ASROCK Z68 Pro3 Manuel utilisateur

Z68 Pro3

User Manual

Version 1.0

Published April 2011

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identiﬁcation or explanation and to the owners’ beneﬁt, without intent to infringe.

Disclaimer:

Speciﬁcations and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or ﬁtness for a particular purpose.

In no event shall ASRock, its directors, ofﬁcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of proﬁts, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction......................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Speciﬁcations................................................................. 6

1.3 Motherboard Layout....................................................... 12

1.4 I/OPanel ...................................................................... 13

2 Installation........................................................... 15

2.1 Screw Holes................................................................... 15

2.2 Pre-installation Precautions ......................................... 15

2.3 CPU Installation............................................................. 16

2.4 Installation of Heatsink and CPU fan............................. 18

2.5 Installation of Memory Modules (DIMM)........................ 19

2.6 Expansion Slots (PCI and PCI Express Slots) .................... 21

2.7 Dual Monitor and Surround Display Features................ 22

2.8 ASRock Smart Remote Installation Guide..................... 25

2.9 Jumpers Setup .......................................................... 26

2.10 Onboard Headers and Connectors ............................ 27

2.11 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation .................................................................. 32

2.12 Serial ATA3 (SATA3) Hard Disks Installation ............. 32

2.13 Hot Plug and Hot Swap Functions for SATA / SATAII

HDDs ............................................................................ 33

2.14 Hot Plug and Hot Swap Functions for SATA3 HDDs .... 33

2.15 SATA / SATAII / SATA3 HDD Hot Plug Feature and

Operation Guide ........................................................ 34

2.16 Driver Installation Guide ............................................ 36

2.17 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM

64-bit With RAID Functions ....................................... 36

2.18 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit Without RAID Functions ................... 37

2.18.1 Installing Windows®XP / XP 64-bit Without RAID

Functions............................................................ 37

2.18.2 Installing Windows®7 / 7 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions............... 37

3 UEFI SETUP UTILITY ................................................. 38

3.1 Introduction.................................................................... 38

3.1.1 UEFI Menu Bar .................................................... 38

3.1.2 Navigation Keys................................................... 39

3.2 Main Screen................................................................... 39

3.3 OC Tweaker Screen ...................................................... 40

3.4 Advanced Screen........................................................... 44

3.4.1 CPU Conﬁguration............................................... 45

3.4.2 North Bridge Conﬁguration................................... 47

3.4.3 South Bridge Conﬁguration.................................. 49

3.4.4 Storage Conﬁguration.......................................... 50

3.4.5 Super IO Conﬁguration ........................................ 51

3.4.6 ACPI Conﬁguration............................................... 52

3.4.7 USB Conﬁguration ............................................... 53

3.5 Hardware Health Event Monitoring Screen ................... 54

3.6 Boot Screen................................................................... 55

3.7 Security Screen ............................................................. 56

3.8 Exit Screen .................................................................... 57

4 Software Support................................................. 58

4.1 Install Operating System................................................ 58

4.2 Support CD Information................................................. 58

4.2.1 Running Support CD............................................ 58

4.2.2 Drivers Menu........................................................ 58

4.2.3 Utilities Menu........................................................ 58

4.2.4 Contact Information.............................................. 58

Chapter 1: Introduction

Thank you for purchasing ASRock Z68 Pro3 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conﬁguration

guide to BIOS setup and information of the Support CD.

Because the motherboard speciﬁcations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modiﬁcations of this manual occur, the updated version

will be available on ASRock website without further notice. You may ﬁnd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speciﬁc information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock Z68 Pro3 Motherboard

(ATX Form Factor: 12.0-in x 8.3-in, 30.5 cm x 21.1 cm)

ASRock Z68 Pro3 Quick Installation Guide

ASRock Z68 Pro3 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-

bit, it is recommended to set the BIOS option in Storage Conﬁguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

1.2 Specifications

Platform - ATX Form Factor: 12.0-in x 8.3-in, 30.5 cm x 21.1 cm

- All Solid Capacitor design (100% Japan-made high-quality

Conductive Polymer Capacitors)

CPU - Supports 2nd Generation Intel®CoreTM i7 / i5 / i3 in

LGA1155 Package

- Supports Intel®Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

- Supports Hyper-Threading Technology (see CAUTION 1)

Chipset - Intel®Z68

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)

- 4 x DDR3 DIMM slots

- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066

non-ECC, un-buffered memory (see CAUTION 3)

- Max. capacity of system memory: 32GB (see CAUTION 4)

- Supports Intel®Extreme Memory Proﬁle (XMP)

Expansion Slot - 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)

- 3 x PCI Express 2.0 x1 slots

- 2 x PCI slots

Graphics * * Requires a Processor with Intel®Graphics Technology

- Intel®HD Graphics 2000/3000

- Pixel Shader 4.1, DirectX 10.1

- Max. shared memory 1759MB (see CAUTION 5)

- Three VGAOutput options: D-Sub, DVI-D and HDMI

(see CAUTION 6)

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI

(Compliant HDMI monitor is required) (see CAUTION 7)

- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI and HDMI ports

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efﬁcient Ethernet 802.3az

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x VGA/D-Sub Port

- 1 x VGA/DVI-D Port

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see CAUTION 8)

