Aztech DSL305E Instructions d'utilisation

ADSL Ethernet Modem

Easy Start

Version 1.0

Contents

Introduction ....................................................... 2

Minimum System Requirements ........................... 2

Modem Package .................................................2

ADSL Ethernet Modem Overview .......................... 3

Step 1: Connecting the ADSL Ethernet Modem to

Your Computer/Notebook ......................... 4

Step 2: Configuring Your Ethernet Network Card ... 8

Step 3: Configuring Your Internet Browser ............ 11

Step 4: Connecting to the Internet ....................... 14

Diagnostic Test ................................................... 16

ADSL/WAN Status .............................................. 16

Firmware Upgrade .............................................. 17

Frequently Asked Questions ................................. 18

Technical Support ............................................... 20

• Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.

• This product is for use only in UL Listed computers.

Easy Start

Introduction

Thank you on your purchase of the ADSL Ethernet Modem! The Modem provides you with

a high-speed broadband Internet connection using your existing phone line that at the same

time allows you to make phone calls.

The ADSL Ethernet Modem can be connected to any computer/notebook with a 10/100

Base-T Ethernet Network card. This documentation assumes that your computer/notebook

already has an Ethernet Network card installed.

Minimum System Requirements

 Pentium®MMX 233MHz with Ethernet Network card (installed with TCP/IP Protocol)

 Operating system support:

Windows®: Windows® 98 / Windows® 98 Second Edition / Windows® Me /

Windows® XP / Windows® 2000

Macintosh®: OS 9.x and above

 Web Browser support:

Microsoft Internet® Explorer 4.0 (or later versions)

Netscape® Navigator 4.7 (or later versions)

Modem Package

¬ADSL Ethernet Modem

¯Telephone cable (RJ-11) 1°Power adapter (DC 12V) 2

®CAT-5 UTP Straight

Ethernet Network cable (RJ-45)

Easy Start

1 The telephone extension cable used for this Modem is a UL Listed Communication Circuit Accessory,

minimum 26AWG.

2 Different countries are bundled with different types of power adapter. The above illustration is only

a representative.

3 Depending on your country of purchase, your package may or may not come with a POTS Splitter.

The POTS Splitter is required if you are connecting a Telephone Set to the Ethernet Modem. Please

refer to Step 1.2 - Connecting to the ADSL Line for details. POTS-Splitter can also be purchased

from your dealer.

±POTS-Splitter3

(optional)

Easy Start

ADSL Ethernet Modem Overview

Front View

ÊETH/ACT

Lights up when the Ethernet Network cable is properly

connected from the Modem to the Ethernet Network Card.

Blinks when the ADSL is transmitting/receiving data.

ËDSL

Lights up when the ADSL connection is established.

Blinks when modem is trying to establish an ADSL

connection with your ADSL Service Provider.

ÌPOWER

Lights up when power is supplied to the Modem.

4To activate the reset function:

- Ensure that your Modem is powered on.

- Use a paper clip or a pencil tip to depress the reset button and release. At this point, the DSL

indicator will be off, followed by the ETH/ACT indicator. The reset is in progress.

- When the DSL indicator starts blinking, it means that the reset process is completed. The

default settings are now restored.

- ADSL line is established once the DSL indicator lights up.

ÊLINE

Telephone jack (RJ-11) to connect to your Telephone Wall

Socket (ADSL line).

ËRESET

To reset your Modem to factory default settings. (All

customised settings that you have saved will be lost!)

Please refer to the below footer4on how to activate the

reset function.

ÌETHERNET

10 / 100 Base-T Ethernet jack (RJ-45) to connect to your

Ethernet Network card.

ÍDC IN

To connect to your Power Outlet via the Power Adapter

that comes with your package.

Rear View

Easy Start

Step 1: Connecting the ADSL Ethernet Modem to

Your Computer/Notebook

Power off your Computer/Notebook or/and any connected devices before

connecting to the ADSL Ethernet Modem!

To connect the ADSL Ethernet Modem to your Computer/Notebook, you need to have an

Ethernet Port present on your Computer/Notebook.

(See the following note if you are not sure of how an Ethernet Port looks like).

Locating the Ethernet Port on your Computer/Notebook

The following are some tips to help you locate your Ethernet Port on your

Computer/Notebook. Alternatively, you may refer to the documentation that

comes with your Computer/Notebook.

Most Computers/Notebooks have labels describing the Ports. For Ethernet Port,

you will see either ETHERNET,ETH or RJ45 labelled near the Port.

If your Computer/Notebook does not have such descriptions, try the following.

-Picture A gives the illustration of an Ethernet Port. All Ethernet Ports have 8

conductors on it. Do not mistaken with the LINE Port (Picture B) that has only

6 conductors.

- An Ethernet Port is slightly bigger than a LINE Port.

A. ETHERNET: B. LINE:

Step 1.1 Connecting to the Ethernet

Back view of a computer

Ethernet Network cable (that comes

with your Modem package)

Ethernet Port

Back view of

the ADSL

Ethernet

Modem

Ethernet

Network Card

Easy Start

Step 1.2 Connecting to the ADSL Line

To connect the ADSL Ethernet Modem to the ADSL line, carried out Step 1.2(a).

To connect the ADSL Ethernet Modem to the ADSL line and a Telephone Set, carried out

Step 1.2(b).

(a) To connect to the ADSL line

Back view of the ADSL

Ethernet Modem

Telephone Wall

Socket

Telephone cable

(b) To connect to the ADSL line and Telephone Set

Telephone cable

Back view of the ADSL

Ethernet Modem

Telephone Wall

Socket

The POTS Splitter is a device that allows you to connect both your Telephone

cable and Telephone Set to the same Telephone Wall Socket. The device at the

same time helps to eliminate background noise on the telephone line, ensuring

the best possible phone performance.

