Assa Abloy LCU9101 Manuel utilisateur

LCU9101

One-door control unit

Innehåll

Introduction.............................................................. 3

Compatible accessories............................................. 3

Motor lock..................................................................... 3

Readers........................................................................ 3

LCU9101 ................................................................... 4

LCU9101 with relay board......................................... 5

Description of the board .................................................... 6

Indications....................................................................... 7

Settings with DIP switches ................................................. 8

DIP1 Telnet................................................................... 8

DIP2 Initiate motor lock .................................................. 8

DIP3 Balanced door monitor switch .................................. 8

DIP4 Fixed IP 192.168.1.250 ........................................... 8

DIP6 Master reset and test mode ..................................... 8

Installation ............................................................... 9

Installation Relay board DAC400RC64.................................. 9

Jumper links................................................................ 10

Terminal blocks ........................................................... 11

Initiating motor lock ..................................................... 13

Connection of accessories ................................................ 14

IG559101931C.doc

2 LCU9101

Connection of direct connected motor lock....................... 14

Balanced Door monitor switch........................................ 14

Day/Night function ....................................................... 15

Blocking input ............................................................. 15

Door monitor switch (magnet) serial/parallel.................... 15

PoE (Power over Ethernet) ............................................ 16

Configuration.......................................................... 17

Introduction ................................................................ 17

Automatic configuration................................................... 17

Conditions................................................................... 17

Check list.................................................................... 18

Manual configuration....................................................... 19

Installation of drivers for USB configuration ..................... 19

Terminal software ........................................................ 20

Configuration via the terminal software ........................... 20

Terminal commands ..................................................... 23

Key handling ............................................................... 26

Technical information ............................................. 27

Dimensions.................................................................... 28

Diagram ........................................................................ 28

LCU9101 3

Introduction

LCU9101 is an IP based control unit for one door with full function

for handling of reader, electrical lock and motor lock directly.

LCU9101 is a Hi-O prepared control unit in the ARX family that

communicates with SLL encryption and handles certificates, for

the highest possible security.

LCU9101 contains all that is necessary for the door. All

connections for e.g. motor lock, reader, electric strike, exit

button, door monitor switch, alarm, door automatic etc. are to be

made here.

Compatible accessories

Motor lock

References to motor lock refers to direct control as follows:

Assa Classic 8000S, 8001S

Assa Classic 8087S

Abloy 8164-II, 8165-II, EL650-II

Assa Evolution 810S, 811S

Readers

LCU9101 handles magnetic readers, EM prox readers, Mifare

readers and Wiegand readers via interface 6390IF or via ADD ON

board 400RW22.

4 LCU9101

LCU9101

LCU9101 5

LCU9101 with relay board

6 LCU9101

Description of the board

00068e30075f

WDG

Over load 12V Out

Over load RE1 12V Out

CL reader connected

RE 1

RE 2

LCU9101 7

Indications

There are LED’s on the board giving the following indications:

Power

(OK)

Green indication, indicates that system is powered.

WDG (OK) Blue indication, normal flash approx. 2 Hz

(2 flashes/sec.)

Unlit – LCU9101 is starting.

LED-lit – Error.

A(Yellow) Flashes slowly while the control unit tries to create

a connection with the ARX server. Lit when the

control unit is in contact with the ARX server.

B(Red) Lit when the control unit have messages to send to

the ARX server.

C(Green) Receiving data.

D(Green) Initiated CL motor lock found.

(Overload)

Lit when the over voltage protection to 12V out,

pin +12V/0V (feeding reader etc.) is triggered.

CL (Red) Lit when readers are connected to the CL+/CL-

port.

12v Over

(Red)

Lit when the over voltage protection to 12V, via

RE1 NO/C, is triggered.

LED RE1/RE2 lit when the relay takes hold.

Link Lit at link.

Unlit when there is no link.

100M Lit at 100 Mbit communication.

Unlit when there is no 100 Mbit communication.

ACT Flashes at activity on the Ethernet port.

Unlit when there is no activity on the Ethernet

port.

8 LCU9101

Settings with DIP switches

DIP1 Telnet

If DIP1 is in position ON when LU9101 is started it is possible to

communicate with the control unit via Telnet. Used when the

control unit should be configured via the Ethernet contact.

DIP2 Initiate motor lock

DIP2 in position ON initiate “Current Loop” motor locks to work

together with control unit LCU9101. When the motor lock is

installed DIP2 is set to position ON and the control unit is

restarted. When the control unit has restarted LED “D” will turn

green when the motor lock is found and initiated. Set DIP2 to OFF

and replace a possible "Learn" jumper link on the motor lock.

DIP3 Balanced door monitor switch

DIP3 in position ON and two resistors of 2,2KΩmounted on the

door monitor switch, then restart the control unit.

DIP4 Fixed IP 192.168.1.250

Can be used when you want to set up the control unit with the aid

of a TP cable, used together with DIP1.

DIP6 Master reset and test mode

When DIP6 is set to ON the control unit performs a master reset

on all parameters at upstart and resets LCU9101 to the factory

settings, it also sets LCU9101 in test mode.

Note! When this is done the LCU9101 will lose all settings and

new information must be loaded to the LCU9101. In the test

mode you can check installed readers and lock, but not the motor

lock. Normal position for DIP6 is OFF.

LCU9101 9

Installation

The following section describes the physical installation of the

control unit and connection of accessories.

Installation Relay board DAC400RC64

To get access to all outputs and inputs relay board DAC400RC64

must be connected.

Connection of relay board is made as follows:

1. Turn off the power to LCU9101

2. Dislocate LCU9101 from the box

3. Align the contact pieces toward each other

4. Make sure that the boards are in level with each other

5. Push the boards together

6. Snap the boards to the box

7. Turn the power ON

LCU9101 + RC64 are ready for operation

10 LCU9101

Jumper links

Potential free contact

Val av NO/NC relä 1

(Ellås relä)

00068e30075f

DIP-omkopplare

DIP1 Telnet ON/OFF

DIP2 I läge ON initiering motorlås

DIP3 Balanserad dörrbladslägeskontakt

DIP4 Fast IP 192.168.1.250

DIP5 Används ej

DIP6 Master reset samt testläge

12V ut (1=+, 2=-)

(12V Ut på relä 1)

12V In (1=+, 2=-)

(In spänning ut på relä 1)

Val av NO/NC relä 2

(LFK)

Hi-O terminering
