Axesstel AXW-D800 Manuel utilisateur
AXW-D800 / AXW-D1900
CDMA 1xEVDO
Wireless Broadband Modem
User Manual
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 2 - Connecting the World Now
User ID and Password
You may need to enter the user ID and password in order to use the
1xEV-DO Modem
Please write User ID and Password for future need. Keep this manual in a
secure place.
User ID: ___________________________
Password: _________________________
Dial Number: _______________________
1x Data Service User ID and Password (optional)
In some cases, your service provider may provide you with a different user
ID and password for 1x data service access (153.6 Kbps max).
User ID: ____________________________
Password: __________________________
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 3 - Connecting the World Now
Table of Contents
Package Contents……………………………………………………. …... 4
Introduction…………………………………………………………………. 5
Features…………………………………………………………………….. 5
Safety Precaution………………………………………………………….. 6
Basic Installation…………………………………………………………… 6
Getting to know the EV-DO modem……………………………………… 7
Connection using Ethernet port…………………………………………... 8
Configuring Your PC………………………………………………………. 8
Configuring Ethernet Connection………………………………………… 11
Connection using USB port……………………………………………….. 13
USB Driver Installation (Part 1: Setup) ………………………………. 13
USB Driver Installation (Part 2: Preparation) ………………………… 14
USB Driver Installation (Part 3: Driver Installation)………………….. 15
Connection using USB port……………………………………………. 16
Disconnect USB connection…………………………………………… 19
Advanced Menu: Web Admin Tool…...………………………………….. 20
Troubleshooting……………………………………………………………. 25
Specification………………………………………………………………… 26
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 4 - Connecting the World Now
Package Contents
After opening the package, check to make sure that you have all the parts
shown below. If any piece is missing or broken, please call customer
service.
zOne Axesstel 1x-EVDO Wireless Broadband Modem
zTwo Antennas
zPower Adaptor (Input: AC 110~240V 50~60 Hz, Output: DC 9V 1A)
zAC Power Cable
zCAT-5 Ethernet cable
zUSB cable
zUSB Driver Installation CD
zQuick Guide or User Manual
CAUTION! Use only the provided power adaptor. Using other power
adaptor may damage the EV-DO modem.
Before you start
You must have an active account with the service provider in order to
make connection.
zConfigure your PC to obtain TCP/IP settings automatically from DHCP
server feature of EV-DO modem. Refer to “TCP/IP Settings” for more
information on how to set up TCP/IP settings on your PC.
zIn order to connect multiple PCs to EV-DO modem and share internet
connection, you will need an Ethernet Switch, a Hub, or a Router.
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 5 - Connecting the World Now
Introduction
Axesstel 1xEv-DO Broadband EV-DO modem allows users to "get
connected" to high speed data services with unprecedented ease.
Powered by the latest QUALCOMM MSM6500 processor, this wireless
broadband modem provides high speed data service through USB or
Ethernet interfaces at rates of up to 2.4Mbps download and 153.6 Kbps
upload. With RJ-45 Ethernet connection, the users can enjoy true plug
and play connection without driver installation.
Features
zCDMA 1xEV-DO data service with speed up to 2.4Mbps download and
153.6Kbps upload
zBackward compatible to CDMA2000 1xRTT Data service (153.6 Kbps
max) if available by the service provided.
zReceive Diversity (2 antennas) for enhanced RF performance
z4 LED indicators (Power, Signal Strength, Connection, and Ethernet)
zRJ-45 Ethernet and High Speed USB 1.1 data port
zWeb based Configuration Tool
zDesktop or Wall-Mountable
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 6 - Connecting the World Now
Safety Precaution
1. Avoid placing the unit in a dusty location, or near a source of gas or fire.
2. Do not shake, hit or drop the unit.
3. To clean the unit, use only a soft, dry cloth. The chemicals in alcohol,
benzine or acetone can damage the surface of the unit.
