Application Notes for Valcom One-Way IP Speakers with
Avaya IP Office –Issue 1.0
Abstract
These Application Notes describe the configuration steps required for the Valcom One-Way IP
Speaker devices to successfully interoperate with Avaya IP Office. The Valcom One-Way IP
Speakers are SIP-based devices that integrate with Avaya IP Office as a SIP endpoint.
Information in these Application Notes has been obtained through DevConnect compliance
testing and additional technical discussions. Testing was conducted via the DevConnect
Program at the Avaya Solution and Interoperability Test Lab.
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
2 of 17
Valcom-1Way-IPO
1. Introduction
These Application Notes describe the configuration steps required for the Valcom One-Way IP
Speakers to successfully interoperate with Avaya IP Office. The Valcom One-Way Speakers
enable voice access to a single zone of one-way paging over an IP-based LAN/WAN. The
Speakers are SIP-based devices that integrate with Avaya IP Office as a SIP endpoint. The
following Valcom One-Way IP Speaker was compliance tested:
VIP-120
When a call is placed to the Valcom One-Way IP Speaker, the device automatically answers the
call and provides one-way communication to the device.
1.1. Interoperability Compliance Testing
The interoperability compliance test plan included feature and serviceability test cases.
The feature testing covered SIP registration, basic calls, display verification, hold/reconnect,
conferences, transfers, media shuffling, and audio codec negotiation.
The serviceability testing focused on verifying the ability of the Valcom One-Way IP Speaker to
recover from adverse conditions, such as a disconnect and reconnect of the Ethernet cable to the
device, and Avaya IP Office reboots.
1.2. Support
Technical support for Valcom can be obtained through the following:
Phone: (800) VALCOM1
Email: [email protected]
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
3 of 17
Valcom-1Way-IPO
2. Reference Configuration
The Valcom One-Way IP Speaker was configured as a SIP endpoint that registered with Avaya
IP Office. When a call is placed to the Valcom One-Way IP Speaker, the device automatically
answers the call and provides one-way communication to the device.
Figure 1: Valcom One-Way IP Speaker with Avaya IP Office
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
4 of 17
Valcom-1Way-IPO
3. Equipment and Software Validated
The following equipment and software were used for the sample configuration provided:
Equipment
Software
Avaya IP Office 500
6.0 (8)
Avaya IP Office 500 Phone Expansion
Module Analog POTS 30 V2
6.0 (8)
Avaya IP Office Manager (Windows PC)
8.0 (8)
Avaya 5610SW IP Telephone (H.323)
2.9.1
Avaya 9620 IP Telephone (H.323)
3.002
Avaya 2420 Digital Telephone
R6 Firmware
Avaya 5420 Digital Phone
R6 Firmware
Avaya 6210 Analog Telephone
n/a
Valcom One-Way IP Speaker (VIP-120)
2.17
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
5 of 17
Valcom-1Way-IPO
4. Configure Avaya IP Office
This section describes the steps required to configure SIP extensions and users on IP Office.
IP Office is configured via the IP Office Manager program. Log into the IP Office Manager PC
and select Start Programs IP Office Manager to launch the Manager application.
Log into the Manager application using the appropriate credentials.
4.1. Administer Extensions
Create an extension for the Valcom One-Way IP Speaker. Right-click on Extension in the left
panel menu, and select New SIP Extension.
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
6 of 17
Valcom-1Way-IPO
On the Extn tab, enter a valid Base Extension.
On the VoIP tab, select G.711 ULAW 64K for Compression Mode and RFC2833 for DTMF
Support.
Click the OK button on the bottom of the screen (not shown).
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
7 of 17
Valcom-1Way-IPO
4.2. Administer Users
Create a user for the Valcom One-Way IP Speaker. Right-click User from the left panel and
select New.
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
8 of 17
Valcom-1Way-IPO
Under the User tab, enter the following values for the specified fields, and retain the default
values in the remaining fields.
Name Enter a desired name.
Full Name Enter a descriptive name.
Extension Enter the extension configured in Section 4.1.
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
9 of 17
Valcom-1Way-IPO
Under the Telephony Supervisor Settings tab, enter the following value for the specified
field, and retain the default values in the remaining fields.
Login Code Enter the desired login code.
Click the OK button on the bottom of the screen.
After making the changes, click File Save Configuration to push the changes to the IP Office
system and have them take effect. Changes will not take effect until this step is completed.
** NOTE ** This may cause a reboot of Avaya IP Office causing service disruption.
MJH; Reviewed:
SPOC 2/8/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
10 of 17
Valcom-1Way-IPO
5. Configure Valcom One-Way IP Speakers
This section provides the procedures for configuring Valcom One-Way IP Speakers. The
information shown is the minimum for configuring the Valcom device. Complete configuration
details may be found in the Valcom documentation listed in Section 9. The procedures include
the following areas:
Launch setup tool
Administer properties
Administer network
Administer SIP
5.1. Launch Setup Tool
From a PC running the Valcom VIP-102B IP Solutions Setup Tool application, select Start
All Programs Valcom IP Solutions VIP-102B IP Solutions Setup Tool. The VIP-102B
IP Solutions Setup Tool screen is displayed. Retain the default values and click OK to scan for
Valcom devices.
