Asus CUBX-E Manuel utilisateur

CUBX-L/CUBX-E

Socket 370 ATX Motherboard

USER’S MANUAL

Special Features

CUBX-L

•UltraDMA/33 Support

•2 USB Ports

CUBX-E

•UltraDMA/100 Support

•5 USB Ports (2 standard, 3 upgradeable)

2ASUS CUBX-L/CUBX-E User’s Manual

USER'S NOTICE

Product Name: ASUS CUBX-L/CUBX-E

Manual Revision: 1.00 E606

Release Date: September 2000

No part of this manual, including the products and software described in it, may be repro-

duced, transmitted, transcribed, stored in a retrieval system, or translated into any language in

any form or by any means, except documentation kept by the purchaser for backup purposes,

without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-

TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF

PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-

NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL

OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)

the serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trade-

marks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.

• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

The product name and revision number are both printed on the product itself. Manual revi-

sions are released for each product design represented by the digit before and after the period

of the manual revision number. Manual updates are represented by the third digit in the manual

revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contactASUS

at http://www.asus.com.tw or through any of the means indicated on the following page.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-

NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT

ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-

MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR

ANYERRORSORINACCURACIESTHATMAYAPPEARINTHIS MANUAL, INCLUD-

ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

ASUS CUBX-L/CUBX-E User’s Manual 3

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC. (Asia-Pacific)

Marketing

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112

Telephone: +886-2-2894-3447

Fax: +886-2-2894-3449

Email: [email protected]

Technical Support

MB/Others (Tel): +886-2-2890-7121 (English)

Notebook (Tel): +886-2-2890-7122 (English)

Desktop/Server (Tel):+886-2-2890-7123 (English)

Fax: +886-2-2895-9254

Email: [email protected]

WWW: www.asus.com.tw

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL (America)

Marketing

Address: 6737 Mowry Avenue, Mowry Business Center, Building 2

Newark, CA 94560, USA

Fax: +1-510-608-4555

Email: [email protected]

Technical Support

Fax: +1-510-608-4555

Email: [email protected]

WWW: www.asus.com

FTP: ftp.asus.com/Pub/ASUS

ASUS COMPUTER GmbH (Europe)

Marketing

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany

Fax: +49-2102-442066

Email: [email protected] (for marketing requests only)

Technical Support

Hotline: MB/Others: +49-2102-9599-0 Notebook: +49-2102-9599-10

Fax: +49-2102-9599-11

Support (Email): www.asuscom.de/de/support (for online support)

