Asus V70 Manuel utilisateur

1. Overview of V70

1-1. Front View

2. SIM card, Memory card and

Battery Installation

1 2

After installing the SIM

card and the mini SD

card, place the battery

back into the battery

compartment.

Push the battery back

in the direction as

shown until it clicks in

place.

3 4

1-2. Rear View

battery cover

volume up / down button

camera lens

reflective mirror

headphone jack

earpiece / speaker

screen

charger / usb port

SIM

Match the nicked

corner of the SIM card

with the notch on the

card holder. Insert the

SIM card into the holder

with the contacts

facedown.

MINI SD

Place the mini SD card

in the slot with the gold

contacts facing down.

3. Battery Charging

1. Make sure the

battery has been

installed first.

2. Connect the charger

to the charger port

on the bottom of the

phone.

3. Connect the charger

to the wall outlet.

4. The Main Menu

When in the standby mode, press (right soft key)

to enter the main menu and use the navigation keys

to select a menu icon. The lower left corner of the

screen displays OK, while the right displays BACK.

Press to select the menu item and (left soft

key) to exit. For quick exit from the menu, press the

(Power/End ). When in sub-menu, navigate in the

same way as in main menu.

NOTE

：：

：

1. The SIM card must be installed in the correct

orientation; otherwise it may be damaged.

2. The battery can be damaged with incorrect

installation. Make sure to put the pins into the

bottom case first then click it back into place.

Inaccurate installation of the battery may cause

danger.

3. Used batteries should be handled as the

instructions on the battery.

arrow mark facedown

Icon Discription

Phone Book：For adding, organizing, and

searching contacts saved in the phone and

SIM memory.

Messages：For composing, editing, sending,

and managing SMS and MMS messages.

Call History：For checking missed, dialed,

answered call information.

Multimedia：For playing MP3 / FM radio,

playing JAVA games, and composing

ringtones.

File Manager：For managing, checking,

editing, and deleting files, images, audio files

in the phone and the mini SD card.

Settings：For adjusting call settings, display,

ringtone, security, network settings as well as

restoring to the default settings.

5-2. Receiving a call

When a call comes in, the phone will alert users by

sounding the ringtone or vibrating, based on users’

previous setup. The screen will display the incoming

number, contact name (only if on the contact list),

and images that users added for the phone book

entry.

1. Press to answer an incoming call.

2. For answering a call by pressing any key, go to

User Profile > Option >Customize > Answer

Mode > Any Key to activate the function.

5. Calls Making and Receiving

5-1. Making a call

1. Slide open the phone and enter the number for

dialing. When mis-dialing, correct a dialed number

by pressing and long pressing to clear all

numbers.

2. Press to store the number to the phone book

after dialing.

3. Press to start connecting.

Fun & Games：For playing JAVA games,

games, editing images, and stopwatch.

5-3. Speed Dial

5-3-1. From the Phone Book

When in standby mode, press to display contact

names. Select one for calling and then press to

place the call.

5-3-2. Redialing（Call Logs）

Press to display the answered and dialed call

history. Select one for calling from the logs, and then

press to place the call.

5-4. Hands-free Speaker

Press to enable the hands-free speaker and

press again to disable the function during the

call.

Icon Discription

Organizer：For setting alarm clock, sched-

uling appointments, recording memos, and

checking world time.

Services：：

：：

：For specifying the WAP and data

settings, setting up GSM/GPRS and access-

ing to the internet and to STK SIM card

services.

Extra：For using calculator, bluetooth, and

converting units / currency.

Shortcuts：For creating shortcuts.

User Profiles：For setting ringtones, volumes,

answering modes, backlight timer.

6. Settings

6-1. Date∕Time

Enter Settings > Phone Setup > Date and Time

1. Set Home City: Use the navigation keys to locate

your city or the nearest one, and press (OK).

5-6. Cancelling an Incoming Call

For cancelling an incoming call, press to transfer

the caller to users’ voice mail or a busy signal will be

heard. (depending on users’ service provider)

5-5. Keypad Lock

In the standby mode, long press to lock the

keypad, and repeat the same move to unlock.

When the keypad is locked, users can still press

to answer a call and use other functions during the

call. Yet, the keypad will stay locked when the call is

finished or cancelled.

5-7. Call Logs

Press in the standby mode to check missed,

dialed, answered call histories and the information of

the calls. The call logs are limited to 20 entries, so

older calls will be dropped from the list when the

quota is exceeded.

2. Set Time/Date: Use the keypad to enter the hours

and minutes and press (OK). Users can also

enable and disable the Daylight Saving function.

3. Set Format: Users are allowed to choose from a

12 or 24 hour clock time format and different date

format--yyyy/mm/dd; mm dd, yyyy; dd/mm/yyyy;

or mm/dd/yyyy.

4. To display the date and time, the function has to

be set up by pressing Settings > Phone Setup >

Display Setting > Show Date and Time.

6-2. Wallpaper

6-2-1. System Images

1. Enter Settings > Phone Setup > Display Setting

> Wallpaper > System.

2. Press to browse the built-in images and press

to confirm the wallpaper setup.

6-2-2. User Define

1. Enter Settings > Phone Setup > Display Setting

> Wallpaper > User Define.

2. Locate the chosen photo and press to confirm.

6-4. Tone Settings

Enter User Profiles > Option >Customize > Tone

Setup to select different ringtones for Incoming Call,

Alarm, Power On/Off, Slider Open/Close, Message

Tone, and Keypad Tone from built-in tones. Or, go to

Multimedia > Melody Compose for personalized

ringtones.

