Avaya P120 SMON User Guide

The products, specifications, and other technical information regarding the products contained

in this document are subject to change without notice. All information in this document is

believed to be accurate and reliable, but is presented without warranty of any kind, express or

implied, and users must take full responsibility for their application of any products specified in

this document. Avaya disclaims responsibility for errors which may appear in this document,

and it reserves the right, in its sole discretion and without notice, to make substitutions and

modifications in the products and practices described in this document.

Avaya™, Cajun™, P550™, LANstack™, CajunView™, and SMON™ are trademarks of

Avaya Inc.

ALL OTHER TRADEMARKS MENTIONED IN THIS DOCUMENT ARE PROPERTY OF THEIR

RESPECTIVE OWNERS.

Release 1.002

Avaya P120 SMON User Guide iii

Table of Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi

The Purpose of this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi

Who Should Use this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Organization of this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Chapter 1 — SMON Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

What is RMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

What is SMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Overview of SMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

SMON Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Filtering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Device SMON Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Switch Statistics Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Port Statistics Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

VLAN Statistics Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Alarms and Events Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Chapter 2 — Device SMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Accessing Device SMON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

The Device SMON User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Application Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Device SMON Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Dialog Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Status Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Working with Device SMON Tools . . . . . . . . . . . . . . . . . . . . . . . . . .13

Mouse Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Using Dialog Box Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Generating Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Chapter 3 — Switch Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Using Switch Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Gauges and Pie Charts in the Switch Statistics Window . . . . . .17

Traffic Graph in the Switch Statistics Window . . . . . . . . . . . . .18

iv Avaya P120 SMON User Guide

Table of Contents

Chapter 4 — Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Selecting Ports to Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Port Statistics Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

The Port Statistics Window . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Chapter 5 — VLAN Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using VLAN Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Selecting VLANs to Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

VLAN Statistics Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

VLAN Statistics Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Chapter 6 — Alarms and Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using Alarms and Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Alarms Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Alarms Table Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Tooltips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Editing Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Alarm Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Overview of the Alarm Wizard . . . . . . . . . . . . . . . . . . . . . . . . .32

Activating the Alarm Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Alarm Wizard Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Device Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Avaya P120 SMON User Guide v

Table of Contents

Appendix A — SMON Dialog Boxes. . . . . . . . . . . . . . . . . . . . . . . . . . 43

Using the General Options Dialog Box . . . . . . . . . . . . . . . . . . . . . . .43

Polling Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Report Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Using the Report Now Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . .46

Using the Auto Report Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . .46

Using the Switch Options Dialog Box . . . . . . . . . . . . . . . . . . . . . . . .48

Samples Per Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Samples To Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Logarithmic Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Level Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Using the Port/VLAN Options Dialog Box . . . . . . . . . . . . . . . . . . . .50

Items Per Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Using the Find Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Finding a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Finding a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Finding a LAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Using the Define Port Filter Dialog Box . . . . . . . . . . . . . . . . . . . . . .53

Using the Define VLAN Filter Dialog Box . . . . . . . . . . . . . . . . . . . . .55

Using the Define TopN Filter Dialog Box . . . . . . . . . . . . . . . . . . . . .57

Using the Find Top5 Peaks Dialog Box . . . . . . . . . . . . . . . . . . . . . . .58

Using the Sort Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Appendix B — Setting Up the SMON License . . . . . . . . . . . . . . . . . . 60

SMON Embedded License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Avaya P120 SMON User Guide vi

Preface

Welcome to Avaya P120 SMON. This chapter provides an introduction to

the structure and assumptions of the guide. It includes the following

sections:

•The Purpose of this Guide - A description of the intended

purpose of this guide.

•Who Should Use this Guide - A description of the intended

audience of this guide.

•Organization of the Guide - A brief description of the subjects

covered in each chapter of this guide.

The Purpose of this Guide

This guide contains the information needed to operate Avaya P120

SMON switch monitoring application efficiently and effectively.

The following table provides information about where to find

documentation about Enterprise SMON and Device SMON for other

devices.

Table 1. SMON Documentation

Application Document

Enterprise SMON Avaya MultiService SMON User Guide

SMON for Avaya M770 Devices Avaya M770 and M-MLS SMON User

Guide

SMON for Avaya P130 Devices Avaya P130 SMON User Guide

SMON for Avaya P330 Devices Avaya P330 SMON User Guide

SMON for Avaya P580/P882

Devices Avaya P580/P882 SMON User Guide

Avaya P120 SMON User Guide vii

Preface

Who Should Use this Guide

This guide is intended for use by network managers familiar with network

management and its fundamental concepts. It is assumed that the user

has the basic responsibility for monitoring Avaya Technologies’ intelligent

switching devices and the network traffic.

Organization of this Guide

This guide is structured to reflect the following conceptual divisions:

•Preface - This chapter describes the guide’s purpose, intended

audience, and organization.

•Overview - This chapter provides an overview of the RMON

standard and Avaya Inc’s SMON concepts and an introduction to

the SMON tools.

•Device SMON - This chapter describes how to launch

Avaya P120SMON and the Device SMON tools. It also describes the

Device SMON userinterface.

•Switch Statistics - This chapter describes the Switch Statistics

tool in detail, including sample screens and filtering options.

•Port Statistics - This chapter describes the Port Statistics tool in

detail, including sample screens and filtering options.

•VLAN Statistics - This chapter describes the VLAN Statistics tool

in detail, including sample screens and filtering options.

•Alarms and Events - This chapter describes the Alarms Table,

Alarms Wizard, and Device Event Log in detail, with instructions

on how to define and activate alarms.

The following Appendices are included at the end of this guide:

•Appendix A - Dialog boxes that appear in SMON tools.

