ASROCK SBC-310 Manuel utilisateur

SBC-310

SBC-311

User Manual

Version 1.0

Published February 2015

Version 1.0

Published February 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMITM and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction ....................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications................................................................. 6

1.3 Motherboard Layout....................................................... 8

1.4 I/O Panel........................................................................ 10

2 Installation ......................................................... 11

2.1 Screw Holes................................................................... 11

2.2 Pre-installation Precautions ........................................... 11

2.3 Installation of Memory Modules (SO-DIMM).................. 12

2.4 Expansion Slots (mini-PCIe and mini-PCIe/mini-SATA

Slots).............................................................................. 13

2.5 Jumpers Setup............................................................... 14

2.6 Onboard Headers and Connectors................................ 16

3 UEFI SETUP UTILITY......................................... 21

3.1 Introduction .................................................................... 21

3.1.1 UEFI Menu Bar .................................................... 21

3.1.2 Navigation Keys ................................................... 22

3.2 Main Screen................................................................... 22

3.3 Advanced Screen........................................................... 24

3.3.1 CPU Conguration ............................................... 25

3.3.2 Chipset Conguration........................................... 27

3.3.3 Storage Conguration .......................................... 29

3.3.4 Intel(R) Rapid Start Technology ........................... 30

3.3.5 AMT Conguration ............................................... 31

3.3.6 Super IO Conguration ........................................ 32

3.3.7 ACPI Conguration............................................... 33

3.3.8 USB Conguration ............................................... 34

3.3.9 Voltage Conguration........................................... 35

3.4 Hardware Health Event Monitoring Screen ................... 36

3.5 Boot Screen ................................................................... 37

3.6 Security Screen ............................................................. 39

3.7 Exit Screen .................................................................... 40

4 Software Support .............................................. 41

4.1 Install Operating System................................................ 41

4.2 Support CD Information ................................................. 41

4.2.1 Running Support CD............................................ 41

4.2.2 Drivers Menu........................................................ 41

4.2.3 Utilities Menu........................................................ 41

4.2.4 Contact Information.............................................. 41

Chapter 1: Introduction

Thank you for purchasing ASRock SBC-310 / SBC-311 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control. It

delivers excellent performance with robust design conforming to ASRock’s commit-

ment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock SBC-310 / SBC-311 Motherboard

(3.5” SBC (5.8-in x 4.0-in) / (146 x 102 mm))

ASRock SBC-310 / SBC-311 Driver CD

ASRock SBC-310 / SBC-311 Jumper Setting Instruction

1.2 Specications

Form

Factor Dimensions 3.5” SBC (5.8-in x 4.0-in) / (146 x 102 mm)

Processor

System

CPU

SBC-310:

BGA type for Intel®CoreTM i7-4650/i5-4300U

Haswell ULT Quad/Dual core MCP processor

SBC-311:

BGA type for Intel®CoreTM i3-4010/ Celeron®

2980U Haswell ULT Dual core MCP processor

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L2 Cache (By CPU)

Chipset (By CPU)

BIOS UEFI

Expansion

Slot

PCI 0

Mini-PCIe 1 (Half Size) + 1 (Full Size ) shared with mSATA

mSATA 1 (Full Size ) shared with SATA2

PCIe 0

CFast Card

Socket 0

Memory

Technology Single Channel DDR3L 1333/1600 MHz SDRAM

Max. 8GB

Socket 1 x SO-DIMM

Graphics

Controller Intel®HD Graphics (By CPU)

VRAM Shared Memory

VGA 0

LVDS 1 co-lay with eDP

HDMI Supports HDMI 1.4a, supported with Level Shift,

resolution up to 4096x2304 (1 x HDMI)

DVI 0

DisplayPort 0

Multi Display Yes (Three Display)

Ethernet

Interface 10/100/1000 Mbps

Controller

GbE LAN1: Realtek RTL8111G, LAN2: Intel®

I218LM (4300U SKU)

GbE LAN1: Realtek RTL8111G, LAN2: Intel®

I218V (2980U SKU)

Connector 2 x RJ-45

SATA

Max Data

Transfer

Rate

SATA3 (6.0Gb/s)

Rear I/O

VGA 0

HDMI 2

DVI-I/D 0

DisplayPort 0

Ethernet 2

USB 4 x USB 3.0

Audio 0

Serial 0

e-SATA 0

PS/2 0

Internal

Connector

USB 4 (2 x USB Header 2.54mm pitch)

LVDS/

Inverter 24 bit dual channel LVDS co-lay with eDP

VGA 0

Serial 4 (2 RS-232/422/485, 2 RS-232)

SATA 2 x SATA3 (6.0Gb/s)

m-SATA 1 (shared)

