algorithms as AES

c. Set password of your choice

d. WPS : Enable

3.4 Click Apply to save the security changes to the router.

NOTE: 1

Assign a complex password of your choice for your Wi-Fi Network to prevent

unauthorized internet access

4. Router Firmware Upgrade

NOTE: 2

Always use an Ethernet Cable Connection to your Router while performing Firmware

Upgrade.

4.1 Download the new firmware for your Aztech HW550-3G Router to your

connected computer.

Configuration Guide for Aztech HW550–3G Router

4.2 Click on Advanced Mode and proceed to System. Click on firmware to open

the firmware upgrade menu.

4.3 Browse to the firmware location on your computer by clicking the Browse

button on the router GUI, click Upgrade button to load the new firmware to

your router.

NOTE: 3

Do not power off or disconnect your router while Firmware Upgrade is in progress

4.4 Wait for the Firmware upgrade process to complete and Router web Page to

return. Verify the new firmware as 201.83.3-005 by clicking Advanced Mode

>> System.

Configuration Guide for Aztech HW550–3G Router

5. Setting Administration Password for Router

The router’s administrator password is used to prevent unauthorized persons from

accessing the web-based setup of your router and changing any of its settings.

NOTE: 4

It is a must to change the administrator password to avoid unwanted access and to

protect your router with a confidential password.

5.1 Go to Advanced Mode, Select System >> Password to input a password of

your choice.

NOTE: 5

Wireless network password that is used to connect devices to the network is different

from the router administration password.
