ATEN CN-6000 Manuel utilisateur

User Manual

CN-6000

2004-05-12

Warning!

This is a class A product. In a domestic environment this

product may cause radio interference in which case the user

may be required to take adequate measures.

Thisequipmenthasbeentestedandfoundtocomplywiththe

limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment

is operated in a commercial environment. This equipment

generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communi-

cations. Operation of this equipment in a residential area is

likelytocauseharmfulinterferenceinwhichcasetheuserwill

be required to correct the interference at his own expense.

2004-05-12

Packing List

The complete CN-6000 package consists of:

M1 CN-6000 KVM On the NetControl Unit

M1 CS Custom KVM Cable Set

M1 Power Adapter

M1 Rack Mount Kit

M1SoftwareCD

M1 User Manual

M1 Quick Start Guide

Check to make sure that all the components are present and that nothing was

damaged in shipping. If you encounter a problem, contact your dealer.

Read this manual thoroughly and follow the installation and operation procedures

carefully to prevent any damage to the unit, and/or any of the devices connected

to it.

Manual Part No. PAPE-0227-1AT

Printed in Taiwan 04/2004

All brand names and trademarks are the registered property of their respective owners.

2004-05-12

CN-6000 User Manual

iii

Contents

1. Introduction

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Hardware Setup

Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3. The Administrator Utility

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Starting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

The Settings Notebook . . . . . . . . . . . . . . . . . . . . . . . . . 13

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Uploading Changes . . . . . . . . . . . . . . . . . . . . . . . . 14

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

User Management . . . . . . . . . . . . . . . . . . . . . . . . . 21

Customization . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Upgrading the Firmware . . . . . . . . . . . . . . . . . . . . . . . . 24

Java Authentication Page . . . . . . . . . . . . . . . . . . . . . . . . 26

4. The Windows Client

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Starting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

The Connection Screen . . . . . . . . . . . . . . . . . . . . . . 28

The File Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

The Tools Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

2004-05-12

CN-6000 User Manual

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Screen Information . . . . . . . . . . . . . . . . . . . . . . . . 36

Keystrokes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Mouse Synchronization . . . . . . . . . . . . . . . . . . . . . . 37

Video Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . 39

5. The Java Client

Starting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

The Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

6. The Log Server

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Starting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

The Menu Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

The CN-6000 List Panel . . . . . . . . . . . . . . . . . . . . . . . . 53

The Event List Window . . . . . . . . . . . . . . . . . . . . . . . . 55

Appendix

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

General Operation . . . . . . . . . . . . . . . . . . . . . . . . . 59

Sun Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

The Administrator Utility . . . . . . . . . . . . . . . . . . . . . 60

The Windows Client . . . . . . . . . . . . . . . . . . . . . . . 60

The Java Client . . . . . . . . . . . . . . . . . . . . . . . . . . 61

The Log Server . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 62

2004-05-12

CN-6000 User Manual

About This Manual

ThisUserManualis providedto helpyou getthe mostfromyour CN-6000system.

It covers all aspects of installation, configuration and operation. An overview of

the information found in the manual is provided below.

Overview

Chapter 1, Introduction, introduces you to the CN-6000 System. Its purpose,

features and benefits are described.

Chapter 2, Hardware Setup, presents the front and back panel components,

and explains how to connect the CN-6000 to your server or KVM switch and the

Internet.

Chapter 3, The Administrator Utility, explains how to connect to the

CN-6000 as an administrator; and how to configure the CN-6000 for operation.

Chapter 4, The Windows Client, explains how to run the Windows Client

Software; how to connect to the CN-6000 and how to remotely control the

connected server (or servers via a KVM switch).

Chapter 5, The Java Client, explains how to run the Java Client Software;

how to connect to the CN-6000 and how to remotely control the connected server

(or servers via a KVM switch).

Chapter 6, The Log Server, is a Windows-based administrative utility that

records all the events that take place on selected CN-6000 units and stores them

in a searchable database.

An Appendix at the end of the manual provides specifications and other

technical information regarding the CN-6000.

2004-05-12

CN-6000 User Manual

Conventions

This manual uses the following conventions:

Courier Indicates text that you should key in.

[ ] Indicates keys you should press. For example, [Enter] means to

press the Enter key. If keys need to be chorded, they appear

together in the same bracket with a plus sign between them:

[Ctrl+Alt].

1. Numbered lists represent procedures with sequential steps.

MBullet lists provide information, but do not involve sequential

steps.

> Indicates selecting an option on a menu. For example, Start > Run

means to open the Start menu, and then select Run.

Indicates critical information.

2004-05-12

CN-6000 User Manual

vii

Notes:

2004-05-12

CN-6000 User Manual

viii

Chapter 1.

Introduction

Overview

The CN-6000 is a control unit that allows operators to monitor and access their

computers from remote locations. The CN-6000 connects to the Internet, an

Intranet,LAN, or WAN usingindustry standardCategory5 cable, thenuses KVM

cable to connect to a local KVM switch or server.

Since the CN-6000 uses TCP/IP for its communications protocol, the server or

KVM switch it is connected to can be accessed from any computer on the Net -

whether that computer is located down the hall, down the street, or half-way

around the world.

Operators at remote locations connect to the CN-6000 via its IP address. Once a

connectionhasbeen establishedandauthorizationgranted,operatorsoftheremote

computer can exchange keyboard, video and mouse signals with the server (or

servers on a KVM switch installation), just as if they were present locally and

working on the equipment directly.

KVM Switch

2004-05-12

Withitsadvanced security features, theCN-6000is the fastest,most reliable, most

cost effective way to remotely access and manage widely distributed multiple

computer installations.

The Administrator and Client software utilities provided with the CN-6000 make

it easy to install, maintain, and operate. System administrators can handle a

multitude of tasks with ease - from installing and running GUI applications, to

BIOS level troubleshooting, routine monitoring, concurrent maintenance, system

administration, rebooting and even pre-booting functions.

The Administrator Utility is used to: configure the system; limit access from

remote computers; manage users; and maintain the system with firmware and

software module updates.

Both a Windows GUI Client and a Java Client are provided for IP connection and

CN-6000 is platform independent, and is able to work with all operating systems.

The CN-6000’s client software allows access to, and control of, the connected

servers. Once an operator successfully connects and logs in, his screen displays

what is running on the remote unit attached to the CN-6000 (a KVM OSD display,

a server’s desktop, or a running program, for example) and he can control it from

his console just as if he were there.

The Log Server records all the events that take place on selected CN-6000 units

for the administrator to analyze.

Your CN-6000 investment is protected by a Firmware Upgrade Utility. You can

stay current with the latest functionality improvements by downloading firmware

update files from our website as they become available, and then using the utility

to quickly and conveniently perform the upgrade.
