DB AR1

Owner's Guide

Whilst every effort has been made to ensure the accuracy of the particulars

contained in this Owner's Guide, neither the Manufacturer nor the Dealer, by

whom this Owner's Guide is supplied, shall in any circumstances be held

responsible for any inaccuracy or the consequences thereof.

retrieval system or transmitted, in any form, electronic, mechanical, photo-

copying, recording or other means without prior written permission from Aston

Martin Lagonda Limited.

The manufacturer reserves the right to vary specifications without notice in

accordance with its policy of continual product improvement.

Produced by the Technical Publications Department

ASTON MARTIN LAGONDA LIMITED

Banbury Road, Gaydon, WARWICK, CV35 0DB, England

Telephone: (+44) 01926 644700 Fax: (+44) 01926 644733

Issue 1 - December 2003 Part No. (ROW) 40-150064-AA

Part No. (North America) 40-150065-AA

iii

○○○○○○○○○○○○○○○○○○○○○○○○

DB AR1 Vehicle Provenance

Vehicle Provenance

Model

e.g. Manual/Auto/Touchtronic

Colour

Body Exterior Interior Trim/ Piping

Interior Veneers

Vehicle Identification Number

As on the VIN plate

First Owner

Vehicle prepared for:

First Owner

By - Selling Dealer

Name

Date of Delivery

Date Delivered to First Owner

Second Owner

Name

Selling Dealer

Dealer Name

Date of Sale

Date Sold

○○○○○○○○○○○○○○○○○○○○○○○○

Third Owner

Name

Selling Dealer

Dealer Name

Date of Sale

Date Sold

Fourth Owner

Name

Selling Dealer

Dealer Name

Date of Sale

Date Sold

Fifth Owner

Name

Selling Dealer

Dealer Name

Date of Sale

Date Sold

○○○○○○○○○○○○○○○○○○○○○○○○

DB AR1 Vehicle Provenance

DB AR1 Owner's Guide Contents

Introduction

Vehicle Provenance iii

Warnings, Cautions and Notes vi

General Information vii

Reporting Safety Defects (USA) x

Reporting Safety Defects (Other Markets) x

Regular Checks xi

Glossary of Terms xii

Section 1 - Owner's Guide

Before Driving 1-A-1

Controls 1-B-1

Driving 1-C-1

Heating, Ventilation & Air Conditioning 1-D-1

Security System 1-E-1

Owner Maintenance 1-F-1

Specifications 1-G-1

Section 2 - Service Schedules & Service Records

Service Schedules 2-A-1

Service Records 2-B-1

Section 3 - Warranty and Emergency Service

Warranty 3-A-1

Aston Martin Emergency Service 3-B-1

Section 4 - Dealer Directory

Aston Martin Lagonda Ltd. Worldwide Dealer Directory 4-A-1

Section 5 - Index

Index 5-A-1

Warnings, Cautions and Notes

Within this Owner's Guide, advice is given at three levels, Warnings,

Cautions and Notes. Take particular care to read all relevant advice before

operating or servicing the vehicle.

Warnings

Procedures which must be followed precisely to help avoid the risk of

personal injury.

Example:

WARNING: Avoid touching the sides of the engine when working in the engine

compartment. The exhaust system will be hot if the engine has recently been run.

Cautions

Procedures which must be followed precisely to reduce the possibility of

damage to the vehicle.

Example:

Caution: Take care that hydraulic fluid does not contact the paint work during the

topping-up operation. Serious paint work damage can result. If a spillage does

occur, immediately flush the hydraulic fluid from the paint work with clean, fresh

water and then wipe with a clean damp cloth.

Notes

Procedures which will help to avoid difficulties in the operation of the

vehicle.

Example:

Note: The ignition must be switched on (position I or II) before the door mirrors

can be adjusted.

DB AR1 Owner's Guide

vii

General Information

DB AR1 Owner's Guide

This Owner's Guide forms part of the essential vehicle equipment for

homologation purposes and must remain with the vehicle at all times.