4. Do not twist or pull the cord out of the unit.
5. Do not disassemble the phone.
6. DO NOT use the power adapter if the power cord is damaged or the
unit has been dropped or damaged in any way.
7. Only use the power adaptor provided by Axesstel. Do not use the
Axesstel adapter for any other purpose.
8. Use only the antenna provided with the unit. Do not use the antenna
for any other purpose.
9. Do not use the unit near water, for example, near a bathtub, sink, wet
basement, or swimming pool.
NOTE: The input voltage and the shape of the plug on this phone may
vary from country to country.
Basic Installation
1. Connect the antennas on the connectors of each side of the unit.
2. Connect the EV-DO modem to computer using RJ-45 Ethernet Cable
(CAT 5) or USB cable.
3. Move the connection selector switch to USB or Ethernet depending on
which cable you are using.
4. Connect the power adaptor to the DC 9V socket of the EV-DO modem.
5. Plug the AC adaptor into an appropriate electrical wall outlet.
Wall mounting…
1. Mark two mounting holes on the wall.
2. Drill two holes at the marked locations.
3. Tighten the screws until the head is about 5mm from the wall.
4. Hang the unit on the screw using the two holes in the back.
5. Push the unit down until the unit is firmly locked into place.
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 7 - Connecting the World Now
Getting to know the EV-DO modem
Power Switch
Power Switch is located on the front side of the EV-DO modem.
Turn on the unit by moving switch to ON position (O). Turn off the unit by
moving switch to OFF position (|).
NOTE: When you turn on the EV-DO modem, it automatically searches for
service signal. When it successfully acquires service signal, the
signal LED turns to green, orange or red depending on signal
strength.
Connection Type Switch
Axesstel Wireless 1xEV-DO Modem lets you choose type of connection.
Connection Type Switch is located between Ethernet port and USB port.
Set this switch to Ethernet or USB depending on type of connection you
are using.
LED Indicators
LED Color Indicates
Green Power is on
Power Off Power is off
Green Excellent signal level
Orange Good signal level
Red Poor signal level
Signal
Off No signal or service is present
Green Connected to the CDMA network
Connect Off Not connected
Green PC connected to the modem by Ethernet
Blinking Indicates data activity
Ethernet
Off No PC connected to the modem by Ethernet
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 8 - Connecting the World Now
Connection using Ethernet port
1. Power off the unit before connecting the cables.
2. Connect CAT-5 Ethernet cable to Ethernet port of EV-DO Modem.
3. Connection type switch next to the Ethernet port should be set to
Ethernet. If not, slide the switch toward the Ethernet port.
4. Connect other end of Ethernet cable to the RJ-45 connector of
Ethernet network adapter or a network device.
5. Connect the Power Adapter to the power connector of EV-DO modem.
Plug the AC plug into a power outlet.
6. Turn the power ON, using the power switch next to the power jack.
The LED labeled “Power” light on.
7. Wait for few seconds for EV-DO modem to search for the service. The
LED labeled “Signal” turns to Red, Orange, or Green when signal is
acquired.
Configuring Your PC
The EV-DO modem’s Ethernet is configured with DHCP by default. This
means that IP address of your PC is automatically assigned by the EV-DO
modem.
If the PC’s cannot get IP address and cannot make connection to internet.
Check the TCP/IP setting of your “Local Area Connection”.
1. Click the Start button, select
Settings, and select Control
Panel.
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 9 - Connecting the World Now
2. Double click the Network
Connection icon.
3. Go to Local Area
Connection Properties.
CDMA 1xEV-DO Wireless Broadband Modem
AXW-D800 / AXW-D1900
- 10 - Connecting the World Now
4. Select the “Internet Protocol
(TCP/IP)”
1. If there is no TCP/IP line
listed, you will need to
install TCP/IP first.
5. Press the “Properties”
button.
6. Check “Obtain an IP
address automatically”
7. Check “Obtain DNS Server
address automatically”.
8. Click Ok to exit Properties.
9. If asked to re-start the PC,
click “YES”.
