Asus RT-AC5300 Manuel utilisateur
Quick Start Guide
RT-AC5300
Wireless-AC5300 Tri-band
Gigabit Router
¨
NA10459 / First Edition / July 2015
na10459_rt-ac5300_qsg.indb 1 2015/7/16 12:17:30
Table of contents
English.............................................................................................3
繁體中文 ........................................................................................16
Français ...........................................................................................29
Português.......................................................................................42
Español............................................................................................55
NOTE / <
注意
> / <REMARQUE> / <NOTA> / <NOTA>
• For more details, refer to the user manual included in the
support CD.
• 更多資訊，請參考請參考驅動程式與公用程式光碟中的使用手
冊。
• Pour plus de détails, consultez le manuel de l'utilisateur
contenu dans le CD de support.
• Para mais detalhes, consulte o manual do utilizador
incluído no CD de suporte.
• Para obtener más detalles, consulte el manual del usuario
incluido en el CD de soporte.
na10459_rt-ac5300_qsg.indb 2 2015/7/16 12:17:31
3
English
A quick look
Power button WAN (Internet) LED
Red: No IP or no physical connection.
On: Has physical connection to a wide
area network (WAN).
Power (DC-IN) port LAN LED
USB 3.0 port WPS LED
WAN (Internet) port USB 2.0 port
LAN 1~4 ports LED On/O button
Power LED WPS button
2.4GHz LED Wi-Fi On/O button
5GHz LED
na10459_rt-ac5300_qsg.indb 3 2015/7/16 12:17:32
4
English
NOTES:
• If any of the items is damaged or missing, contact your retailer.
• USB External HDD/Flash disk:
• The wireless router works with most USB HDDs/Flash disks up to
4TB and supports read-write access for FAT16, FAT32, NTFS, and
HFS+.
• To safely remove the USB disk, launch the web GUI (http://router.
asus.com), then in the Network Map page's upper right corner,
click the USB icon and click Eject USB 3.0 / USB 2.0.
• Incorrect removal of the USB disk may cause data corruption.
• For the list of le system and hard disk partitions that the
wireless router supports, visit http://event.asus.com/networks/
disksupport
• For the list of printers that the wireless router supports, visit
http://event.asus.com/networks/printersupport
Package contents
RT-AC5300 Wireless Router AC adapter
Network cable (RJ-45) Quick Start Guide
Support CD (User Manual)
na10459_rt-ac5300_qsg.indb 4 2015/7/16 12:17:32
5
English
Installing your router
IMPORTANT: Before installing the router, ensure that Internet connec-
tion is available.
1. Position your wireless router.
For optimal wireless transmission between the wireless router and connected
wireless devices, ensure that you:
• Place the wireless router in a centralized area for a maximum wireless coverage
for the network devices.
• Keep the wireless router away from metal obstructions and away from direct
sunlight.
• Keep the wireless router away from 802.11g or 20MHz only Wi-Fi devices,
2.4GHz computer peripherals, Bluetooth devices, cordless phones, transformers,
heavy-duty motors, uorescent lights, microwave ovens, refrigerators, and other
industrial equipment to prevent signal interference or loss.
• Always update to the latest rmware. Visit the ASUS website at
http://www.asus.com to get the latest rmware updates.
na10459_rt-ac5300_qsg.indb 5 2015/7/16 12:17:32
6
English
2. Prepare your modem.
a. Unplug the AC adapter from the power outlet and disconnect it from your
cable/ADSL modem.
b. Disconnect the network cable from your cable/ADSL modem.
c. Reboot your computer (recommended).
Modem
OFF!
a
b
c
WARNING! Before disconnecting the wires/cables, ensure that your
cable/ADSL modem has been turned o for at least two minutes. If your
modem has a backup battery, remove it as well.
na10459_rt-ac5300_qsg.indb 6 2015/7/16 12:17:33
7
English
3. Set up your wireless environment.
RT-AC5300
WAN
1LAN
Internet
Modem
b
a
c
d
a. Insert your wireless router’s AC adapter to the DC-IN port and plug it to a
power outlet.
b. Using another network cable, connect your modem to your wireless router’s
WAN port.
c. Insert your modem’s AC adapter to the the DC-IN port and plug it to a power
outlet.
d. Using the bundled network cable, connect your computer to your wireless
router’s LAN port. Ensure that the WAN and LAN LEDs are blinking.
4. Disable some settings on your computer.
a. Disable the proxy server, if enabled.
b. Set the TCP/IP settings to automatically obtain an IP address.
c. Disable the dial-up connection, if enabled.
NOTE: For more details on disabling your computer settings, refer to
Frequently Asked Questions (FAQs).
na10459_rt-ac5300_qsg.indb 7 2015/7/16 12:17:33
8
English
Quick Internet Setup (QIS) with Auto-detection
The Quick Internet Setup (QIS) function guides you in quickly setting up your
Internet connection.
NOTE: When setting the Internet connection for the rst time, press
the Reset button on your wireless router to reset it to its factory default
settings.
To use QIS with auto-detection:
1. Log into the Web GUI. The QIS page launches automatically.
NOTES:
• By default, the login username and password for your wireless
router's Web GUI is admin.
• The wireless router's login username and password is dierent from
the 2.4GHz/5GHz network name (SSID) and security key. The wireless
router's login username and password allows you to log into your
wireless router's Web GUI to congure your wireless router's settings.
The 2.4GHz/5GHz network name (SSID) and security key allows Wi-Fi
devices to log in and connect to your 2.4GHz/5GHz network.
na10459_rt-ac5300_qsg.indb 8 2015/7/16 12:17:33
9
English
2. The wireless router automatically detects if your ISP connection type is Dy-
namic IP, PPPoE, PPTP and L2TP. Key in the necessary information for your
ISP connection type.
IMPORTANT! Obtain the necessary information from your ISP about
the Internet connection type.
for Automatic IP (DHCP)
for PPPoE, PPTP and L2TP
na10459_rt-ac5300_qsg.indb 9 2015/7/16 12:17:33
10
English
NOTES:
• The auto-detection of your ISP connection type takes place when you
congure the wireless router for the rst time or when your wireless
router is reset to its default settings.
• If QIS failed to detect your Internet connection type, click Skip to
manual setting and manually congure your connection settings.
3. Assign the wireless network name (SSID) and security key for your 2.4GHz
and 5 GHz wireless connection. Click Apply when done.
4. Your Internet and wireless settings are displayed. Click Next to continue.
5. Read the wireless network connection tutorial. When done, click Finish.
na10459_rt-ac5300_qsg.indb 10 2015/7/16 12:17:34