WWW: www.asuscom.de

FTP: ftp.asuscom.de/pub/ASUSCOM

4ASUS CUBX-L/CUBX-E User’s Manual

CONTENTS

1. INTRODUCTION .............................................................................. 7

1.1 How This Manual Is Organized .................................................. 7

1.2 Item Checklist ............................................................................. 7

2. FEATURES ......................................................................................... 8

2.1 The ASUS CUBX-L/CUBX-E Motherboard ............................. 8

2.1.1 Specifications .................................................................. 8

2.1.2 Special Features ............................................................. 10

2.1.3 Performance Features .................................................... 10

2.1.4 Intelligence .................................................................... 11

2.2 Motherboard Components ........................................................ 12

2.2.1 Component Locations.................................................... 13

3. HARDWARE SETUP ...................................................................... 14

3.1 CUBX-L/CUBX-E Motherboard Layout ................................. 14

3.2 Layout Contents ........................................................................ 15

3.3 Hardware Setup Procedure ....................................................... 17

3.4 Motherboard Settings................................................................ 17

3.5 System Memory (DIMM) ......................................................... 22

3.5.1 General DIMM Notes .................................................... 22

3.5.2 Memory Installation ...................................................... 23

3.6 Central Processing Unit (CPU) ................................................. 25

3.7 Expansion Cards ....................................................................... 26

3.7.1 Expansion Card Installation Procedure ......................... 26

3.7.2 Assigning IRQs for Expansion Cards............................ 27

3.7.3 Accelerated Graphics Port (AGP) ................................. 29

3.8 Connectors ................................................................................ 30

3.9 Starting Up the First Time ........................................................ 41

4. BIOS SETUP..................................................................................... 42

4.1 Managing and Updating Your BIOS......................................... 42

4.1.1 Upon First Use of the Computer System....................... 42

4.1.2 Updating BIOS Procedures (only when necessary) ...... 43

4.2 BIOS Setup Program ................................................................ 45

4.2.1 BIOS Menu Bar ............................................................. 46

4.2.2 Legend Bar .................................................................... 46

4.3 Main Menu................................................................................ 48

4.3.1 Primary & Secondary Master/Slave .............................. 49

4.3.2 Keyboard Features ......................................................... 52

ASUS CUBX-L/CUBX-E User’s Manual 5

CONTENTS

4.4 Advanced Menu ........................................................................ 54

4.4.1 Chip Configuration ........................................................ 58

4.4.2 I/O Device Configuration .............................................. 60

4.4.3 PCI Configuration ......................................................... 62

4.4.4 Shadow Configuration ................................................... 65

4.5 Power Menu .............................................................................. 66

4.5.1 Power Up Control.......................................................... 68

4.5.2 Hardware Monitor ......................................................... 70

4.6 Boot Menu ................................................................................ 71

4.7 Exit Menu ................................................................................. 73

5. SOFTWARE SETUP....................................................................... 75

5.1 Install Operating System........................................................... 75

5.2 Start Windows........................................................................... 75

5.3 Installing Drivers and Software ................................................ 75

6. SOFTWARE REFERENCE ........................................................... 79

6.1 ASUS PC Probe ........................................................................ 79

6.2 ASUS Update............................................................................ 84

7. APPENDIX........................................................................................ 85

7.1 PCI-L101 Fast Ethernet Card ................................................... 85

7.2 ASUS CIDB Intrusion Detection Module ................................ 87

7.3 Glossary .................................................................................... 89

INDEX ................................................................................................... 93

6ASUS CUBX-L/CUBX-E User’s Manual

FCC & DOC COMPLIANCE

FederalCommunicationsCommissionStatement

This device complies with FCC Rules Part 15. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer's instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! Any changes or modifications to this product not expressly ap-

proved by the manufacturer could void any assurances of safety or performance

and could result in violation of Part 15 of the FCC Rules.

Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the

Federal Register, National Archives and Records Administration, U.S. Government Printing Office.

CanadianDepartmentofCommunications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the Canadian

Department of Communications.

This Class B digital apparatus complies with Canadian ICES-003.

CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS CUBX-L/CUBX-E User’s Manual 7

1. INTRODUCTION

Manual / Checklist

1.1 How This Manual Is Organized

This manual is divided into the following sections:

1. INTRODUCTION Manual information and checklist

2. FEATURES Production information and specifications

3. HARDWARE SETUP Intructions on setting up the motherboard.

4. BIOS SETUP Intructions on setting up the BIOS

5. SOFTWARE SETUP Intructions on setting up the included software

6. SOFTWARE REFERENCE Reference material for the included software

7. APPENDIX Optional items and general reference

1.2 Item Checklist

Please check that your package is complete. If you discover damaged or missing

items, please contact your retailer.

Package Contents

(1) ASUS Motherboard

(1) Ribbon cable for internal

UltraDMA/33 IDE drives

(1) Ribbon cable for one 5.25”and

two 3.5”floppy disk drives

(1) Bag of spare jumper caps

(1) ASUS Support CD with

drivers and utilities

(1) This Motherboard User’s

Manual

(1) 40-pin 80-conductor ibbon cable

for internalUltraDMA100/66/33

IDE drives (only for CUBX-E)

(1) Promise ATA100 Support Disk

(only for CUBX-E)

Optional Items

ASUS CIDB chassis intrusion de-

tection module

ASUS IrDA-compliant infrared

module

ASUS PCI-L101 Wake-On-LAN

10/100 Ethernet Card

8ASUS CUBX-L/CUBX-E User’s Manual

2.1 The ASUS CUBX-L/CUBX-E

Motherboard

TheASUS CUBX-L/CUBX-E is carefully designed for the demanding PC user who

wants advanced features processed by the fastest CPU.

2.1.1 Specifications

•Latest Intel Processor Support

Intel Pentium

III 100MHz FSB Coppermine core FC-PGA

Intel Celeron™66MHz FSB Coppermine core FC-PGA

Intel Celeron™66MHz FSB Mendocino PPGA

•Intel AGPset: Features Intel’s 440BX AGPset with I/O subsystems and front-side

bus(FSB)platform,whichbooststhetraditional66MHzexternalbusspeedto100MHz.

•JumperFree™Mode:Allows processor settings and easy overclocking of fre-

quency and Vcore voltage all through BIOS setup when JumperFree™mode is

enabled. Easy-to-use DIP switches instead of jumpers are included to allow

manual adjustment of the processor’s external frequency.

•Anti-Boot Virus BIOS: Features a programmable BIOS, offering enhanced

Advanced ConfigurationPower Interface (ACPI) support forWindows 98 com-

patibility, built-infirmware-basedvirusprotectionthroughTrend ChipAwayVirus

codes, and autodetection of most devices for virtually automatic setup.

