User Manual
CS-74E
Read this guide thoroughly and follow the installation and operation
procedures carefully in order to prevent any damage to the unit and/or
any devices that connect to it.
This package contains:
M1 CS-74E Four Port KVM Switch
M4 CS Custom KVM Cables
M1 Console Connector Cable
M1 User Manual
If anything is damaged or missing, contact your dealer.
© Copyright 2003 ATEN®International Co., Ltd.
Manual Part No. PAPE-1233-100
Printed in Taiwan 07/2003
All brand names and trademarks are the registered property of their respective owners.
2003-07-02
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy, and if not installed and
used in accordance with the instruction manual, may cause
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
MReorient or relocate the receiving antenna;
MIncrease the separation between the equipment and
receiver;
MConnect the equipment into an outlet on a circuit different
from that which the receiver is connected;
MConsult the dealer or an experienced radio/television
technician for help.
2003-07-02
Overview
The CS-74E KVM (Keyboard, Video, Mouse), Switch is a
control unit that allows acess to up to four computers from a
single console (keyboard, monitor, and mouse). With its custom
designed connectors, the CS-74E significantly reduces the
number of ports required for a 4 port KVM switch.
The special connector design, featuring a custom SPDB-15
male connector for the keyboard, video, and mouse, provides
several advantages over standard KVM switch
implementations: 1) increased reliability; 2) a handsome,
space-saving, vertical-standing, modern appearance; and
3) neater, more efficient, cabling that eliminates the usual
tangled cable mess.
Setup is fast and easy; plugging cables into their appropriate
ports is all that is entailed. There is no software to configure; no
need to get involved in complex installation routines; and no
need to be concerned with incompatibility problems. Since the
CS-74E intercepts keyboard and mouse input directly, it works
on any hardware platform and with all operating systems.
The CS-74E provides two convenient computer access
methods: 1) switching the KVM focus to a computer by
pressing one of the push button port selection switches located
on the unit’s front panel; and 2) switching to the target computer
by entering hotkey combinations from the keyboard.
There is no better way to save time and money than with an
CS-74E installation. By allowing a single console to manage all
of the computers, the CS-74E eliminates the expense of
purchasing a separate keyboard, monitor, and mouse for each
one. Additionally, it saves the extra space and energy costs
that they would require, and eliminates the inconvenience and
wasted effort involved in constantly having to move from one
computer to another.
- 1 -
2003-07-02
Features
MCompact vertical-standing design
MCustom connector layout requires only 5 ports - 4 SPDB-15
female connectors for connecting to the computers - plus a
single, integrated, SPDB-15 male connector for the
keyboard, video, and mouse console
MEasy to install - no software required - connecting cables to
the computers is all it takes
MEasy to operate - computer selection via selection switches
or hotkeys
MPower on detection - automatically switches to the first
powered on port
MAuto scan function to monitor computer operation
MLED display for easy status monitoring
MHot pluggable - add or remove computers without powering
down the switch
MCaps Lock, Num Lock, and Scroll Lock states are saved and
restored when switching
MKeyboard and mouse emulation for error free computer
booting
MSupports Microsoft IntelliMouse and the scrolling wheel on
most mice
MSuperior video quality - up to 2048 x 1536; DDC2B
MNon-powered
MSaves Time, Space, Power, and Equipment Costs
- 2 -
2003-07-02
System Requirements
Console
MA VGA, SVGA, or Multisync monitor capable of the highest
resolution that you will be using on any computer in the
installation
MA PS/2 style keyboard
MA PS/2 style mouse
Computers
The following equipment must be installed on each computer
that is to be connected to the system:
MA VGA, SVGA or Multisync port.
MA PS/2 Style keyboard port.
MA PS/2 Style mouse port.
Cables
Only CS Custom cable sets specifically designed to work with
this switch may be used. One Console Connector Cable, as
well as two 1.2 m and two 1.8 m KVM cable sets are provided
with this package.
KVM cable sets are also available in 3, and 6 meter lengths. If
you need additional cables, contact your dealer.
Length CS Part Number
1.2 m 2L-5201P
1.8 m 2L-5202P
3.0 m 2L-5203P
6.0 m 2L-5206P
- 3 -
2003-07-02
Components
Front View:
1. Port Selection Switches
MPress a switch to give the KVM focus to the system
attached to its corresponding port.
MPressing Buttons 1 and 2 simultaneously starts Auto
Scan Mode (see p. 9).
MWhile in Auto Scan Mode, pressing any button exits Auto
Scan Mode and switches the KVM focus to its
corresponding port.
2. Port LEDs
The Port LEDs are built into the Port Selection Switches. A lit
LED indicates that its corresponding Port is the one that has
the KVM focus.
Depending on the Port’s status, the LED may flash
according to a specific pattern (see the table on p. 11 for
details).
- 4 -
2
1
2003-07-02
Rear
1. Power Jack
The power adapter cable plugs in here.
Note: The CS-74E does not require external power. Use of
a power adapter is optional, and requires a separate
purchase.
2. Console Port Connector*
The Console Adapter Cable plugs in here.
3. CPU Port Connectors*
The KVM cables that connect the unit to the mouse,
keyboard, and video ports on the computers you are
connecting up can plug into any available port.
*The shape of the 15-pin CPU and Console port connectors
has been specifically modified so that only cables designed to
work with this switch can plug in (see the Cables section on
p. 3 for details).
- 5 -
23
1
2003-07-02
Installation
Refer to the diagrams on p. 7 as you do the following:
1. Plug the Console Adapter Cable into the Console Port
Connector on the rear panel of the CS-74E.
2. Plug your keyboard, monitor and mouse into their respective
connectors on the Console Adapter Cable. The connectors
are color coded and marked with an approprieate icon for
easy identification.
3. Use the custom KVM cables (described in the Cables
section on p. 3), to connect the CS-74E CPU Ports to the
monitor, keyboard and mouse ports of the computers you
are installing.
4. If you choose to use external power, plug the power adapter
into an AC power source, then plug the power adapter cable
into the unit’s Power Jack.
Note: The power adapter should be DC9V with the inside
positive and the outside negative:
5. Turn on the power to the computers.
Note: The CS-74E’s default is to link to the first computer
you turn on.
- 6 -
1. Make sure that power to all the devices you will
be connecting up have been turned off. You
must unplug the power cords of any computers
that have the Keyboard Power On function.
2. To prevent damage to your installation due to
ground potential difference, make sure that all
devices on the installation are properly grounded.
2003-07-02
- 7 -
1
2
4
3
2
3
2003-07-02
Operation
Manual Port Selection
With Manual Port Selection you simply press the appropriate
Port Selection switch on the unit’s front panel to give the KVM
focus to its corresponding port. The Port LED lights to indicate
that its port has the KVM focus.
Hotkey Port Selection
Hotkey port selection allows you to directly access a computer
from the keyboard, instead of having to manually switch to it
with the Port Selection button. The CS-74E provides three
Hotkey navigation features:
MSelecting the Active Port
MAuto Scan Mode
MSkip Mode
Invoking Hotkey Mode:
All Hotkey operations begin by invoking Hotkey Mode. Invoking
Hotkey Mode takes three steps: 1) Press and hold down the
Num Lock key; 2) Press and release the asterisk key or the
minus key; 3) Release the Num Lock key:
[Num Lock] + [*];
or:
[Num Lock] + [-];
Note: The asterisk or minus key must be released within one
half second, otherwise Hotkey invocation is canceled
and it has no effect.
- 8 -
2003-07-02
