Asus P2/370A Manuel utilisateur
Quick Installation Chart
For your convenience, this chart lists all the CPUs supported by P2/370A & P2/370A-Z and their
corresponding jumper setting.
CPU Model Ratio JF0 JF1 JF2 JF3
300/100 200/66 3.0x 1-2 2-3 1-2 1-2
350/100 233/66 3.5x 1-2 2-3 2-3 1-2
400/100 266/66 4.0x 2-3 1-2 1-2 1-2
450/100 300/66 4.5x 2-3 1-2 2-3 1-2
500/100 333/66 5.0x 2-3 2-3 1-2 1-2
550/100 366/66 5.5x 2-3 2-3 2-3 1-2
600/100 400/66 6.0x 1-2 1-2 1-2 2-3
650/100 433/66 6.5x 1-2 1-2 2-3 2-3
700/100 466/66 7.0x 1-2 2-3 1-2 2-3
750/100 500/66 7.5x 1-2 2-3 2-3 2-3
800/100 533/66 8.0x 2-3 1-2 1-2 2-3
The Ratio of some latest CPUs are fixed by Intel, such as Celeron 366, 400... etc. You can ignore the four
jumpers if you have this CPU on board and it will be auto detected by motherboard. Please check with the
CPU manufacturer or vendor for the CPU Ratio information.
*** The CPU CLK over specification operation is optional, please see session 3.4.15 for more information.
P2/370A or P2/370A-Z
Motherboard
User’s Manual
Product Name: P2/370A or P2/370A-Z
Manual Revision: English, 1.1
Trademarks
Intel, Socket 370, Celeron, Pentium II and Pentium III are trademarks of Intel Corporation
Award is a trademark of Award Software International Inc.
MS-DOS, Windows 95, Windows 98 and Windows NT are registered trademarks of Microsoft Corporation
Novell is a trademark of Novell Corporation
Sound Blaster SB16 is a trademark of Creative Technology
ESS and Solo-1 are trademarks of ESS Technology, Inc.
All other brand and product names are trademarks or registered trademarks of their respective companies.
Table of Contents
Chapter 1. Introduction
1.1 Product Overview
1.2 Features
1.3 Specifications
1.4 Content
1.5 System Board Layout
Chapter 2. Hardware Setup
2.1 Installation Procedure
2.1.1 Jumper Settings
2.1.2 Enable/Disable Sound
2.1.3 Clearing the CMOS
2.1.4 CPU Voltage Setting
2.1.5 CPU Frequency Selection
2.1.6 CPU FSB Frequency Setting
2.2 Installation of CPU
2.2.1 For Celeron, Pentium II & III CPU
2.2.2 For Socket 370 CPU
2.3 Installation of Memory
2.3.1 Installation of 168-pin DIMM
2.3.2 Removal of 168-pin DIMM
2.3.3 Memory Configuration
2.4 I/O Connections/Panel Connections
2.4.1 ATX Power Connector
2.4.2 CPU Fan Connector
2.4.3 Infrared Connector
2.4.4 Wake-up on LAN Connector
2.4.5 Creative’s SB_LINK Sound Connector
2.4.6 Floppy Disk Drive Connector
2.4.7 Primary/Secondary IDE Connector
2.4.8 PS/2 Mouse Port
2.4.9 PS/2 Keyboard Connector
2.4.10 Serial Port
2.4.11 Printer Port
2.4.12 USB Connectors
2.4.13 Line Out Connector (optional)
2.4.14 Line In Connector (optional)
2.4.15 Microphone In Connector (optional)
2.4.16 Game/MIDI Port (optional)
2.4.17 ATAPI IDE/SONY Audio (optional)
2.4.18 Mitsumi Audio (optional)
2.4.19 Panel Connection
Chapter 3. BIOS Setup
3.1 CMOS Setup Utility
3.2 Standard CMOS Setup
3.3 BIOS Features Setup
3.4 Chipset Features Setup
3.5 Power Management Setup
3.6 PNP/PCI Configuration Setup
3.7 Integrated Peripherals
3.8 Load BIOS Defaults
3.9 Load Setup Defaults
3.10 Supervisor/User Password
3.11 IDE HDD Auto Detection
3.12 Exit CMOS Setup Utility
Chapter 4. Sound Driver Installation
4.1 Windows 95 Installation
4.2 Windows 98 Installation
4.3 Windows NT 4.0 Installation
4.4 AudioRack32 Installation
Chapter 1. Introduction
1.1 Product Overview
Thank you for purchasing the P2/370A & P2/370A-Z motherboard. This motherboard utilizes Intel's latest
technology, namely 440BX ( 440ZX ) AGPset chipset. We have conducted a motherboard compatibility test
with a variety of hardware and software, such as CPUs, memory, display cards, CD ROMs, Novell, MS
Office ....etc and has passed NSTL Year 2000 certification test program.
