Automationdirect.com Productivity 2000 P2-16TR Manuel utilisateur

2000

Sales 800-633-0405 www.productivity2000.com 1

Document Name Edition/Revision Date

P2-16TR-DS 1st Ed. 8/15/2014

Output Specifications

Outputs per Module 16

Operating Voltage Range

(CE) 6.25-24 VDC (-15%/+20%)

6-240 VAC (-15%/+10%)

(UL) 6-27 VDC (-15%/+10%)

6-240 VAC (-10%/+10%)

Output Type Relay, form A (SPST)

AC Frequency 47 - 63 Hz

Maximum Output Current @ Temp 1A / point, 8A / common @ 60°C

for both AC and DC

Minimum Load Current 5mA @ 5VDC

Maximum Inrush Current 4A for 10ms

OFF to ON Response m10ms

ON to OFF Response m10ms

Status Indicators Logic Side (16 points)

Commons 2 Isolated (8 point / common)

External Fuses (user supplied) 8A Max

Warranty: Thirty-day money-back guarantee. Two-year limited replace-

ment. (See www.productivity2000.com for details).

Terminal Block sold separately, (see wiring options on page 3).

P2-16TR Relay Output

The P2-16TR Relay Output Module provides

sixteen 1A surge-protected outputs with

two isolated commons for use with the

Productivity2000 system.

Output Specifications ............................................... 1

Module Installation ................................................... 2

QR Code .................................................................. 2

Hot Swap Information............................................... 2

Wiring Options.......................................................... 3

Wiring Diagram and Schematic. ...............................3

Warning .................................................................... 4

Typical Relay Life..................................................... 4

Removable Terminal Block Specifications................4

General Specifications ............................................. 4

www.productivity2000.com Tech Support 770-844-4200

Important Hot-Swap Information

The Productivity2000 supports hot-swap! Individual

modules can be taken offline, removed, and replaced

while the rest of the system continues controlling your

process. Before attempting to use the hot-swap feature,

be sure to read the hot-swap topic in the programming

software’s help file or our online documentation at

AutomationDirect.com for details on how to plan your

installation for use of this powerful feature.

QR Code

Use any QR Code reader application to

display the module’s product insert.

1 Align

with slot

2rotate

to seated

position

Module Installation

WARNING: Do not apply field power until

the following steps are completed. See

hot-swapping procedure for

exceptions.

WIRE STRIP

LENGTH

WIRE STRIP

LENGTH

Step One: Align module

catch with base slot and

rotate module into

connector.

Locked Unlocked

Step Two: Pull top locking tab

toward module face. Click indi-

cates lock is

engaged.

Step Three: Attach field wiring using the removable

terminal block or ZIPLink wiring

system.

Caution: If possible, remove field power prior to

proceeding. If not, then EXTREME care MUST be taken

to prevent damage to the module, or even personal injury

due to a short circuit from the live terminal block.

6 - 27 VDC

6 - 120

VAC

50 - 60 Hz L

EXTERNAL

FUSE

RECOMMENDED

6 - 27 VDC

6 - 120

VAC

50 - 60 Hz

12345678910 11 12 1813 14 15 16 17

135 - 240 VAC

50 - 60 Hz

C1 and C2 Must

Be Linked Externally

for this V

oltage Range

12345678910111

813 14 15 16 17

6–27 VDC

6–120 VAC

135

–240 VAC

– 60 Hz

8A Max

User Supplied

External Fuse

Sales 800-633-0405 www.productivity2000.com 3

Wiring Diagram and Schematic

Wiring Options

1ZIPLink Connection System

Cable + ZIPLink Module = Complete System

ZIPLink pre-wired

terminal block cables

0.5m (1.6FT) cable

1.0m (3.3FT) cable

2.0m (6.6FT) cable

ZIPLink Modules

Feed through

ZL-P2-CBL18

ZL-P2-CBL18-1

ZL-P2-CBL18-2

ZL-RTB20

2Terminal Block with pigtail cable

1.0m (3.3FT) cable

2.0m (6.6FT) cable

ZL-P2-CBL18-1P

ZL-P2-CBL18-2P

3Screw Terminal Block only

P2-RTB

(Quantity 1)

4Spring Clamp Terminal Block only

P2-RTB-1

(Quantity 1)

www.productivity2000.com Tech Support 770-844-4200

Typical Relay Life

Voltage & Type of Load Operations at 1A Load Current

30VDC Resistive

30VDC Solenoid

120VAC Resistive

120VAC Solenoid

240VAC Resistive

240VAC Solenoid

100,000

WARNING: To minimize the risk of potential safety problems, you should follow all appli-

cable local and national codes that regulate the installation and operation of your equip-

ment. These codes vary from area to area and it is your responsibility to determine which

codes should be followed, and to verify that the equipment, installation, and operation are

in compliance with the latest revision of these codes.

Equipment damage or serious injury to personnel can result from the failure

to follow all applicable codes and standards. We do not guarantee the products

described in this publication are suitable for your particular application, nor do we

assume any responsibility for your product design, installation, or operation.

If you have any questions concerning the installation or operation of this equipment,

or if you need additional information, please call Technical Support at 770-844-4200.

This publication is based on information that was available at the time it was print-

ed. At AutomationDirect.com® we constantly strive to improve our products and services,

so we reserve the right to make changes to the products and/or publications at any time

without notice and without any obligation. This publication may also discuss features that

may not be available in certain revisions of the product.

General Specifications

Operating Temperature 0° to 60°C (32° to 140°F)

Storage Temperature -20° to 70°C (-4° to 158°F)

Humidity 5 to 95% (non-condensing)

Environmental Air No corrosive gases permitted

Vibration IEC60068-2-6 (Test Fc)

Shock IEC60068-2-27 (Test Ea)

Field to Logic Side Isolation 1800VAC applied for 1 second

Insulation Resistance >10MΩ@ 500VDC

Heat Dissipation 2.73W

Enclosure Type Open Equipment

Agency Approvals UL508 file E139594, Canada & USA

CE (EN61131-2*)

Module Keying to Backplane Electronic

Module Location Any I/O slot in a Productivity2000 System.

Field Wiring

Use ZIPLink Wiring System or removable terminal

block (not included). See “Wiring Options” on

page 3.

EU Directive

See the “EU Directive” topic in the

Productivity2000 Help File. Information can also be

obtained at: www.productivity2000.com

Connector Type (not included) 18 position removable terminal block

Weight 188g (6.64oz)

*Meets EMC and Safety requirements. See the D.O.C. for details.

Removable Terminal Block Specifications

Part Number P2-RTB P2-RTB-1

Number of

Positions 18 Screw Terminals 18 Spring Clamp Terminals

Wire Range

30-16 AWG (0.051 - 1.31 mm²)

Solid / Stranded Conductor

3/64 in. (1.2 mm) Insulation Maximum

1/4 in. (6-7 mm) Strip Length

28-16 AWG (0.081 - 1.31 mm²)

Solid / Stranded Conductor

3/64 in. (1.2 mm) Insulation Maximum

19/64 in. (7-8 mm) Strip Length

Conductors “USE COPPER CONDUCTORS, 75°C” or Equivalent.

Screw Driver

Width 1/8 inch (3.8 mm) Maximum

Screw Size M2 N/A

Screw Torque 2.5 lb·in (0.28 N·m) N/A