Important Safety Information

1. Always wear your seat belt.

2. Never drive under the influence of alcohol or drugs.

3. Always obey all speed and traffic laws and regulations. Never drive

faster than the posted speed limit or than conditions allow.

4. Be particularly careful driving on slippery or wet surfaces.

5. Your DB AR1 is a high performance car and has handling

characteristics that you may not be accustomed to. Familiarise

yourself with the car and always drive prudently, being aware of

your own limitations and the limitations of the vehicle. As with

other vehicles of this type, failure to operate the vehicle properly

can result in accident and injury.

6. Follow the maintenance schedule prescribed in this guide.

7. Never allow your DB AR1 to be driven by inexperienced drivers.

8. NeverallowyourDBAR1to beworkedon byunqualifiedindividuals.

9. To be sure that you are receiving qualified technical assistance

using correct parts, have all service work performed by an Aston

Martin dealer.

10. Use snow tyres in winter conditions

DB AR1 Owner's Guide

viii

Maintenance and Servicing

Regular maintenance and servicing is the responsibility of the owner.

Regular routine maintenance helps to prevent unnecessary breakdowns

and inconvenience. Each vehicle is given a full Pre-Delivery Inspection to

ensure that all systems function correctly and that the vehicle meets its

specifications. Failure to carry out maintenance at the recommended

intervals could result in deterioration of vehicle performance and possible

infringement of regulations. Such lack of proper maintenance may also

adversely affect your warranty protection.

Your Aston Martin dealer will arrange for appointments on a distance or time

interval basis to ensure that all routine and corrective maintenance work is

undertaken and recorded in the 'Service Schedules and Service Records'

section of this Owner's Guide.

Location of Components

When reading component descriptions or when

following procedures in this Owner's Guide, the

following convention is adopted for locating items

within the vehicle.

All directions are described as viewed from the

driver's seat. Thus the fuel filler cap indicated on this

diagram will be described as "located at the rear left

side of the vehicle".

DB AR1 Owner's Guide

Vehicle Identification

The Vehicle Identification Number (VIN) is shown in the left hand corner of

the windscreen.

The Vehicle Identification Plate attached to the right front inner wing is

model and market dependant but typically contains the following types of

information:

Maximum Gross Rear Axle Weight

Maximum Gross Front Axle Weight

Maximum Permitted Laden Weight

Vehicle Identification Number

Model Type Approval Number

Note: Gross axle weight is the maximum permissible weight on a single axle. The

sum of the axle weights must never exceed the maximum permitted laden weight

of 2152kg.

DB AR1 Owner's Guide

Reporting Safety Defects (USA)

If you believe that your vehicle has a defect which could cause a crash or

could cause injury or death, you should immediately inform the National

Highway Traffic Safety Administration (NHTSA) in addition to notifying

Aston Martin Lagonda (North America) Inc. 533 MacArthur Boulevard, NJ

07430-2326.

If NHTSA receives similar complaints, it may open an investigation, and if

it finds that a safety defect exists in a group of vehicles, it may order a recall

and remedy campaign. However, NHTSA cannot become involved in

individual problems between you, your Dealer, or Aston Martin Lagonda

(North America) Inc.

To contact NHTSA, you may either call the Auto Safety Hot-line toll-free at

1-800-424-9393 (or 366-0123 in Washington D.C. area) or write to:

NHTSA, U.S. Department of Transportation, Washington D.C. 20590.

You can also obtain other information about motor vehicle safety from the

Auto Safety Hot-line.

Reporting Safety Defects (Other Markets - Non-USA)

If you believe that your vehicle has a safety defect which could cause a crash

or could cause injury or death, you should immediately inform your Aston

Martin dealer or the manufacturers service operations department at the

address below:

Aston Martin, Service Operations, Banbury Road, Gaydon, WARWICK,

CV35 0DB, England

Telephone (44) (0)1926 644700

Facsimile (44) (0)1926 644733

DB AR1 Owner's Guide
