Avalue Technology RITY153 Manuel utilisateur

Part No. E2017RT53A0R

RITY153

15” XGA Flat Touch Panel PC Intel® Atom™ Processor with

Intel® Valleyview SoC

Quick Reference Guide

1st Ed –19 February 2019

RITY153

2 RITY153 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

RITY153 Quick Reference Guide

Content

1. Getting Started ........................................................................................................4

1.1 Safety Precautions....................................................................................................4

1.2 Packing List...............................................................................................................4

1.3 System Specifications...............................................................................................5

1.4 System Overview......................................................................................................9

1.4.1 Right View................................................................................................................................ 9

1.4.2 Bottom View............................................................................................................................. 9

1.5 System Dimensions ................................................................................................10

1.6 Stand Dimensions...................................................................................................11

1.7 Panel + Stand Dimensions......................................................................................13

2. Hardware Configuration .......................................................................................15

2.1 RITY153 connector mapping ..................................................................................16

2.1.1 External Serial Port 1 connector (COM1).............................................................................. 16

2.1.2 External Serial Port 2 connector (COM2).............................................................................. 17

2.1.3 External Serial Port 3 connector (COM3).............................................................................. 18

2.1.4 VGA connector (VGA) ........................................................................................................... 18

2.2 Installing Battery(Optional).......................................................................................19

RITY153

4 RITY153 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x RITY Series Panel PC

1 x Power Adapter

1 x Power Cord

1 x Stand (option)

Quick Reference Guide

RITY153 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

Intel® Celeron® Apollo Lake Platform

CPU

Intel® Celeron® Processor N3350

Memory

Default 1 x 204-pin SODIMM Socket with 4GB DDR3L

Optional to 8GB

Adapter

DC 24V power input by Power Mini DIN 4P connector

System Fan

Fanless

Speaker

Speaker x2 on back

Camera

Supported optional (ACC-NBCAM-03R)

Operating System

Windows 10 64bit

MSR

Supported optional (E968XRT2200R)

2nd display

Supported 2nd Display by internal VGA(Pin header) +12V

Storage

Hard Disk Drive

2.5” HDD optional (Default 500G)

Solid State Drive

2.5” SSD optional

Other Storage

Device

mSATA by M.2 B key slot optional

Panel

LCD Panel

15” 1024 x 768 XGA CMI G150XGE-L04 C4 400nits (LVDS interface)

(Default)

15” 1024 x 768 XGA CMI G150XNE-L03 300nits (LVDS interface)

15” 1024 x 768 XGA G150XNE-E01 (eDP interface) (optional)

B/L

Inverter/Converter

Panel built in

Touch Screen

Resistive: 5W touch

Capacitive: 15” 2 points touch

Touch Controller

Resistive: PenMount6000

Capacitive: EETI control board

External I/O

Serial Port

4 x COM ports supported ( 2 x Pin header , 2 x Edge I/O )

All Pin 9 supported 5V/12V 1A max output, selected by BIOS.

COM1 & 2: RS232/422/485 selected in BIOS, RS422/485 by standard.

COM3 Pin header

COM4 Pin header

USB Port

10 x USB ports supported

Internal x6

1 x USB 2.0 for resistive touch controller

RITY153

6 RITY153 Quick Reference Guide

1 x USB 2.0 for 2nd display Touch

4 x USB 2.0 Pin header (PH5X2P)

External x4

4 x USB3.0 port (Dual stack)

Video Port

HDMI port

VGA(Ping header) supported 2nd display +12V

Audio Port

Pin header

LAN Port

2 x RJ45 connectors for Dual Giga LAN

Wireless LAN

Antenna

4G Antenna

Switch

Power switch on right side with cover

Indicator Light

Front panel right side with PWR/ HDD/ LAN

Expansion Slots

1 x M.2 B Key slot

Supported 4G/mSATA module

SIM card slot onboard

Battery

Support battery for 10 Minutes (optional)

Others

1 x RJ11 connector for cash drawer

Mechanical

Power Type

DC 19-24V power input

Power Connector

Type

4P Mini DIN

Wafer for Battery charger / Discharger

Dimension

362.1 x 290.1 x 51mm(Without stand)

Weight

TBD

Color

Black/White

Fanless

OS Support

Windows 10 64bit

Stand

Power Type

DC 24V power input

Built in adapter

Dimension

TBD

Weight

TBD

Color

Black / White

Reliability

EMI Test

CE/FCC/VCCI : Class B

Safety

All design for this project have to comply with UL / CB / CCC

Dust and Rain

Test

IP 65 for front panel, IP 41 for back

Vibration Test

Follow Avalue standard:

