TH147 and TH148LE 400-147-010-C 27/11/06 4/4
nTo access the configuration menu, press the backlight button
for 3 seconds.
oTo go to the next parameter (menu item), briefly press the
backlight button.
pTo modify a parameter, press .
qRepeat steps 2 and 3 if necessary.
rPress the backlight button for 3 seconds to exit the configura-
tion menu.
Power supply: 2 AA batteries
Maximum load: 1 A @ 24 Vca per output
Unoccupied load: 12 VCC / ± 10% / 20 mA
Setpoint range (heating): 5 to 28°C (41 to 82°F)
Setpoint range (cooling): 15 to 35°C (59 to 95°F)
Display range: -10 to 50°C (14 to 122°F)
Storage temperature: -20 to 50°C (-2 to 122°F)
Temperature display resolution: 0.5°C (1°F)
Accuracy: ± 0.5°C (1°F)
Cycle length: 10, 12, 15, 20 or 30 min. (programmable)
Compressor short-cycle protection (minimum off time): 5 minutes
Dimensions: 127 mm x 75 mm x 28 mm (5 in. x 3 in. x 1 in.)
Aube warrants this product, excluding battery, to be free from
defects in the workmanship or materials, under normal use and ser-
vice, for a period of one (1) year from the date of purchase by the
consumer. If at any time during the warranty period the product is
determined to be defective or malfunctions, Aube shall repair or
replace it (at Aube's option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to
the place from which you purchased it, or
(ii) contact Aube. Aube will make the determination whether the
product should be returned, or whether a replacement product
can be sent to you.
This warranty does not cover removal or reinstallation costs. This
warranty shall not apply if it is shown by Aube that the defect or mal-
function was caused by damage which occurred while the product
was in the possession of a consumer.
Aube's sole responsibility shall be to repair or replace the product
within the terms stated above. AUBE SHALL NOT BE LIABLE FOR
ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY INCI-
DENTAL OR CONSEQUENTIAL DAMAGES RESULTING,
DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY WAR-
RANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF
THIS PRODUCT. Some provinces and states do not allow the
exclusion or limitation of incidental or consequential damages, so
this limitation may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY HONEY-
WELL MAKES ON THIS PRODUCT. THE DURATION OF ANY
IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE, IS HEREBY LIMITED TO THE ONE-YEAR DURATION OF
THIS WARRANTY. Some provinces and states do not allow limita-
tions on how long an implied warranty lasts, so the above limitation
may not apply to you.
This warranty gives you specific legal rights, and you may have
other rights which vary from province or state to another.
For any questions regarding the product installation, operation or
warranty, contact us at:
705 Montrichard
Saint-Jean-sur-Richelieu, Quebec
J2X 5K8
Canada
Tel.: (450) 358-4600
Toll-free: 1-800-831-AUBE
Fax: (450) 358-4650
Email: aube.service@honeywell.com
For more information on our products, visit us at
www.aubetech.com
4. Configuration Menu
DISPLAY DESCRIPTION DEFAULT OPTIONS
Temperature display °C °C or °F
Unoccupied mode setpoint - heat-
ing (TH148LE only) 1, 2 10°C
(50°F)
5°C to 28°C
(41°F to 82°F)
Unoccupied mode setpoint - cool-
ing (TH148LE only) 1, 2 35°C
(95°F)
15°C to 35°C
(59°F to 95°F)
Heating cycles per hour 242, 3, 4, 5 or 6 3
Cooling cycles per hour 242, 3, 4, 5 or 6 4
1To enable the Unoccupied mode, see section 2.4.
2Use the system mode selector to switch the display between the heating parame-
ter and the cooling parameter.
3For optimal heating control, use the setting that matches your system as follows:
2=30 min (steam, gravity), 3=20 min (hot water, 90%+ high-efficiency furnace),
4=15 min (gas or oil), 5=12 min (alternate setting for gas or oil), 6=10 min (electric).
4The corresponding cycle lengths are: 2=30 min., 3=20 min., 4=15 min., 5=12 min.,
6=10 min.
5. Technical Specifications
6. Warranty
7. Service