We have set high standards on our quality control, with absolute confidence, we believe this product is the
wisest choice.
This manual is composed of four sections. The first section is the introduction of this motherboard, and the
second section explains the proper procedure to setup the motherboard, the third section provides
information on how to setup the CMOS. The last section states the sound driver installation .
1.2 Features
Support Desktop Management Interface (DMI) through BIOS.
Support Accelerated Graphics Port (AGP) cards for high performance.
Modem Remote Ring On.
Wake up on LAN.
RTC Wake Up Alarm: Program the date/time to wake up your system.
Support NCR SCSI BIOS.
Support Advanced Configuration Power Interface (ACPI).
BIOS Green feature function, and 2Mbits “Plug & Play” Flash ROM.
ESS 1938S Solo-1 PCI Sound on board (optional).
1.3 Specifications
CPU - Supports Intel Celeron, Pentium II, Pentium III with 66/100 FSB Processors
Chipset - Intel 440BX AGPset chipset for P2/370A ( Intel 440ZX AGPset chipset for
P2/370A-Z )
DIMM - Supports 3.3V EDO or SDRAM in 3 168-pin banks,each bank consists of
1x168-pin 64-bit DIMM socket, which can support memory sizes of
8/16/32/64/128/256 MB modules. (P2/370A-Z has 2x168-pin socket only )
- Supports up to a maximum of 768 MB system memory( maximum system
memory of P2/370A-Z is 512MB )
IDE - Dual channel PIO and PCI Bus Master IDE ports support up to 4 EIDE devices
for HDD or CD-ROM
- Supports PIO Mode 4 with data transfer rate up to 14 MB/Sec
- Supports Ultra DMA 33 (UDMA) with data transfer rateup to 33 MB/Sec
BIOS - 2Mbits Award BIOS V.4.51 with built-in Anti-Virus, DMI support, and green
function (Plug-and-Play BIOS)
- Supports CD-ROM, SCSI, and LS120/ZIP boot up
- Support NCR SCSI BIOS.
I/O Devices - One FDD control port supports two of the 5.25" or 3.5" floppy drives up to 2.88
MB.
- Two high-speed 16550 UART compatible serial ports
- One parallel ports with ECP/ EPP compatibility.
- One PS/2 mouse port
- One PS/2 Keyboard connector
IR Port - One IrDA/ASKIR compatible Infrared interface port. (Cable optional)
USB Ports - Two Universal Serial Bus (USB) ports support up to 127 peripheral devices.
Sound (optional) - ESS Solo-1 ES1938S PCI Sound Chip
- Built-in 3D audio effects processor
- Full native DOS games compatibility, via three technologies TDMA, DDMA &
PC/PCI
- High quality ESFM music synthesizer
- Dynamic range (SNR) over 80db
- Record, compress and playback voice, sound and music
- Full-Duplex operation for simultaneous record and playback
- Stereo inputs from line in, Auxiliary A (CD audio) and Auxiliary B and a mono
input from microphone
- MPU-401 interface for wavetable synthesizer and MIDI devices
- Integrated dual game port
- Support PC games and application for Sound Blaster And Sound Blaster pro
- Support Microsoft Windows Sound System
- Meet PC 97/98 and WHQL specifications
- Sample record/playback rates up to 48KHz
ATX Power - Supports Modem remote Ring-On function
- Supports software power off function
- Supports RTC Wake-Up.
- Supports Wake up on LAN.
Expansion Slots - Four 32-bit PCI expansion slots
- One 16-bit ISA expansion slot
- One 32-bit AGP expansion slot
Others - Supports Creative’s Sound Blaster 16 compatibility for real-mode DOS games.
Operating System - Supports Windows 95/98, Windows NT, MS-DOS V. 6.22, OS/2, Novell, Unix,
SCO UNIX.....
Dimension - 305 mm x 170 mm ATX Form factor
1.4 Content
The motherboard box contains the following items:
One Motherboard
One IDE Ribbon Cable
One Floppy Ribbon Cable
One Retention mechanism
One Driver CD
User's Manual & Quick Installation Chart
1.5 MotherBoard Layout
Notice:
If the product name is P2/370A-Z the part number of chipset is FW82443ZX instead of FW82443BX.
P2/370A-Z supports M1 & M2 DIMM socket only.