Ramdom Vibration Operation

Quick Reference Guide

RITY153 Quick Reference Guide

Reference IEC60068-2-64 Testing procedures

Test Fh : Vibration boardband random Test

1 Test PSD : 0.00454G²/Hz, 0.5 Grms for HDD

Test PSD : 0.00454G²/Hz, 1.5 Grms for mSATA

2 Test frequency : 5 ~ 500 Hz

3 Test axis : X,Y and Z axis

4 Test time : 30 minutes each axis

5 System condition : operation mode

6 Test curve

Sine Vibration Test

Reference IEC60068-2-6 Testing procedures

Test Fc : Vibration sinusoidal

1 Test Acceleration : 2G

2 Test frequency : 5 ~ 500 Hz

3 Sweep：1 Oct/ per one minute. (logarithmic)

4 Test axis : X,Y and Z axis

5 Test time :30 min. each axis

6 System condition : Non-Operating mode

7 Test curve

Package Vibration Test:

Reference IEC60068-2-64 Testing procedures

Test Fh : Vibration boardband random Test

1 Test PSD : 0.026G²/Hz , 2.16 Grms

2 Test frequency : 5~500 Hz

3 Test axis : X,Y and Z axis

4 Test time : 30 minutes each axis

5 Test curve

Mechanical Shock

Test

Follow Avalue standard:

With CF/SSD: 10Grms, IEC 60068-2-27, Half Sine, 11ms

Drop Test

Follow Avalue standard:

Package drop test

Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed

Test Ea : Drop Test

1 Test phase : One corner, three edges, six faces

2 Test high :

3 Package weight :

4 Test drawing

Operating

0°C ~ 40°C

RITY153

8 RITY153 Quick Reference Guide

Temperature

Operating

Humidity

12hrs operation dwell time at 40°C/80% Relative Humidity, Non-condensing

Storage

Temperature

0°C ~ 60°C

Note: Specifications are subject to change without notice.

Quick Reference Guide

RITY153 Quick Reference Guide

1.4 System Overview

1.4.1 Right View

1.4.2 Bottom View

Connectors

Label

Function

Note

COM1/2/3

External Serial Port 1/2 connector (For

RS-232/422/485)

External Serial Port 3 connector (For RS-232)

DB-9 male connector

VGA

VGA connector

C/D

Cash Drawer connector

USB

4 x USB 3.0 connector

1 x USB 2.0 connector

LAN

2 x RJ-45 Ethernet connector

HDMI

HDMI connector

DC-IN

DC Power-in connector

BATTERY

DC Power-out connector

USB

RITY153

10 RITY153 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Avalue Technology Écran tactile

Avalue Technology

Avalue Technology SID-21WR2 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1538 Manuel utilisateur

Avalue Technology

Avalue Technology PPC-1529 Manuel utilisateur

Avalue Technology

Avalue Technology SPC-1509 Manuel utilisateur

Avalue Technology

Avalue Technology SPC-1533 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-15WD510 Manuel utilisateur

Avalue Technology

Avalue Technology FPC-1707 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1209 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1503 Manuel utilisateur

Avalue Technology

Avalue Technology OFP-21W33 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1532-C1 Manuel utilisateur

Avalue Technology

Avalue Technology CCD-07WR2 Manuel utilisateur

Avalue Technology

Avalue Technology ARC-15W33 Manuel utilisateur

Avalue Technology

Avalue Technology SID-21W04 Manuel utilisateur

Avalue Technology

Avalue Technology VNS-10W01 Manuel utilisateur

Avalue Technology

Avalue Technology LPC-1909 Series Manuel utilisateur

Avalue Technology

Avalue Technology AID-173SBT Manuel utilisateur

Avalue Technology

Avalue Technology CCD-07W01 Manuel utilisateur

Avalue Technology

Avalue Technology MPC-21W3 Manuel utilisateur

Avalue Technology

Avalue Technology APC-2132 Manuel utilisateur

Avalue Technology

Avalue Technology APC-18W9 Manuel utilisateur

Avalue Technology

Avalue Technology MTP-1233 Comment utiliser

Avalue Technology

Avalue Technology FPC 17" SERIES Manuel utilisateur

Avalue Technology

Avalue Technology ARC-1709 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
