ATCOM D2SW Manuel utilisateur
D2SW
IP Phone
Version: 1.0
2019-02-26
IP Phone
User Manual
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn2
Copyright © 2022 ATCOM TECHNOLOGY
Copyright © 2022 ATCOM Technology CO., LTD. All rights reserved. No parts of this publication
may be reproduced or transmitted in any form or by any means, electronic or mechanical,
photocopying, recording or otherwise, for any purpose, without the express written permission of
ATCOM Technology CO., LTD. Under the law, reproducing includes translating into another
language or format.
Caution:
Change or modifications to this product not expressly approved by ATCOM, or operation of this
product in any way other than as detailed by this User Manual, could void your manufacture
warranty.
This document is subject to change without notice, if the content of document is difference
from the actual IP phone feature, please refer to the actual IP phone.
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn3
Contact ATCOM
Overview of ATCOM
ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping
innovating with customer’s needs oriented, working with partners to establish a total solution
for SMB VoIP with IP phone.
With more than ten years of experience in R&D, manufacturing and service in the VoIP
industry. ATCOM mission is "creating maximum value for voice over IP applications". We are
dedicated to providing competitive IP phones and other IP voice terminals for equipment
manufacturers, hosted PBX suppliers and telecoms operators. We offer extremely valuable IP
voice solutions to enterprises.
Until now, our VoIP products have been available in 60+ countries and used by millions of end
users.
Contact Sales
Address Area C, A2F , Block 3 ,Huangguan Technology Park , #21 Tairan 9th
Rd, Chegongmiao , Futian District , Shenzhen China
Tel + (86) 755-83018618-1
FD2SW(w)
+ (86) 755-83018319
E-mail sales@atcom.com.cn
Contact Technical Support
Tel + (86) 755-83018618-2
E-mail Support@atcom.com.cn
Website Address:http://www.atcom.cn/
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn4
Content
Contact ATCOM ................................................................................. 3
1. Overview of D2SW ........................................................................... 7
1.1. Interface ......................................................................... 7
1.2. Hardware .......................................................................... 8
1.3. Software .......................................................................... 8
1.4. Network ........................................................................... 9
1.5. Management and Maintenance ........................................................ 9
1.6. Protocol .......................................................................... 9
1.7. Compliant and Certified Standard ................................................. 10
1.8. Packing list ..................................................................... 10
1.9. Connection ....................................................................... 10
1.10.Installation ........................................................................ 12
2. Keypad and GUI ............................................................................ 15
2.1. Keypad .............................................................................. 15
2.2. Starting ............................................................................ 17
2.3. Standby ............................................................................. 18
3. Call Function ............................................................................. 20
3.1. Answer the calls .................................................................... 20
3.2. Make Calls .......................................................................... 21
3.3. Multiple line dial-up ............................................................... 23
3.4. Call Hold ........................................................................... 23
3.5. Call Transfer ....................................................................... 23
3.6. Mute calls .......................................................................... 24
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn5
3.7. 3-Way Conference .................................................................... 24
3.8. Hang up the phone ................................................................... 26
3.9. Voicemail ........................................................................... 26
4. Configuration ............................................................................. 26
4.1. Guide document ...................................................................... 27
4.2. Status info ......................................................................... 28
4.3. Multi-Scene ......................................................................... 30
4.3.1. Configure the multiple scene from the LCD setting ............................ 30
4.3.2. Configure the multiple scene from the Webpage .............................. 31
4.4. Call Features ....................................................................... 32
4.4.1. Call Forward .................................................................. 33
4.4.2. Call Waiting................................................................... 36
4.4.3. Auto Answer .................................................................. 37
4.4.4. DSS Keys ..................................................................... 38
4.4.5. DND .......................................................................... 43
4.4.5. Key as Send .................................................................. 45
4.4.6. Hotline ....................................................................... 46
4.4.7. Anonymous Call .............................................................. 46