Chapter 2. Hardware Setup
2.1 Installation Procedure
1. Jumper settings
2. Installation of CPU
3. Installation of Memory
4. I/O Connections & Panel Connections
2.1.1 Jumper Settings
In this manual , (1-2) represents the first and second pins of the jumper. (2-3) represents the second
and third pins of the jumper. On the motherboard, you will see two sets of jumpers with different
color jumper caps:
Yellow Jumper Caps : Sets the Function of Flash CMOS
JRTC
Green Jumper Caps : Sets the type and speed of CPU
JF0, JF1, JF2, JF3
Red Jumper Caps : Sets the FSB frequency of CPU JFSB
Enable/Disable Sound function JSND (optional)
WARNING: Electronic parts are Static sensitive. To prevent damage to the computer and its parts
please take the following measures.
-Work on a surface such as concrete, linoleum or hard wood floor.
-Ground your self with either a properly installed grounding strap or by touching a major electrical
appliance long enough to discharge the static.
2.1.2 Enable/Disable Sound (JSND : Red Jumper Cap) (The Sound function and jumper are optional)
This jumper lets you to enable or disable the sound function.
1-2 : Enable Sound function (Default Setting)
2-3 : Disable Sound function
2.1.3 Clearing the CMOS (Yellow Jumper Caps)
JRTC: CMOS Function Selection
1-2 : Clear data
2-3 : Normal Operation (Default Setting)
How to Clear the CMOS Setting
1. Turn off the power.
2. Remove ATX power cable from connector J1.
3. Remove Yellow Jumper Cap from JRTC (2-3) and put on JRTC (1-2) to remove the CMOS setting.
4. Remove Yellow Jumper Cap from JRTC (1-2) and put on JRTC (2-3).
5. Connect ATX power cable back to connector J1.
6. Turn on the power.
7. While the system reboots, press <DEL> key to set the BIOS setup.
2.1.4 CPU Voltage Setting
The motherboard supports CPU VID function, the CPU core voltage is automatically detected, the
range is from 1.3V to 3.5V for Pentium II & III CPU and. the range is from 1.3V to 2.0V for Socket 370
& Celeron CPU
2.1.5 CPU Frequency Selection (Green Jumper Caps)
CPU Model Ratio JF0 JF1 JF2 JF3
300/100 200/66 3.0x 1-2 2-3 1-2 1-2
350/100 233/66 3.5x 1-2 2-3 2-3 1-2
400/100 266/66 4.0x 2-3 1-2 1-2 1-2
450/100 300/66 4.5x 2-3 1-2 2-3 1-2
500/100 333/66 5.0x 2-3 2-3 1-2 1-2
550/100 366/66 5.5x 2-3 2-3 2-3 1-2
600/100 400/66 6.0x 1-2 1-2 1-2 2-3
650/100 433/66 6.5x 1-2 1-2 2-3 2-3
700/100 466/66 7.0x 1-2 2-3 1-2 2-3
750/100 500/66 7.5x 1-2 2-3 2-3 2-3
800/100 533/66 8.0x 2-3 1-2 1-2 2-3
The Ratio of some latest CPUs are fixed by Intel, such as Celeron 366, 400… etc. You can ignore the
four jumpers if you have this CPU on board and it will be auto detected by motherboard. Please
check with the CPU manufacturer or vendor for the CPU Ratio information.
2.1.6 CPU FSB Frequency Setting (Red Jumper Caps)
The JFSB jumper provides three FSB frequency settings for the CPU. Auto Detect , 66MHz or
100MHz FSB frequency can be selected with this jumper. The 100MHz FSB frequency setting is over
specification operation for 66MHz FSB CPU . The over specification operation is not recommended.
2.2 Installation of CPU
2.2.1 For Celeron, Pentium II & III CPU
The motherboard provides a Single Edge Contact(SEC)slot for processor packaged in an SEC
cartridge. Follow these steps to install CPU:
Mount the Universal Retention Mechanism (URM) & Insert the CPU: ( The illustration is just for
reference )
This URM was designed to accommodate 3 types of CPU Form Factor. ( SECC, SECCII & SEPP ). For
Example : Pentium II & Celeron family.
Note : Please put a soft pad under M/B before the installation of URM.
Installation for SECC CPU :
1. Leave space below each mounting hole for the fastener to protrude through the hole.
2. Position URM on the M/B next to the slot1 connector.
3. Push down retainer pin into respective fastener to secure URM onto the M/B.
4. Push CPU into URM to contact with slot1.
5. Make sure latching portion of CPU engaged with windows ledge of URM.
Installation for SECC II or SEPP CPU :
1. Same as step (1) of SECC.
2. Same as step (2) of SECC.
3. Same as step (3) of SECC.
4. Same as step (4) of SECC.
5. Snap in 2 clips into side windows of URM to secure SEPP CPU.
If there is a fan on the CPU, Please plug in the fan cable to the three pin fan connector on the
motherboard (PFAN1).