Mini-PCIe 1

Parallel 0

IrDA 0

GPIO 4 x GPI + 4 x GPO

SATA PWR

Output Con 1

Speaker

Header 1

Watchdog

Timer

Output Output from super I/O to drag RESETCON#

Interval 256 Segments, 0,1,2…255 Sec/Min

Power

Requirements

Input PWR DC 9-36 input

Power On

AT/ATX Supported

AT: Directly PWR on as power input ready

ATX: Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.3 Motherboard Layout

BIOS

Chip

FAN1

JGPIO1

mini-PCIe

LPC1

SPEAKER1

LAN1

HDMI1

BLT_VOL1

mini-PCIe / mini-SATA

CI1

SATA_PWR1

LVDS 1

BLT_PWR1

USB 3.0

T: USB1

B: USB0

COM1 COM2 COM3 COM4

JGPIO_PWR1

CLRMOS1

USB8_9

BUZZ1

DDR3 (Support DDR3L Only)

BKT_PWR1

PNL_PWR1

SATA3_1

SATA3_2

BLT_PWM1

USB 3.0

T: USB3

B: USB2

HDMI2

LAN2

CI2

MSATA_SEL1

USB6_7

ATX1 2V 1

PWR_COM1

PWR_COM2

PWR_COM3

PWR_COM4

JGPIO_SET1

HD_AUDIO1

PWR_JP1

HDLED RESET

PLED PWRBTN

PANEL1

1 : Clear CMOS Header

2 :

4-Pin FAN Connector (+12V)

3 :

mSATA Select

4 : 2-Pin Buzzer Header

5 :

USB2.0 Headers

(USB6_7, USB8_9)

6 : Backlight & Amp Volume Control

(BLT_VOL1)

7 : Inverter Power Control Wafer (BLT_PWR1)

8 : Backlight Control Level (BLT_PWM1)

: Backlight Power Select

(LCD_BLT_VCC)

(BKT_PWR1)

10 : SATA3 Connectors (SATA3_1, SATA3_2)

11 : Panel Power Selection (LCD_VCC) (PNL_PWR1)

2 : SATA Power Output Connector

13 :

System Panel Header

14 : ATX/AT Mode Select

15 : ATX Power Connector (Input 9V-36V)

16 : LPC Header

17 : COM Port Header (COM4)

18 : COM Port Pin9 PWR Setting Jumper (PWR_COM4 (For COM Port4))

19 : COM Port Header (COM3)

20 : COM Port Pin9 PWR Setting Jumper (PWR_COM3 (For COM Port3))

21 : COM Port Header (COM2)

22 : COM Port Pin9 PWR Setting Jumper (PWR_COM2 (For COM Port2))

23 : COM Port Header (COM1)

24 : COM Port Pin9 PWR Setting Jumper (PWR_COM1 (For COM Port1))

: GPIO Default Setting

26 : Digital Input / Output Power Select

27 : Digital Input / Output Pin Header

28 : 3W Audio AMP Output Wafer

29 : Chassis Intrusion Headers

(CI1, CI2)

30 :

Front Panel Audio Header

31 : LVDS Panel Connector

1.4 I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

1 USB 3.0 Ports (USB01)

2 USB 3.0 Ports (USB23)

3 HDMI Port (HDMI1)

4 HDMI Port (HDMI2)

5 LAN RJ-45 Port (LAN1)*

6 LAN RJ-45 Port (LAN2)*

ACT/LINK

LED

SPEED

LED

LAN Port

12 4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK Z97 Pro3 Manuel utilisateur

ASROCK

ASROCK 4CORE1600P35-WIFI - V1.0 Manuel utilisateur

ASROCK

ASROCK 890FX Deluxe5 Manuel utilisateur

ASROCK

ASROCK P55 PRO/USB3 - Manuel utilisateur

ASROCK

ASROCK IMB-151N Manuel utilisateur

ASROCK

ASROCK PHANTOM GAMING B650E PG-ITX WiFi Manuel utilisateur

ASROCK

ASROCK H61M-DGS Manuel utilisateur

ASROCK

ASROCK Z170 Extreme3 Manuel utilisateur

ASROCK

ASROCK IMB-140 Plus Manuel utilisateur

ASROCK

ASROCK H77 Pro4/MVP Manuel utilisateur

ASROCK

ASROCK 775i915P-SATA2 Manuel utilisateur

ASROCK

ASROCK X99M Extreme4 Manuel utilisateur

ASROCK

ASROCK G41M-VGS3 Manuel utilisateur

ASROCK

ASROCK B150M Pro4V Manuel utilisateur

ASROCK

ASROCK R-4130 Manuel utilisateur

ASROCK

ASROCK ALIVEN570SLI-ESATA2 Manuel utilisateur

ASROCK

ASROCK N3150DC-ITX Manuel utilisateur

ASROCK

ASROCK M3N78D Manuel utilisateur

ASROCK

ASROCK H510M-HDV Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z170 Gaming K4 Series Manuel utilisateur

ASROCK

ASROCK IMB-A1000 Manuel utilisateur

ASROCK

ASROCK H61M-HP4 Manuel utilisateur

ASROCK

ASROCK EPC612D8A Manuel utilisateur

ASROCK

ASROCK Z97 Extreme4 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