SATA3 - 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 10, RAID 5, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and "Hot Plug"

functions

USB3.0 - 2 x USB 3.0 ports by Etron EJ168A, support

USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 10, RAID 5, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

- 2 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature - 64MbAMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, IGPU, DRAM, PCH, CPU PLL, VTT, VCCSA

Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), ASRock

Software Suite (CyberLink DVD Suite - OEM and Trial;

Creative Sound Blaster X-Fi MB - Trial)

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 9)

- Instant Boot

- ASRock Instant Flash (see CAUTION 10)

- ASRock APP Charger (see CAUTION 11)

- SmartView (see CAUTION 12)

- ASRock XFast USB (see CAUTION 13)

- Lucid Virtu (see CAUTION 14)

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 15)

- ASRock U-COP (see CAUTION 16)

- Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see CAUTION 17)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

Auto-Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit compliant

Certiﬁcations - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 18)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

CAUTION!

1. About the setting of “Hyper Threading Technology”, please check page

45.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 19 for proper installation.

3. DDR3 frequency options may depend on the processor. Only K-Series

CPU can support DDR3 overclock to 2133 and 1866.

4. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®OS with 64-bit CPU, there is no such limita-

tion.

5. The maximum shared memory size is deﬁned by the chipset vendor and

is subject to change. Please check Intel®website for the latest informa-

tion.

6. You can choose to use two of the three monitors only. D-Sub, DVI-D and-

HDMI monitors cannot be enabled at the same time. Besides, with the

DVI-to-HDMI adapter, the DVI-D port can support the same features as

HDMIport.

7. xvYCC and Deep Color are only supported under Windows®7 64-bit /

7. Deep Color mode will be enabled only if the display supports 12bpc

in EDID. HBR is supported under Windows®7 64-bit / 7 / VistaTM 64-bit /

VistaTM.

8. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 13

for proper connection.

9. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ﬁne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In

Hardware Monitor, it shows the major readings of your system. In Fan

Control, it shows the fan speed and temperature for you to adjust. In

Overclocking, you are allowed to overclock CPU frequency for optimal

system performance. In OC DNA, you can save your OC settings as a

proﬁle and share with your friends. Your friends then can load the OC

proﬁle to their own system to get the same OC settings. In IES (Intelligent

Energy Saver), the voltage regulator can reduce the number of output

phases to improve efficiency when the CPU cores are idle without

sacrificing computing performance. Please visit our website for the

operation procedures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

10. ASRock Instant Flash is a BIOS ﬂash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems ﬁrst like MS-DOS or Windows®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS ﬁle to your USB ﬂash drive, ﬂoppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional ﬂoppy diskette or other complicated ﬂash utility. Please

be noted that the USB ﬂash drive or hard drive must use FAT32/16/12 ﬁle

system.

11. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply installing the APP Char-

ger driver, it makes your iPhone charged much quickly from your com-

puter and up to 40% faster than before. ASRock APP Charger allows you

to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

12. SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your

OS version is Windows®7 / 7 64 bit / VistaTM / VistaTM 64 bit, and your

browser version is IE8. ASRock website: http://www.asrock.com/Feature/

SmartView/index.asp

13. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

14. With Lucid Virtu technology, you can enjoy beneﬁts from both 3D perfor-

mance of the discrete GPU and advanced media features of Intel®HD

graphics.

15. Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU.

16. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC sys-

tem.

17. Combo Cooler Option (C.C.O.) provides the ﬂexible option to adopt three

different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.

Please be noticed that not all the 775 and 1156 CPU Fan can be used.

Autres manuels pour Z68 Pro3

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK WOLFDALE1333-DVI Manuel utilisateur

ASROCK

ASROCK P43 PRO USB3 Manuel utilisateur

ASROCK

ASROCK B75M-GL R2.0 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z97X Killer Series Manuel utilisateur

ASROCK

ASROCK B450M Steel Legend Manuel utilisateur

ASROCK

ASROCK P4I65G Manuel utilisateur

ASROCK

ASROCK B760M-C Manuel utilisateur

ASROCK

ASROCK UTX-110 Manuel de service

ASROCK

ASROCK G31M-GS - R2.0 Manuel utilisateur

ASROCK

ASROCK H310CM-HDVP/DASH Manuel utilisateur

ASROCK

ASROCK P4S55FX Manuel utilisateur

ASROCK

ASROCK A55M-HVS Manuel utilisateur

ASROCK

ASROCK J1900D2Y Manuel utilisateur

ASROCK

ASROCK M3A760GMH Manuel utilisateur

ASROCK

ASROCK Q1900B-ITX Manuel utilisateur

ASROCK

ASROCK E3C236D4U Manuel utilisateur

ASROCK

ASROCK X299 GAMING i9 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Manuel utilisateur

ASROCK

ASROCK Phantom Gaming 4 Z690 Manuel utilisateur

ASROCK

ASROCK A770DE Manuel utilisateur

ASROCK

ASROCK FM2A78M-DG3+ Manuel utilisateur

ASROCK

ASROCK Z490 Taichi Manuel utilisateur

ASROCK

ASROCK N4200-NUC IPC Manuel utilisateur

ASROCK

ASROCK A55DEL Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