2.2.2 For Socket 370 CPU
Before installing CPU, make sure the power is off. Locate the level bar on the PGA370 ZIF socket.
Push level bar away from the socket and pull upward 90 degrees. Insert the CPU into the socket.
Make sure the notch of the CPU corresponds with the white dot on the ZIF socket (the corner
without pin socket). Do not push in the CPU. Make sure all pins are aligned with the CPU socket. ON
the level bar.
2.3 Installation of Memory
P2/370A motherboard has 3x168-pin 64-bit Dual Inline Memory Module (DIMM) sockets divided into
3 banks ( P2/370A-Z has 2x168-pin DIMM socket only ). You can install 3.3V Extended Data Output
(EDO)or Unbuffered Synchronous DRAM (SDRAM)memory. This will increase the system reliability.
2.3.1 Installation of 168-pin DIMM (Dual Inline Memory Module)
1. Before inserting the DIMM, make sure the pin1 of the DIMM matches with the pin1 on the DIMM socket.
2. Insert DIMM into the DIMM sockets at a 90-degree angle and press down.
2.3.2 Removal of 168-pin DIMM
1. Press the holding clips on both sides of the socket outward to release the DIMM.
2. Gently pull the DIMM out of the socket.
3.
2.3.3 Memory Configuration
There is no jumper setting required for the memory size or type. It is automatically detected by the
system BIOS, and the total memory size is to add them together.
DIMM Socket DIMM Modules
DIMM1 EDO/SDRAM 8, 16, 32, 64, 128, 256MB
DIMM2 EDO/SDRAM 8, 16, 32, 64, 128, 256MB
DIMM3 EDO/SDRAM 8, 16, 32, 64, 128, 256MB
Notice: The P2/370A-Z motherboard supports DIMM1 & DIMM2 socket only.
2.4 I/O Connections/Panel Connections
I/O Connections
J1 ATX Power Connector
PFAN1 CPU fan connector
SIR Infrared Connector ( Cable optional )
JP1 Wake up on LAN connector
SB_LINK For link with Creative’s Sound Blaster 16
JFLP1 Floppy Disk Drive Connector
IDE1, 2 Primary/ Secondary IDE Connectors
MS PS/2 Mouse Port
KB PS/2 Keyboard Connector
JCOM1, 2 Serial Ports 1 & 2
JPRT Printer Port
USB1, 2 USB Connector
P1 Game/MIDI Connectors (optional)
LOUT Line out Connector (optional)
LIN Line in Connector (optional)
MIC Microphone in Connector (optional)
MITSUMI The Connector for Mitsumi CD-ROM audio cable (optional)
SONY The Connector for IDE/Sony CD-ROM audio cable (optional)
2.4.1 ATX Power Connector (20-pin J1)
Make sure that the power supply is off before connecting or disconnecting the power cable.
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Asus Carte mère
Asus
Asus P5VD2 VM - SE Motherboard - Micro ATX Instructions de montage
Asus
Asus SK8N Manuel utilisateur
Asus
Asus TUF Z270 MARK 2 Manuel utilisateur
Asus
Asus P7F7-E WS SUPERCOMPUTER Manuel utilisateur
Asus
Asus F1A55-M LE R2.0 Manuel utilisateur
Asus
Asus Motherboard A7S8X-MX Manuel utilisateur
Asus
Asus TUF B360-PLUS GAMING Manuel utilisateur
Asus
Asus P5Q GREEN Manuel utilisateur
Asus
Asus P4BP-MX 2.0 Manuel utilisateur
Asus
Asus ITX 220 - Motherboard - Mini ITX Guide de démarrage rapide
Asus
Asus P5G41T-M SI Guide de démarrage rapide
Asus
Asus PEI-10G/82599-2S Manuel utilisateur
Asus
Asus P5V800-MX Manuel utilisateur
Asus
Asus P5WD2 Premium Manuel utilisateur
Asus
Asus H61M-K Manuel utilisateur
Asus
Asus A8N-VM Manuel utilisateur
Asus
Asus P5LD2-C IPAT Manuel utilisateur
Asus
Asus P8Z68-V LX Manuel utilisateur
Asus
Asus P5KPL-AM EPU Manuel utilisateur
Asus
Asus TUF GAMING B650-PLUS Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
Biostar
Biostar M7VIT Bravo Instructions d'utilisation et d'installation
Intel
Intel D33217CK Manuel utilisateur