•Appendix B - How to set up the SMON license so that SMON will

work with Avaya P120 Devices.

Avaya P120 SMON User Guide 1

1SMON Overview

This chapter describes SMON, Avaya Inc.’s switched network monitoring

system. This chapter includes the following s:

•What is RMON - A brief description of the RMON standard.

•What is SMON - A general description of SMON switch

monitoring technology.

•Overview of SMON - An introduction to SMON.

•Device SMON Tools - The Device SMON tools and how they

function.

What is RMON

RMON is the internationally recognized and approved standard for

detailed analysis of shared Ethernet and Token Ring media. It ensures

consistency in the monitoring and display of statistics between different

vendors.

RMON’s advanced remote networking capabilities provide the tools

needed to monitor and analyze the behavior of segments on a network.

In conjunction with an RMON agent, RMON gathers details and logical

information about network status, performance, and users running

applications on the network.

An RMON agent is a probe that collects information about segments,

hosts, and traffic, and sends it to a management station.

The network administrator uses software tools to view the information

collected by the RMON agent on the management station.

Avaya P120 SMON User Guide 2

SMON Overview

RMON has two levels:

• RMON I analyzes the MAC layer (Layer 2 in the OSI seven-layer

model).

• RMON II analyzes the upper layers (Layers 3 and above).

RMON is an industry standard that Avaya Inc. and other companies have

adopted in their network management applications. SMON takes the

RMON standard and extends it to the switching environment.

What is SMON

SMON is an extension of the RMON standard. SMON adds to the

monitoring capabilities of RMON in the following ways:

• It provides additional tools and features for monitoring in the

switch environment.

• It provides a global view of traffic flow in a network with multiple

switches.

Device SMON extends RMON I for the MAC layer, and AnyLayer SMON

extends RMON II for the network layer and above. SMON monitoring

collects and displays data in real-time.

Using SMON monitoring, you can get:

• A global view of traffic for all switches on the network.

• An overall view of traffic passing through a specific switch.

• Detailed data about the hosts transmitting packets through a

switch.

• An analysis of traffic passing through each port connected to a

switch.

• A view of traffic between various hosts connected to a switch.

Overview of SMON

SMON is an RMON-compliant network management suite that

implements the SMON extensions to RMON. SMON works with the other

components of Avaya MultiService Network Manager to provide a full

spectrum of in-depth monitoring of switch traffic and network

performance.

Chapter 1

3 Avaya P120 SMON User Guide

SMON consists of a software console application on a workstation and

remote monitoring probes in network devices that support SMON.

The SMON console communicates constantly with the SMON devices on

your network. The console uses the SNMP protocol to gather information

from the devices. SMON provides a suite of powerful graphic display tools

to view this information.

SMON gives you detailed analysis of the traffic flow on your switched

network, from a global view down to a specific host, and from total MAC

layer traffic down to a specific application protocol - all in real-time.

In addition, SMON allows you to set alarms based on traffic thresholds.

When an alarm is triggered, a trap can be sent to the device’s manager

and the event that triggered the alarm can be entered in SMON’s Event

Log.

SMON Devices

SMON provides monitoring capabilities for Avaya Inc’s network devices

that support the SMON extensions of the RMON standard.

Filtering Options

SMON tools provide different methods of filtering the information

displayed on the screen. These method include:

• Specific filtering

• TopN filtering

For information on how to use filters, refer to Appendix A, SMON Dialog

Boxes.

Specific

Filtering Specific filtering options provide the ability to specify the switches,

VLANs, or ports for which you want to view SMON information.

TopN

Filtering TopN filtering provides the ability to filter information based on the

amount of a particular type of traffic being monitored. When using TopN

filtering, specify the number of switches, VLANs, or ports for which you

want to view SMON information. Then select a statistic which will be

used as the basis for the filtering.

Using TopN filtering you can, for example, view information on only the

top 5 most active ports, or on the 8 switches generating the most error

traffic.

Autres manuels pour P120 SMON

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avaya Logiciel

Avaya

Avaya IP Office CTI Link Manuel

Avaya

Avaya Plantronics Blackwire C620 s Supplément

Avaya

Avaya Communication Manager Manuel de service

Avaya

Avaya M770 Manuel utilisateur

Avaya

Avaya Endpoint Access Control Agent Manuel utilisateur

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

Avaya

Avaya Compact Contact Center V5 Manuel de service

Avaya

Avaya 16-300272 Manuel utilisateur

Avaya

Avaya Customer Interaction Express 1.0 IVR-Editor Manuel utilisateur

Avaya

Avaya IP Office Phone Manager Manuel utilisateur

Avaya

Avaya C360 Manager Manuel utilisateur

Avaya

Avaya IP Office CTI Link Manuel utilisateur

Avaya

Avaya IP Office SMDR Manuel d'installation et d'exploitation

Avaya

Avaya IP Office Phone Manager Manuel utilisateur

Avaya

Avaya IP Office Phone Manager Manuel de l'opérateur

Avaya

Avaya Communication Manager IP DECT Mode d’emploi

Avaya

Avaya IP Office Phone Manager Supplément

Avaya

Avaya IP Office Phone Manager Manuel utilisateur

Avaya

Avaya CCM 3.1 Manuel utilisateur

Avaya

Avaya Interaction Center Manuel

Avaya

Avaya CCC Report Manager Manuel utilisateur

Avaya

Avaya Integrated Management Manuel technique

Avaya

Avaya Cajun P550 Manager 5.1 Manuel utilisateur

Avaya

Avaya IP Office Phone Manager Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur

Novell

Novell SP2 - S Mode d’emploi

Lexmark

Lexmark Apps Manuel de service
