Avalue Technology PPC-2127 Manuel utilisateur

Part No. E2017P170A0R

PPC-2127

21.5" Intel® Atom™ Processor D2550 Fanless Plastic

Chassis Touch Panel PC

Quick Reference Guide

1st Ed –10 March 2016

PPC-2127

2 PPC-2127 Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

PPC-2127 Quick Reference Guide

Content

1. Getting Started............................................................................................................4

1.1 Safety Precautions ................................................................................................4

1.2 Packing List...........................................................................................................4

1.3 System Specifications ...........................................................................................5

1.4 System Overview...................................................................................................7

1.4.1 Front View.................................................................................................................................... 7

1.4.2 Rear View..................................................................................................................................... 7

1.5 System Dimensions...............................................................................................8

2. Hardware Configuration.............................................................................................9

2.1 PPC-2127 connector mapping.............................................................................10

2.1.1 External Serial port 1 connector (COM1)................................................................................... 10

2.2 Installing Hard Disk..............................................................................................11

PPC-2127

4 PPC-2127 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x PPC-2127 Panel PC

1 x CD/DVD-ROM contains the followings:

—Ethernet drivers and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—Wi-Fi drivers and utilities

—Touch controller drivers and utilities

—Chipset drivers and utilities

1 x packing set includes the followings:

—1 x power cord

—1 x AC/DC adapter 12V/7A 84W

Quick Reference Guide

PPC-2127 Quick Reference Guide

1.3 System Specifications

Component

Mother Board

EBM-CDV

CPU

Onboard Intel® Atom™ D2550 1.86GHz CPU

CPU Cooler (Type)

Fanless Heatsink

Memory

One 204-pin SODIMM Supports Up to 4GB DDR3 1066MHz SDRAM

Audio Codec

RealTek ALC892-GR Audio Codec

Power Supply

External power adapter

Adapter

FSP084-DMAA1

Speaker

8Ω 2W*2

Camera

Optional ACC-NBCAM-006 with Mic

Wireless LAN

Optional MiniPCIe ABOCOM WM5201

Operating System

Windows 7

Windows Embedded Standard 7

Windows Embedded POSReady 7

Windows 7 For Embedded System

Storage

Hard Disk Drive

2.5” HDD

Solid State Drive

2.5” SSD

Other Storage Device

Type I/II CF

Panel

LCD Panel

21.5" SXGA TFT LCD 1920*1080 AUO T215HVN01.0

B/L Inverter/Converter

LED Driving board ADB-2850-60 V2.4

Touch Screen

T216S-5RB005N-0A28R0-200PH

Touch Controller

EETI ETP-CP-S458XRU

External I/O

PS/2 KB & Mouse

1 x PS/2 KB & MS

Serial Port

2 x COM D-sub 9 pin (1 For Optinal)

USB Port

4 x USB2.0 (2 For Optional)

Video Port

1 x HDMI

Audio Port

1 x Line out (RealTek ALC892-GR)

LAN Port

2 x Intel® 82574L PCIe Gigabit Ethernet (1 For Optinal)

Wireless LAN Antenna

PCB Antenna 2.4/5.0GHz-IPEX Ø 1.13mm (Optinal)

Expansion Slots

1 x MiniPCIe Slot

Mechanical

Power Type

AT/ATX

Power Connector

Lockable DC plug

PPC-2127

6 PPC-2127 Quick Reference Guide

Type

Dimension

542mm x 382mm x 63mm

Weight

8.5 Kgs

Color

White + Gray

Fanless

Reliability

EMI Test

Class B

Safety

CE / FCC

Operating

Temperature

0°C ~ 40°C

Operating Humidity

10% to 95% @ 40°C, Non-condensing

Storage Temperature

-10°C ~ 50°C

Note: Specifications are subject to change without notice.

Quick Reference Guide

PPC-2127 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

Note: The programmable function keys are available to be programmed by the

user, and they are unable to work unless programmed.

1.4.2 Rear View

Connectors

Label

Function

Note

COM1

External Serial port 1 connector

DB-9 male connector

Compact Flash

CF Type I/II Socket with Ejector

USB/COM2

2 x USB2.0 connector

Serial port connector

DB-9 male connector

USB

2 x USB2.0 connector

DC IN

DC Power-in connector

HDD

HDD LED

LAN1/2

RJ-45 Ethernet connector 1/2

PWR

Power LED

RESET

Reset button

Speaker Out

Speaker Out audio jack

HDMI

HDMI connector

PPC-2127

8 PPC-2127 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

Quick Reference Guide

PPC-2127 Quick Reference Guide

2.Hardware

Configuration

Please refer to EBM-CDV Quick Installation Guide or User’s Manual.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

PPC-2127

10 PPC-2127 Quick Reference Guide

2.1 PPC-2127 connector mapping

2.1.1 External Serial port 1 connector (COM1)

Note:

COM1 RS-232/422/485 mode select by SW1 (RS-232 is

default).

RS-232

Signal

DCD

DSR

RXD

RTS

TXD

CTS

DTR

GND

RS-422

Signal

TX1-

RX1+

TX1+

RX1-

GND

RS-485

Signal

TX1-

TX1+

GND
