Audio Technica AT-LP60-USB Guide de démarrage rapide
Audio-Technica AT-LP60-USB & AT-LP120-USB Turntables
Software Guide
Pages 2-15
Tourne-disques USB Audio-Technica
Guide logiciel
Pages 16-21
Tocadiscos USB de Audio-Technica
Guía de software
Páginas 22-27
2
Audio-Technica USB Turntables
Contents
A note about software ....................................................................................................... 2
System requirements ........................................................................................................ 2
Installing Audacity software for Mac OSX and above ................................................... 3
Setting up your Mac (OSX and above) to work with your USB Turntable ................. 4
Additional Mac audio settings .......................................................................................... 6
Installing Audacity software for PC ..................................................................................7
Setting up your PC (with Windows XP) to work with your USB Turntable ................8
Setting up your PC (with Windows Vista) to work with your USB Turntable ..........11
Setting up your PC to work with Audacity ................................................................... 13
Recording albums with Audacity ................................................................................... 15
To learn more about Audacity ........................................................................................15
A note about software
Your Audio-Technica AT-LP60-USB or AT-LP120-USB turntable is supplied with Audacity
recording software for your convenience. Please note that other third-party recording
software packages are also compatible with this turntable.
Audacity is free software, distributed under the GNU General Public License (GPL). More
information and open source code is on the included Audacity CD and on the Audacity
web site: http://audacity.sourceforge.net
System Requirements
PC or Mac with an available USB port (USB1.1 or higher)
CD-R or CD-RW writer for burning CDs & installation
Audacity requires:
Mac running OSX or above or
PC running Windows (XP and above)
Mac is a trademark of Apple Inc., registered in the U.S. and other countries.
Windows is a registered trademark of Microsoft Corporation in the U.S. and other countries.
3
Installing Audacity software for MAC OSX and above
5. Turn your computer on.
6. Insert the included Audacity CD in your Mac’s CD drive. Open the CD icon on your
desktop. Drag the installation folder for Audacity to your applications folder.
When the files have been copied, eject the CD.
USB cable (included)
RCA
USB AC
Included adapter cable (RCA
to 3.5 mm stereo male)
Typical connection for: Speakers with
RCA inputs
Speakers with 3.5 mm
stereo input
(using
adapter cable)
1. Before installing software, assemble the turntable, following directions in the
included Owners Manual.
2. Plug the AC cord on your turntable into an AC power outlet.
3. Next, use the included USB cable to connect the turntable to your Mac’s USB port.
4. If you have external self-powered speakers, make certain they are plugged into
your computer’s audio input or into the line-out RCA plugs of the USB turntable, and
that the Phono/Line switch on your turntable is switched to Line. (Audacity offers
a software play-through feature that allows you to listen to the album through your
computer while recording, even if you don’t have external speakers.) If your computer
has a headphone output, you can choose to monitor your recording with headphones.
Cables
Red to Red
White to White
4
Setting up your MAC (OSX and above) to work with your USB Turntable
1. Open the Audacity program.
2. Select Preferences from the Audacity menu.
3. Select Audio I/O tab at the top left.
• Under Playback, Device, select Built-in Audio.
• Under Recording, Device, select USB Audio CODEC.
• Under Recording, Channels, select 2 (Stereo).
• Check the box marked Software Playthrough.
5
Setting up your MAC (OSX and above) to work with your USB Turntable
5. Next, from the main Audacity window, select the drop-down box (arrow pointing
down) next to the microphone at the right side of your screen.
• If you don’t see the drop-down box or the microphone pictured below, return
to Preferences Menu (see step 2, page 17). Select the Interface tab. Check
Enable Meter Toolbar. This will allow you to see the microphone with the
drop-down box on your main screen.
4. Next, select Quality tab at the top.
• Default Sample Rate: 44100 Hz.
• Default Sample Format: 16-bit.
• Real-time sample rate converter: Fast Sinc Interpolation.
• High-quality sample rate converter: High-quality Sinc Interpolation.
• Real-time dither: None.
• High-quality dither: Triangle.
• Select OK to save settings and exit Preferences menu.
6. Select Monitor Input from the drop-down menu. NOTE: You will need to select
this setting every time you launch Audacity. The other settings selected above will
be saved when you exit the program.
6
Additional MAC audio settings
We have set the Audacity playback and record settings. Now it’s time to set the
separate Macintosh audio playback and record settings.
1. Go to Applications > Utilities > then select and open Audio MIDI Setup.
2. In the Audio Midi window under the tab Audio Devices, select the following:
• Under System Settings, Default Input, select USB Audio CODEC.
• Under System Settings, Properties For, select USB Audio CODEC.
• Under Default output, select Built-in Audio, or Built-in Output.
• For System output, select Built-in Audio.
This will allow other programs (in addition to Audacity) to use your Mac’s internal sound
card for audio output.
7
Installing Audacity software for PC
5. Turn your computer on.
6. Insert the included Audacity CD. An Audacity window will appear. Click Audacity
Setup icon to install. Follow the directions on the pop-up windows to install
the software.
7. Re-start your computer.
USB cable (included)
RCA
USB AC
Included adapter cable (RCA
to 3.5 mm stereo male)
Typical connection for: Speakers with
RCA inputs
Speakers with 3.5 mm
stereo input
(using
adapter cable)
1. Before installing software, assemble the turntable, following directions in the
included Owners Manual.
2. Plug the AC cord on your turntable into an AC power outlet.
3. Next, use the included USB cable to connect the turntable to your PC’s USB port.
4. If you have external self-powered speakers, make certain they are plugged into
your computer’s audio input or into the line-out RCA plugs of the USB turntable, and
that the Phono/Line switch on your turntable is switched to Line. (Audacity offers
a software play-through feature that allows you to listen to the album through your
computer while recording, even if you don’t have external speakers.) If your computer
has a headphone output, you can choose to monitor your recording with headphones.
Cables
Red to Red
White to White
8
Setting up your PC (with Windows XP) to work with your USB Turntable
1. Close programs operating on your computer.
2. Start menu > Control Panel > Sounds and Audio Devices
• Begin at your Start menu. Select Control Panel.
• Select (double-click) Sounds and Audio Devices.
9
4. Select the Voice tab.
• In the Voice playback area of the window, select your computer’s internal
sound card (not USB Audio CODEC; not Microsoft Sound Mapper).
• In the Voice recording area of the window, select USB Audio CODEC. Click Apply.
NOTE: If the “USB Audio CODEC” option does not appear, check the USB
cable to ensure it is properly connected to the USB port.
3. The following screen will pop up:
10
Setting up your PC (with Windows XP) to work with your USB Turntable
5. Next, select the Audio tab.
• In the Sound playback area of the window, select your computer’s internal
sound card.
• In the Sound recording area of the window, select USB Audio CODEC.
• Check the following box: Use only default devices.
• Click Apply; then click OK.