4.5. Contacts ............................................................................ 48
4.6. History ............................................................................. 54
4.7. Message ............................................................................. 57
4.7.1. Voice Mail .................................................................... 57
4.8. Settings ............................................................................ 58
4.9. Display ............................................................................. 75
5. Advanced Feature .......................................................................... 77
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn6
5.1. Codecs .............................................................................. 77
5.2. Capture and Upgrading ............................................................... 78
5.3. Auto Provision ...................................................................... 80
5.4. Export & Import configuration file .................................................. 82
5.4.1. Export configuration file ...................................................... 82
5.4.2. Import configuration file ...................................................... 83
5.5. Export System log ................................................................... 83
5.6. Dial plan ........................................................................... 84
5.6.1. Replace Rule .................................................................. 85
5.6.2. Dial-now ...................................................................... 86
5.6.3. Area Code .................................................................... 87
5.6.4. Block Out ..................................................................... 88
6. FAQ ....................................................................................... 89
6.1. How to reset to factory ............................................................. 91
6.2. Upgrade the firmware on safe mode ................................................... 92
6.3. How to make IP Peer to Peer call .................................................... 92
7.Trouble shooting ........................................................................... 94
7.1. The phone is failed to register to SIP server ....................................... 94
7.2. The phone is failed to gain IP address .............................................. 94
7.3. Only one party can hear from another on calling ..................................... 94
8. Abbreviation .............................................................................. 95
9. FCC Caution ............................................................................... 96
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn
7
1. Overview of
D2SW
Type
POE
D2SW
No
1.1. Interface
7
D2SW
D2SW
POE
Power adapter Wi-Fi
No
Necessary Yes
100M
Yes
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn8
Power Input DC 5V-600mA
LAN Port RJ45
Headset Jack RJ9
Handset Jack
RJ9
1.2. Hardware
LCD 128*64
CPU 400MHz Dual-Core
LED Indicator 1 Status Light , 2 line indicators
1.3. Software
Sip 2.0 (RFC3261) and other related SIP RFCs
6 SIP accounts registration, 2 SIP line keys
STUN
Jitter Buffer, VAD,CNG
G711A, G711U, G722, G726-16, G726-24, G726-32, G726-40, G729, L16, iLBC_13_3,
iLBC_15_2
Echo Cancellation
SIP Domain name, Authentication and Backup SIP Server
DTMF（RFC2833, Inband, SIP INFO)
Call transfer, Call forward, 3-way conference, Call hold, Call back
DND(Do Not Disturb), Auto answer, Blacklists, Block Call-ID, Block Anonymous call, Dial
plan, IP call
Phone book with 1000contacts and 50 blacklists
Call History with 400 records include answered calls, missed calls, dialed calls and forward
calls
Auto update via HTTP, HTTPS, FTP, TFTP, DHCP, RPS and PNP
Syslog
SNTP,NTP
Customized Ringtone
Daylight Saving time
OpenVPN, QoS
802.1X
WEB access with different login level
Soft button: soft button *4
Redundancy SIP server
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn9
Multi-language: English, French, Hebrew, Russian, Spanish, Chinese, Persian, Polish,
Portuguese, Turkish, German, Italian
Support Multi-scene feature scenarios
Support Guide document
D2SW is signal port IP phone, enabled the Wi-Fi default
1.4. Network
LAN/PC: Support Bridge mode
Support Open VPN
Support DHCP, STATIC IP
Primary/Secondary DNS Server
Support QoS
Support LLDP
Support 802.1X
Web access via HTTP&HTTPS
Support 2.4GHz Wi-Fi with 802.11n protocol
Support the Wi-Fi and Ethernet network change connect automatically
1.5. Management and Maintenance
Support firmware updating under safe mode
Support different level user management
Configuration via web , keyboard
Support multi-language
Firmware and configuration file auto provision
Support system log
1.6. Protocol
IEEE 802.3 /802.3 u 10 Base T / 100Base TX
DHCP: Dynamic Host Configuration Protocol
SIP RFC3261, RFC3262, RFC3263, RFC3264, RFC3265, RFC2543, RFC3489, RFC3842,
RFC3515, RFC2976, RFC3428, RFC2327, RFC2782, RFC1889
TCP/IP: Transfer Control Protocol/Internet Protocol
RTP: Real-time Transport Protocol
RTCP:RTP Control Protocol
DNS: Domain Name Server
TFTP: Trivial File Transfer Protocol
HTTP:Hypertext Transfer Protocol
FTP:File Transfer Protocol
D2SW IP Phone User Manual
ATCOM TECHNOLOGY CO., LIMITEwww.atcom.cn10
1.7. Compliant and Certified Standard
CE:
Comply with ROHS in EU
Comply with ROHS in China
Operation temperature: -10 ~ 50° C
Storage temperature: -10 ~ 50° C
Humidity: 10 to 90% no dew
1.8. Packing list
Model D2SW
Telephone 1 Unit
Handset 1 Unit
Handset cable 1 Unit
Stand bracket 1 Unit
Power adapter Standard
Network Cable 1 Unit，1.5 meters
Quickstart Guide 1 Unit
Headset Optional
1.9. Connection
1.9.1. Connect to ethernet Network
D2SW is able to be connected with network via LAN port.