7. SMS

When a new SMS message arrives, the display will

inform users with a new message animation. Just

slide open the phone and press to read the

message. Also, users can check received messages

by entering Messages > SMS > Inbox. Unread

messages wiil be marked as 。

6-3. User Profiles

On the User Profiles menu, users can select manners

like General, Meeting, Outdoor, Indoor, Headset.

Besides, users can customize features including Tone

Setup, Volume, Alert Type, Intelligent Call Alert, Ring

Type, Connect Notice, Extra Tone, Answer Mode,

LCD Backlight.

3. Press (Option) to select Done

4. Enter a phone number or press to search a

contact name from the phone book list and press

to send.

Note: Inserted objects can include an image,

an animation, or an audio. Some phones may

not be able to receive SMS that contains

anything other than text.

8. MMS

8-1. Composing MMS

8-1-1. Composing Text

1. Enter Messages > MMS > Write Message

2. Select Edit content and press to start editing.

Press to key in text.

8-1-2. Adding Images

After finishing the text, press to select Add

image. Locate the chosen image and press

to confirm.

8-1-3. Adding Audio

After adding images, press to select Add

audio. Locate the chosen audio and press to

7-1. Composing and Sending SMS

1. Enter Messages > SMS > Write Message

2. Key in text messages or press (Option) for

using templates, inserting objects, selecting text

formats, and input methods.

8-1-4. Adding Attachment

If a file needs adding, press to select Add

Attachment. Locate the chosen attachment and

confirm.

※A MMS can only hold one file attachment.

8-1-5 Inserting New Slide

A slide can only include one combination of text,

image, and audio. To have a multi-slide MMS, just

press to select Insert New Slide and repeat

the previous steps to add slides.

8-1-6. Sending MMS

1. In the Write Message window, highlight the To

field and press Edit to maunally Add Number or

Add E-mail or press to access the phone

book to choose recipients

2. For two or more recipients, just press to

repeat the previous step.

3. For Cc or Bcc recipients, operate as the To field.

4. When editing is finished, press to select

Done to Send Only, Save and Send, Save to

Drafts, Send Options, or Exit.

9. Audio Player

V70 is equipped with a high quality audio player for

digital music files.

To start the audio player, select Multimedia > Audio

Player or press to enter the Audio Player interface

directly.

9-1. Interface of the Audio Player

Title

Number∕

Total of Songs

Play Time

Volume

Play∕Pause

Stop

Source (Memory

Card or Phone)

confirm.

9-3. Audio Player Settings（List Auto

Gen）

Enter Multimedia > Audio Player and press

(List) > (Option) > Settings > List Auto Gen

1. Use navigation button left and right to turn On and

Off the List Auto Gen function.

2. List Auto Gen can be activated only when digital

music files are placed under the directory of My

music in the phone or memory card.

3. To add musics, disable the function first and then

enter Multimedia > Audio Player. Press

(List) > (Option) > Add to add a piece of

music or a whole music file.

10. Camera

10-1. Photo Capture

1. Enter Multimedia > Camera or press to activate

camera directly.

2. Press to start capturing.

Option Discription

∕Increase / Decrease Brightness

∕Zoom In / Out

Frame: function only at the 160X120 size

Effect: repeated presses can switch differ-

ent effect settings.

White Balance: repeated presses can switch

different white balance setups.

Delay Timer: repeated presses can set up

delay seconds.

Cont Shot: repeated presses can set up the

number of shots.

Night Mode: repeated presses can start or

stop the night mode.

Image Quality: repeated presses can select

the image quality.

Image Size: repeated presses can resize

the image.

Camera Setting shortcuts

9-2. Playing MP3 Music

1. Select Multimedia > Audio Player. Press to

display a list of available digital music files.

2. Press ∕to choose the previous / next song,

to play / pause music, and to stop music.

3. Press on the right side to adjust volumes.

3. Press (Save) to save the photo to Image

Viewer and press (Back) to discard it.

Video Setting Shortcuts

11. Video Recording

1. Enter Multimedia > Video Recorder and press

to start recording.

2. During recording, press to pause / continue

recording and press to stop recording.

3. Press to store the video to Video Player, or

press to discard it.

Option Discription

∕Increase / Decrease Brightness

∕Zoom In / Out

Effect: repeated presses can switch differ-

ent effect settings.

White Balance: repeated presses can switch

different white balance setups.

Night Mode: repeated presses can start or

stop the night mode.

Table des matières

Autres manuels Asus Téléphone portable

Asus

Asus 02 Xda Graphite Manuel utilisateur

Asus

Asus ROG-PHONE 05 Manuel utilisateur

Asus

Asus J202 Manuel utilisateur

Asus

Asus PadFone X Manuel utilisateur

Asus

Asus Zenfone 2 Laser Manuel utilisateur

Asus

Asus ZENFONE T500 Manuel utilisateur

Asus

Asus Z00XS ZX551ML Manuel utilisateur

Asus

Asus E600 Manuel utilisateur

Asus

Asus P552W Manuel utilisateur

Asus

Asus X00ADC Manuel utilisateur

Asus

Asus ZENFONE 3 SERIES Manuel utilisateur

Asus

Asus P525 Manuel utilisateur

Asus

Asus V66 Handset Manager Manuel utilisateur

Asus

Asus ZENFONE2 ZE500KL Manuel utilisateur

Asus

Asus P750 Manuel utilisateur

Asus

Asus Z008D Manuel utilisateur

Asus

Asus M530w Manuel utilisateur

Asus

Asus J201S Manuel utilisateur

Asus

Asus PadFone Station Manuel utilisateur

Asus

Asus AI220 Manuel utilisateur

Asus

Asus Verizon Zenfone V live Manuel utilisateur

Asus

Asus P750 Instructions de montage

Asus

Asus V75 Manuel utilisateur

Asus

Asus ZB602KL Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
