Avalon A10-TL Manuel utilisateur
A few simple steps to ensure
perfect water, every time.
English
English
www.avalonh2o.com
We’re Here to Help
Let’s Connect
Call Us:
1.800.256.0695
Email Us:
support@avalonh2o.com
sales@avalonh2o.com
Live Chat:
Monday-Thursday: 9 a.m.-5:30 p.m.
Friday: 9 a.m.-4:30 p.m.
@avalon_h2o Avalon Water Coolers Avalonh2o
Follow our social media accounts and stay up to
date on the latest Avalon news.
We are also available
for live video chat!
English
Use and Care Guide
MODELS: A10-TL • A10BLK
Registration
Please visit the website below to register your new water cooler within the first
30 days of purchase. Registration within the first 30 days will activate your one
year warranty.
www.avalonh2o.com/register-my-avalon-cooler
Please keep your model number, order number and purchase date
for future support. You can reach us at 1-800-256-0695.
Model Number
Order Number
Purchase Date
English
Contents
About Your Water Cooler
Meet Your Avalon Product
Part Names
Indicator Lights
Tech Specs
Getting Started
Unpacking
Operation Instructions
Cleaning
Rinsing, Cleaning and Draining
Cleaning
Troubleshooting
Safety
Warranty
1
2-3
4
5
7
8-10
12-14
15-16
18-19
21-22
24
English
1
Meet Your Avalon Product
About Your Water Cooler
English
UL Listed
We design &
manufacture with
your safety in mind
Child Safety Feature
Ensures safe hot
water flow for the
entire family
Attractive Design
Attractive stainless
steel design with 3
water spouts
Top Loading
Suitable for 3 or
5 gallon bottles
Custom Temperature
Piping hot,
cool or crisp
cold water
2
Part Names
8. Bottle Supporter
7. Cold Water
Push Button
6. Cool Water
Push Button
4. Hot Water
Push Button
5. Child Safety Lock
9. Hot Water Spout 11. Cold Water Spout
10. Cool Water Spout
12. Drip Tray
2. Heating Indicator Light
3. Cooling Indicator Light
1. Power Indicator Light
About Your Water Cooler
English
3
Part Names
15. Power Cord
16. Condenser
17. Drain Outlet
13. Cooling Switch 14. Heating Switch
About Your Water Cooler
English
4
Power Indicator Light
This light will remain on as long as the water cooler is plugged in to indicate that
the cooler is on.
Heating Indicator Light
This light will indicate when the water is heating. The light will remain on while the
water is heating and will turn o when it has reached the correct temperature of
185°F. As the water is dispensed the hot tank will refill and the water will heat. As
the water reheats this indicator light will turn on.
Cooling Indicator Light
This light will indicate when the water is cooling. The light will remain on while the
water is cooling and will turn o when it has reach the correct temperature of 47°F.
As the water is dispensed the cold tank will refill and the water will cool. As the
water cools this indicator light will turn on.
Indicator Lights
About Your Water Cooler
English
5
Tech Specs
Model A10-TL
Hot/Cold/Cool Output
Hot Water Capacity
Hot Tank Volume
Cold Water Capacity
Cold Tank Volume
Product Size
Packing Size
Net Weight/Gross Weight
Voltage/Frequency
Cooling Method
Heating Method
Heating Watts / Cooling Watts
Power Consumption
1.8L/min / 2.2L/min / 2.0L/min
4 L/H ( ≥ 185°F)
1.02 Liters
2 L/H ( ≤ 47°F)
3 Liters
13”(L)x12”(W)x40”(H)
16”(L)x15”(W)x42.5”(H)
34.17 lb /38.58 lb
115 V 60Hz
Compressor
Internal Element
420W / 100 W
520 W
Avalon Models A10-TL • A10BLK
About Your Water Cooler
English
