Audio-Technica AT-LP60-USB, AT-LP120-USB & AT-LP240-USB Turntables

Software Guide

Audio-Technica USB Turntables

Contents

A note about software ....................................................................................................... 2

System requirements ........................................................................................................ 2

Installing Audacity software for Mac OSX and above ................................................... 3

Setting up your Mac (OSX and above) to work with your USB Turntable ................. 4

Additional Mac audio settings .......................................................................................... 6

Installing Audacity software for PC .................................................................................. 7

Setting up your PC (with Windows XP) to work with your USB Turntable ................ 8

Setting up your PC (with Windows Vista or Windows 7) to work with

your USB Turntable ...................................................................................................... 11

Setting up your PC to work with Audacity ...................................................................13

Recording albums with Audacity ...................................................................................15

To learn more about Audacity ........................................................................................ 15

A note about software

Your Audio-Technica AT-LP60-USB, AT-LP120-USB or AT-LP240-USB turntable is supplied

with Audacity recording software for your convenience. Please note that other third-party

recording software packages are also compatible with this turntable.

Audacity is free software, distributed under the GNU General Public License (GPL). More

information and open source code is on the included Audacity CD and on the Audacity

web site: http://audacity.sourceforge.net

System Requirements

PC or Mac with an available USB port (USB1.1 or higher)

CD-R or CD-RW writer for burning CDs & installation

Audacity requires:

Mac running OSX or above* or

PC running Windows (XP or above*)

*NOTE: For use with Windows 7, Windows Vista and Mac OSX 10.6: If the Audacity

recording software included with this turntable is version 1.2.6, please download Audacity

recording software for these operating systems from http://audacity.sourceforge.net.

Mac is a trademark of Apple Inc., registered in the U.S. and other countries.

Windows is a registered trademark of Microsoft Corporation in the U.S. and other countries.

Installing Audacity software for MAC OSX and above

Cables

Red to Red

White to White

5. Turn your computer on.

6. Insert the included Audacity CD in your Mac’s CD drive. Open the CD icon on your

desktop. Drag the installation folder for Audacity to your applications folder.

When the files have been copied, eject the CD.

USB cable (included)

RCA

USB

Included adapter cable (RCA

to 3.5 mm stereo male)

Typical connection for:

Speakers with 3.5 mm

stereo input

(using adapter cable)

1. Before installing software, assemble the turntable, following directions in the

included Owners Manual.

2. Plug the AC cord on your turntable into an AC power outlet.

3. Next, use the included USB cable to connect the turntable to your Mac’s USB port.

4. If you have external self-powered speakers, make certain they are plugged into

your computer’s audio input or into the line-out RCA plugs of the USB turntable, and

that the Phono/Line switch on your turntable is switched to Line. (Audacity offers

a software play-through feature that allows you to listen to the album through your

computer while recording, even if you don’t have external speakers.) If your computer

has a headphone output, you can choose to monitor your recording with headphones.

NOTE: On the AT-LP240-USB, the RCA cables are not permanently attached to the turn-

table; they plug into the RCA jacks on the back of the turntable. See the AT-LP240-USB

owner’s manual for cable connection instructions.

Typical connection for: Speakers with

RCA inputs

Setting up your MAC (OSX and above) to work with your USB Turntable

1. Open the Audacity program.

2. Select Preferences from the Audacity menu.

3. Select Audio I/O tab at the top left.

• Under Playback, Device, select Built-in Audio.

• Under Recording, Device, select USB Audio CODEC.

• Under Recording, Channels, select 2 (Stereo).

• Check the box marked Software Playthrough.

NOTE: The screens shown are from Audacity 1.2.6; later versions of Audacity

may change.

Setting up your MAC (OSX and above) to work with your USB Turntable

5. Next, from the main Audacity window, select the drop-down box (arrow pointing

down) next to the microphone at the right side of your screen.

• If you don’t see the drop-down box or the microphone pictured below, return

to Preferences Menu (see step 2, page 17). Select the Interface tab. Check

Enable Meter Toolbar. This will allow you to see the microphone with the

drop-down box on your main screen.

4. Next, select Quality tab at the top.

• Default Sample Rate: 44100 Hz.

• Default Sample Format: 16-bit.

• Real-time sample rate converter: Fast Sinc Interpolation.

• High-quality sample rate converter: High-quality Sinc Interpolation.

• Real-time dither: None.

• High-quality dither: Triangle.

• Select OK to save settings and exit Preferences menu.

6. Select Monitor Input from the drop-down menu. NOTE: You will need to select

this setting every time you launch Audacity. The other settings selected above will

be saved when you exit the program.

NOTE: The screens shown are from Audacity 1.2.6; later versions of Audacity

may change.

Additional MAC audio settings

We have set the Audacity playback and record settings. Now it’s time to set the

separate Macintosh audio playback and record settings.

1. Go to Applications > Utilities > then select and open Audio MIDI Setup.

2. In the Audio Midi window under the tab Audio Devices, select the following:

• Under System Settings, Default Input, select USB Audio CODEC.

• Under System Settings, Properties For, select USB Audio CODEC.

• Under Default output, select Built-in Audio, or Built-in Output.

• For System output, select Built-in Audio.

This will allow other programs (in addition to Audacity) to use your Mac’s internal sound

card for audio output.

NOTE: The screens shown are from Audacity 1.2.6; later versions of Audacity

may change.