•PC100 Memory Support: Equipped with four DIMM sockets to support Intel

PC100-compliant SDRAMs (8, 16, 32, 64, 128, or 256MB) up to 1 GB. These

new SDRAMs are necessary to meet the critical enhanced 100MHz bus speed

requirement.

•Peripheral Wake Up: Supports modem, PS/2 keyboard, PS/2 mouse, and LAN

card wake up functions from sleep or soft-off mode.

•PC Health Monitoring: Provides an easier way to examine and manage system

status information, such as CPU and system voltages, temperatures, and fan

status through the onboard hardware ASIC and the bundled LDCM by Intel or

PC Probe from ASUS.

•AGP Slot: Supports an Accelerated Graphics Port card for high performance,

component level interconnect targeted at 3D graphical display applications us-

ing a 1X or 2X mode bus.

•PCI/ISA Expansion Slots: Provides five 32-bit PCI (rev 2.2) and two ISA ex-

pansion slots. PCI supports up to 133MB/s maximum throughput.

2. FEATURES

Specifications

2. FEATURES

ASUS CUBX-L/CUBX-E User’s Manual 9

2. FEATURES

Specifications

•Multi-I/O:Providestwo high-speed UARTcompatible serial ports and one paral-

lel port with EPP and ECP capabilities.

•UltraDMA/33 Bus Master IDE: Comes with an onboard PCI Bus Master IDE

controller with two connectors that support four UltraDMA/33 IDE devices on

two channels. Supports UltraDMA/33, PIO Modes 3 and 4, and Bus Master IDE

DMA Mode 2, as well as Enhanced IDE devices, such as Tape Backup, CD-

ROM, CD-R/RW, and LS-120 drives.

•Wake-On-LAN Connector: Supports Wake-On-LAN activity through an op-

tionalASUS PCI-L101 10/100 Fast Ethernet PCI card (see 7.1 PCI-L101 LAN

Card) or a similar ethernet card.

•Suspend and Go: Suspend-to-RAM (STR) provides maximum power savings

as an alternative to leaving the computer ON and QuickStart™so that you do

not have to wait for a long time for system bootup (see Suspend-to-RAM Ca-

pability in 4.5 Power Menu for more information).

•Promise PCI-ATA100 Support (only on CUBX-E): Provides support to PCI-

ATA100 controller to provide Ultra DMA/100 solutions.

•Supports Up to 5 USB Ports (only on CUBX-E): Provides support for up to

five USB ports right out of the box.

10 ASUS CUBX-L/CUBX-E User’s Manual

2.1.2 Special Features

•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more

Energy Saving Features for operating systems that support OS Direct Power

Management (OSPM) functionality. With these features implemented in the OS,

PCs can be ready around the clock, yet satisfy all the energy saving standards.

To fully utilize the benefits of ACPI, an ACPI-supported OS such as Windows

98 must be used.

•Easy Installation: Incorporates BIOS that supports autodetection of hard disk

drives, PS/2 mouse, and Plug and Play devices to make the setup of hard disk

drives, expansion cards, and other devices virtually automatic.

•NewCompliancy:Both the BIOS and hardware levels of this motherboard meet

the stringent requirements for PC’99 certification. The new PC’99 requirements

for systems and components are based on the following high-level goals: Sup-

port for Plug and Play compatibility and power management for configuring

and managing all system components, and 32-bit device drivers and installation

proceduresforWindows95/98/NT.Color-coded connectorsanddescriptiveicons

make identification easy as required by PC’99.

•Symbios SCSI BIOS: Supports optional ASUS SCSI controller cards through

the onboard SYMBIOS firmware.

2.1.3 Performance Features

•Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-

ter busses to the memory and processor.

•SDRAMOptimizedPerformance:Supportsthenewgenerationmemory-Syn-

chronous Dynamic RandomAccess Memory (SDRAM) which increases the data

transfer rate to 800MB/s max using PC100-compliant SDRAM.

•High-Speed Data Transfer Interface: The CUBX-L motherboard supports

UltraDMA/33 and can handle data transfer rates up to 33MB/s. The CUBX-E

motherboard supports UltraDMA/100, which increases the data transfer rate to

100MB/s. UltraDMA/100 is backward compatible with DMA/66, DMA/33, and

DMA and with existing DMA devices and systems so there is no need to up-

gradecurrentEIDE/IDEdrivesandhostsystems.(UltraDMA/66andUltraDMA/

100 require a 40-pin 80-conductor cable to be enabled.)

2. FEATURES

Specifications

2. FEATURES