Telephone Set

POTS Splitter

Connect the Telephone set to the

jack labelled TEL or PHONE and

the telephone cable to the jack

labelled LINE.

Easy Start

Step 1.3 Connecting to the Power Outlet

Connect the ADSL Ethernet Modem to the Power Outlet via the Power adapter (that comes

with your Modem package).

Connect the other end of the

Power Adapter to the Power

Outlet.

Back view of the ADSL

Ethernet Modem

If you have Telephone set(s)/Facsimile

machine connected to other Telephone

Wall Socket(s), you will need to plug

in a Micro-Filter to each of the

Telephone Wall Socket before

connecting to the Telephone set as

illustrated.

Like the POTS Splitter, Micro-Filter

helps to eliminate noise on the

telephone line when your Ethernet

Modem and Telephone set are both

sharing the same line. The only

difference is that the POTS Splitter

has two RJ-11 jacks whereas the

Micro-Filter has only one.

(Micro-Filter can be purchased from

your dealer).

Easy Start

Step 1.4 Checking Your Connections

Please check your connections before proceeding.

Step 1.5 Powering Up

-Power on the Power Outlet that the ADSL Ethernet Modem is connected to.

-Power on your Computer/Notebook.

Proceed to Step 2.

LINE

ETHERNET

12V DC

To your Power Outlet

To the Ethernet Port on your

Computer/Notebook

To your Telephone Wall

Socket (ADSL line)

Easy Start

2.1.1 For Windows®98 Second Edition / Windows®Me

iii Click the option Obtain an IP address

automatically and click OK to save

the settings.

Ensure that your Modem is powered on.

Restart your system.

Proceed to Step 3.

iFrom your Windows desktop, right-click on the Network Neighborhood icon. Select

Properties.

ii From the Configuration tab, select TCP/IP-> xxx where xxx refers to the model of your

Ethernet Network Card that is connected to the ADSL Ethernet Modem.

Click Properties.

Step 2: Configuring Your Ethernet Network Card

This documentation assumes that your computer/notebook is already installed with an

Ethernet Network card.

(This screen shot uses 3Com EtherLink

Ethernet card model as an example).

2.1 For PC users

Easy Start

ii Ensure that the field Connect Using indicates the model of your Ethernet Network Card

that is connected to your ADSL Ethernet Modem.

(This is important especially if you have more than one Local Area Connection icons displayed

at the Network and Dial-up Connections / Network Connections window. Ensure that you have

selected the correct one.)

Select Internet Protocol (TCP/IP) and click Properties.

iii Select the option Obtain an IP

address automatically and click OK.

Click OK again to close.

Ensure that your Modem is powered on.

Restart your system.

Proceed to Step 3.

2.1.2 For Windows®2000 / Windows®XP

iWindows® 2000:

a) From your Windows desktop, right-click on the icon My Network Places and

select Properties.

b) At the Network and Dial-up Connections window, right-click on the Local Area

Connection icon and select Properties.

Windows® XP:

(Instructions are based on default Start menu option)

a) From your Windows desktop, click Start >All Programs > Accessories >

Communications > Network Connections.

b) Right-click on the Local Area Connection icon that reflects the model of your

Ethernet Network Card that is connected to the ADSL Ethernet Modem and

click Properties.

(This screen shot uses 3Com EtherLink

Ethernet card model as an example).

Easy Start

2.2 For MAC users

2.2.1 For MAC OS 9.x

iClick Apple Menu > Control Panels > TCP/IP.

ii At the following display, ensure that your selections for Connect via and Configure are

as indicated.

iii Close the window to save. Proceed to Step 3.

2.2.2 For MAC OS X

iClick Apple Menu > System Preferences.

ii At Internet & Network row, click Network icon.

iii At the following display, ensure that your selections for Location, Show and Configure

(at the TCP/IP selection) are as indicated.

iv Click Apply Now to save. Close the window. Proceed to Step 3.

If you do not see this

selection, click the PPPoE tab.

Unselect the option, 'Connect

using PPPoE'. Repeat step

2.2.2 iii.

Autres manuels Aztech Modem

Aztech

Aztech MDP3880 Manuel utilisateur

Aztech

Aztech ADSL2/2+ Modem Manuel utilisateur

Aztech

Aztech 56K External Modem Fiche d'information produit

Aztech

Aztech UM3100 Manuel utilisateur

Aztech

Aztech DSL605E Instructions d'utilisation

Aztech

Aztech MSP3880W Series Manuel utilisateur

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech MR2800-W Manuel utilisateur

Aztech

Aztech DSL5018EN(1T1R) Instructions d'utilisation

Aztech

Aztech MDP3858A Series Manuel utilisateur

Aztech

Aztech HomePlug AV Wireless N Extender Manuel utilisateur

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech HomePlug AV with Simple Connect Button Manuel utilisateur

Aztech

Aztech ADSL USB Modem Instructions d'utilisation

Aztech

Aztech DSL600E(C) Manuel utilisateur

Aztech

Aztech 206U Manuel utilisateur

Aztech

Aztech DSL700P Manuel utilisateur

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech MR2800-W Manuel utilisateur

Aztech

Aztech FG7003GRV(AC) Manuel utilisateur

Aztech

Aztech HL109EP Instructions d'utilisation

Aztech

Aztech DSL Turbo 900 Package Manuel utilisateur

Aztech

Aztech DSL600E Manuel utilisateur

Aztech

Aztech 56K External Modem Fiche d'information produit

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
