TORQUE CHART

This chart shows the correlation

between pump gauge psi reading

and torque output for your Rapid-Torc

RTX-2 hydraulic torque wrench.

PSI FT.LB.

1500 257

1600 274

1800 308

2000 342

2200 376

2400 410

2600 445

2800 479

3000 513

3200 547

3400 581

3600 616

3800 650

4000 684

4200 718

4400 752

4600 787

4800 821

5000 855

5200 889

5400 923

5600 958

PSI FT.LB.

5800 992

6000 1026

6200 1060

6400 1094

6600 11 2 9

6800 11 6 3

7000 119 7

7200 1231

7400 1265

760 0 1300

7800 1334

8000 1368

8200 1402

8400 1436

8600 1471

8800 1505

9000 1539

9200 1573

9400 1607

9600 1642

9800 1676

10000 1710

BAR NM

104 348

110 371

124 417

138 464

152 510

165 556

179 603

193 649

207 696

220 742

234 788

248 835

262 881

276 927

290 974

303 1020

317 1066

331 111 3

345 11 5 9

358 1206

372 1252

386 1298

BAR NM

400 1345

414 1391

427 1437

441 1484

455 1530

468 1577

482 1623

496 1669

510 1716

524 1762

538 1808

552 1855

565 1901

579 1947

593 1994

607 2040

620 2087

634 2133

648 2179

662 2226

676 2272

690 2318

Set the pressure on the pump that

corresponds to the torque value.

1Find the closest torque value for

your application, either in ft-lbs

or in Nm.

FOOT-POUNDS NEWTON-METERS

The above torque values are only applicable when using a calibrated RTX-2 hydraulic torque wrench powered by a 10,000 psi pump

ﬁtted with a calibrated class 1 gauge.

RT-PTCen-RTX-2 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised October 2014

QUICK SETUP

GUIDE

Setting up your hydraulic torque wrench for use is easy.

Please read the included user manual and safety instruc-

tion booklet for additional guidelines.

FOUR BASIC STEPS TO OPERATE YOUR RTX-2

Scan the code to see a brief overview video on how to use the document or go to

rapidtorc.com/torque_setup

RT-PTCen-RTX-2 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised September 2014

Wear personal protec-

tive equipment, such as

eyeglasses and steel-toe

shoes.

SET PRESSURE

Make sure the hoses are

free of any defects. The

couplers are on pump

and the tool should be

securely connected.

Place tool on at surface.

Turn pump on. Cycle the

tool. Press the “ON’ but-

ton on the remote, hold

until tool clicks. Release,

wait for the tool to click.

Repeat the cycle. Ensure

there is no leak.

Use the torque conver-

sion chart to set the psi

for the torque you need.

Press the remote’s “ON”

button and slowly turn

the pressure regulator

clockwise to reach the

right pressure.

CYCLE YOUR TOOL

CONNECT HOSES

WEAR PPE
