Avenview C-COMP-VGA Manuel utilisateur

Component to VGA Converter with Audio

Model #: C-COMP-VGA

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no

representations or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the

right to make changes to specifications and product descriptions at any time without notice. No license, whether express, implied,

or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and

Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its

products of Avenview Inc. is strictly prohibited.

Table of Contents

Section 1: Getting Started ...................................................................................................................... 1

1.1 Important Safeguards ............................................................................................................ 1

1.2 Safety Instructions ................................................................................................................. 1

1.3 Regulatory Notices Federal Communications Commission (FCC).......................................... 2

1.4 Introduction ........................................................................................................................... 2

1.5 Package Contents................................................................................................................... 2

1.6 Before Installation.................................................................................................................. 2

1.7 Panel Description ................................................................................................................... 3

1.8 Installation.............................................................................................................................. 4

1.9 General Troubleshooting ....................................................................................................... 4

Section 2: Specifications......................................................................................................................... 5

www.avenview.com

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.

Damage, deterioration or malfunction resulting from:

Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product

modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.

Any damage of the product due to shipment.

Removal or installation of the product.

Causes external to the product, such as electric power fluctuation or failure.

Use of supplies or parts not meeting our specifications.

Normal wear and tear.

Any other causes which does not relate to a product defect.

Removal, installation, and set-up service charges.

1.2 Safety Instructions

The C-COMP-VGA, Avenview Component to VGA Converter with Audio has been tested for conformance to

safety regulations and requirements, and has been certified for international use. However, like all

electronic equipments, the C-COMP-VGA should be used with care. Read the following safety instructions

to protect yourself from possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.

Dismantling the housing or modifying the module may result in electrical shock or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing housing may expose you

to dangerous voltage or other hazards

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or

liquid falls or spills on to the housing, unplug the module immediately.

Have the module checked by a qualified service engineer before using it again.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device

before cleaning.

www.avenview.com

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

Avenview C-COMP-VGA Component to VGA Converter with Audio receives and switches two video and

stereo audio sources and displays one of them on a VGA monitor, plasma TV, LCD or a projector in high

resolution formats. The C-COMP-VGA accepts both VGA and Component inputs, and converts Component

inputs to VGA outputs. With only a press of a button, you can select between your PC and game console,

such as PS2, PS3, Wii, XBOX, XBOX3 and DVD Player.

-Automatic conversation between Component and VGA

-Supports PC video display resolutions of up to UXGA (1600x1200 @ 75Hz)

-Component supports 480p, 576p, and 720p

-Buffered VGA output for 60m (200 feet) long range transmission

-Stereo audio switch

1.5 Package Contents

Before you start the installation of the converter, please check the package contents.

-C-COMP-VGA x 1

-Power Adapter (+5VDC, 2A) x 1

-User Guide x 1

1.6 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an

injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or

high humidity.

Use the DC power adapter with correct specifications. If inappropriate power supply is used then

it may cause a fire.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

www.avenview.com

1.7 Panel Description

FRONT PANEL

1. 5V DC Power Jack

2. Power LED indicator

3. VGA/Component Switch Button

( : switch to Component source; : switch to VGA source)

4. Component Video Input

5. Component Stereo Input

REAR PANEL

6. PC Stereo Audio Phone Jack Input

7. PC Stereo Audio Phone Jack Output

8. VGA Input

9. VGA Output

www.avenview.com

1.8 Installation

To setup Avenview C-COMP-VGA follow these steps for connecting to a device:

1. Power off display source such as DVD Player, Set-top box

2. Connect your VGA source to VGA input and PC Audio to Audio phone jack input

3. Connect your Component source to Component input and Stereo Audio to Audio IN

4. Plug in 5V DC power cord to power jack of C-COMP-VGA

5. Power on C-COMP-VGA

6. Power on VGA and Component source devices

1.9 General Troubleshooting

Problem

Possible Solutions

No Image

Check if connection to the computer and the monitor are correct.

Ensure that display device supports 480p or 720p resolution

Screen Defects Appear

This product supports up to UXGA resolution.

Check the VGA and Component connection

Check the maximum resolution range of the graphics card.

Some LCD monitors DO NOT support interlaced video inputs such as 1080i or

480i. Adjust the source device such as XBOX or PS output resolution to

progressive 480p or 720p.

www.avenview.com

Section 2: Specifications

Item

Description

Video Bandwidth

400MHz for VGA and 70MHz for Component

Input Connector

1 x VGA

1 x Component

2 x Audio In

Output Connector

1 x VGA

1 x Audio Out

Power Supply

5VDC, 2Amp

Dimension (L x W x H)

5” x 3.7” x 1”

Environmental

Operation

0˚to 40˚C (32 ~ 104˚F)

Storage

-20˚C ~ 60˚C (-4 ~ 140˚F)

Humidity

20 ~ 90% RH (no condensation

www.avenview.com

Disclaimer

While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with

respect to the operation or use of Avenview hardware, software or other products and documentation described

herein, for any act or omission of Avenview concerning such products or this documentation, for any interruption of

service, loss or interruption of business, loss of anticipatory profits, or for punitive, incidental or consequential

damages in connection with the furnishing, performance, or use of the Avenview hardware, software, or other

products and documentation provided herein.

Avenview Inc. reserves the right to make changes without further notice to a product or system described herein to

improve reliability, function or design. With respect to Avenview products which this document relates, Avenview

disclaims all express or implied warranties regarding such products, including but not limited to, the implied

warranties of merchantability, fitness for a particular purpose, and non-infringement.
