ASROCK Q1900TM-ITX Manuel utilisateur

User Manual

Q1900TM-ITX

Version 1.0

Published May 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

Chapter 2 Installation 9

2.1 Installing Memory Modules (SO-DIMM) 10

2.2 Expansion Slots (PCI Express Slots) 12

2.3 Jumpers Setup 13

2.4 Onboard Headers and Connectors 14

Chapter 3 Software and Utilities Operation 20

3.1 Installing Drivers 20

3.2 A-Tuning 21

3.3 Intel® Smart Connect Technology 23

3.4 ASRock APP Shop 28

3.4.1 UI Overview 28

3.4.2 Apps 29

3.4.3 BIOS & Drivers 32

3.4.4 Setting 33

3.5 Start8 35

Chapter 4 UEFI SETUP UTILITY 38

4.1 Introduction 38

4.1.1 UEFI Menu Bar 38

4.1.2 Navigation Keys 39

4.2 Main Screen 40

4.3 Advanced Screen 41

4.3.1 CPU Conguration 42

4.3.2 Chipset Conguration 43

4.3.3 Storage Conguration 45

4.3.4 Intel® Smart Connect Technology 46

4.3.5 Super IO Conguration 47

4.3.6 ACPI Conguration 48

4.3.7 USB Conguration 50

4.3.8 Trusted Computing 51

4.4 Tools 52

4.5 Hardware Health Event Monitoring Screen 54

4.6 Boot Screen 55

4.7 Security Screen 57

4.8 Exit Screen 58

Q1900TM-ITX

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Q1900TM-ITX motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock Q1900TM-ITX Motherboard (Mini-ITX Form Factor)

• ASRock Q1900TM-ITX Quick Installation Guide

• ASRock Q1900TM-ITX Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x SATA 1 to 2 Power Cable (Optional)

• 2 x I/O Panel Shields

• 1 x WiFi Module Screw

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

Q1900TM-ITX

PB 2

English

1.2 Specications

Platform • in Mini-ITX Form Factor (Compatible with Mini-ITX)

• ASRock DuraCap (2.5 x longer life time) (100% Japan-made

high-quality conductive polymer capacitors)

• High Density Glass Fabric PCB

CPU • Intel® Quad-Core Processor J1900 (2 GHz)

Memory • Dual Channel DDR3/DDR3L Memory Technology

• 2 x DDR3/DDR3L SO-DIMM Slots

• Supports DDR3/DDR3L 1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 16GB (see CAUTION)

Expansion

Slot

• 1 x PCI Express 2.0 x1 Slot

• 1 x mini-PCI Express Slot (Bluetooth function in WiFi

module is not supported)

Graphics

• Intel® 7th generation (Gen 7) graphics (Supports Intel® Quick

Sync Video)

• DirectX 11.0, Pixel Shader 5.0

• ree graphics output options: D-Sub, HDMI and LVDS

• Supports HDMI with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports LVDS with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI Port

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Port

3 4

English

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Qualcomm® Atheros® AR8171

• Supports Qualcomm® Atheros® Security Wake On Internet

Technology

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x DC Jack (Compatible with the 19V power adapter)

• 1 x D-Sub Port

• 1 x HDMI Port

• 3 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 1 x USB 3.0 Port (Supports ESD Protection (ASRock Full

Spike Protection))

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Microphone / Front Speaker (Supports

SPDIF Optical)

Storage • 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

Connector • 1 x Backlight Power Selection Jumper

• 1 x Panel Power Selection Jumper

• 1 x Backlight Control Header

• 1 x Digital Input / Output Pin Header

Q1900TM-ITX

3 4

English

• 1 x Digital Input / Output Power Selection Jumper

• 1 x Home eater PC Header

• 1 x Monitor Switch Header

• 1 x Digital MIC Header

• 1 x 3W Audio AMP Output Wafer Header

• 1 x LVDS Connector

• 1 x CIR Header

• 1 x COM Port Header

• 1 x Power LED Header

• 1 x TPM Header

• 1 x CPU Fan Connector (4-pin)

• 1 x Chassis Fan Connector (4-pin)

• 1 x SATA Power Connector

• 1 x Front Panel Audio Connector

• 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD

Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header by Etron EJ188 (Supports 2 USB 3.0 ports)

(Supports ESD Protection (ASRock Full Spike Protection))

BIOS

Feature

• 64Mb AMI UEFI Legal BIOS with GUI support

• Supports Plug and Play

• ACPI 1.1 compliant wake up events

• SMBIOS 2.3.1 support

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-

bit / 7 32-bit / 7 64-bit

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP Ready (ErP/EuP ready power supply is required)

5 6

English

* For detailed product information, please visit our website: http://www.asrock.com

Due to limitation, the actual memory size may be less than 4GB for the reservation for

system usage under Windows® 32-bit operating systems. Windows® 64-bit operating systems

do not have such limitations. You can use ASRock XFast RAM to utilize the memory that

Windows® cannot use.
