ASROCK IMB-171-D Manuel utilisateur

IMB-171-D

IMB-171-L

IMB-161-D

IMB-161-L

User Manual

Version 1.0

Published February 2013

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction........................................................ 5

1.1 Package Contents ......................................................... 5

1.2 Specications (IMB-171-D)............................................ 6

1.3 Specications (IMB-171-L) ............................................ 8

1.4 Specications (IMB-161-D)............................................ 10

1.5 Specications (IMB-161-L) ............................................ 12

1.6 Motherboard Layout (IMB-171-D / IMB-171-L /

IMB-161-D / IMB-161-L) ................................................ 14

1.7 I/O Panel (IMB-171-D) ................................................... 16

1.8 I/O Panel (IMB-171-L).................................................... 17

1.9 I/O Panel (IMB-161-D) ................................................... 18

1.10 I/O Panel (IMB-161-L).................................................. 19

2 Installation.......................................................... 20

2.1 Screw Holes................................................................... 20

2.2 Pre-installation Precautions ........................................... 20

2.3 Installation of Memory Modules (DIMM) ........................ 21

2.4 Expansion Slot .............................................................. 22

2.5 Jumpers Setup............................................................... 23

2.6 Onboard Headers and Connectors................................ 24

2.7 Serial ATA2 (SATA2) / Serial ATA3 (SATA3) Hard Disks

Installation...................................................................... 29

2.8 Hot Plug and Hot Swap Functions for SATA2 / SATA3

HDDs ............................................................................ 29

2.9 Driver Installation Guide ............................................ 30

3 UEFI SETUP UTILITY ................................................ 31

3.1 Introduction .................................................................... 31

3.1.1 UEFI Menu Bar .................................................... 31

3.1.2 Navigation Keys ................................................... 32

3.2 Main Screen................................................................... 32

3.3 Advanced Screen........................................................... 33

3.3.1 CPU Conguration ............................................... 34

3.3.2 North Bridge Conguration................................... 37

3.3.3 South Bridge Conguration.................................. 38

3.3.4 Storage Conguration .......................................... 39

3.3.5 Intel(R) Rapid Start Technology ........................... 40

3.3.6 Intel(R) Smart Connect Technology ..................... 41

3.3.7 Super IO Conguration ........................................ 42

3.3.8 ACPI Conguration............................................... 43

3.3.9 USB Conguration ............................................... 44

3.3.10 Trusted Computing............................................. 45

3.4 Hardware Health Event Monitoring Screen ................... 46

3.5 Boot Screen ................................................................... 47

3.6 Security Screen ............................................................. 49

3.7 Exit Screen .................................................................... 50

4 Software Support................................................ 51

4.1 Install Operating System................................................ 51

4.2 Support CD Information ................................................. 51

4.2.1 Running Support CD............................................ 51

4.2.2 Drivers Menu........................................................ 51

4.2.3 Utilities Menu........................................................ 51

4.2.4 Contact Information.............................................. 51

Chapter 1: Introduction

Thank you for purchasing ASRock IMB-171-D / IMB-171-L / IMB-161-D / IMB-161-L

motherboard, a reliable motherboard produced under ASRock’s consistently strin-

gent quality control. It delivers excellent performance with robust design conforming

to ASRock’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock IMB-171-D / IMB-171-L / IMB-161-D / IMB-161-L Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock IMB-171-D / IMB-171-L / IMB-161-D / IMB-161-L Driver CD

ASRock IMB-171-D / IMB-171-L / IMB-161-D / IMB-161-L Jumper setting instruc-

tion

2 x Serial ATA (SATA) Data Cables

1 x Serial ATA (SATA) HDD Power Cable

2 x COM Port Cables

1 x I/O Panel Shield

1.2 Specifications (IMB-171-D)

Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU Socket LGA1155 for Intel®Core i7/i5/i3/Celeron

(Sandy Bridge and Ivy Bridge)

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L3 Cache (By CPU)

Chipset Q77

BIOS UEFI

Expansion

Slot

PCI 0

Mini-PCIe 1 (Half Size)

mSATA 0

PCIe 1 (x16) (IVY Bridge: Gen3; Sandy Bridge: Gen2)

CFast Card

Socket 0

Memory

Technology Dual Channel DDR3 1066/1333/1600 MHz

SDRAM

Max. 16GB

Socket 2 x SO-DIMM

Graphics

Controller Intel® HD Graphics (By CPU)

VRAM Shared Memory

VGA No

LVDS No

HDMI Supports HDMI 1.4a, max resolution 1920x1200

DVI Support max resolution 1920x1200

Display Port Supports max resolution 2560x1600

Multi Display Yes

Ethernet

Ethernet 10/100/1000 Mbps

Controller GbE LAN1:Intel®82583V, LAN2: Intel®82579LM

Connector RJ-45 x 2 w/ LED

SATA

Max Data

Transfer

Rate

2 x SATA2 (3.0Gb/S), 2 x SATA3 (6.0Gb/S),

Supports RAID0/1/5/10

Rear I/O

VGA 0

DVI 1 (DVI-I)

HDMI 1

DisplayPort 1

Ethernet 2

USB 6 (2 x USB 2.0 compliant, 4 x USB 3.0

compliant)

Audio 2 (Mic-in, Line-out)

Serial 2 (RS-232/422/485)

PS/2 1 (Combo)

Internal

Connector

USB 4 (USB 2.0 compliant)

LVDS/

Inverter 0

VGA 0

Serial 4 (RS-232)

SATA 2 x SATA2 (3.0Gb/s), 2 x SATA3 (6.0Gb/s),

Supports RAID0/1/5/10

mPCIe 1

Parallel 0

mSATA 0

IrDA 0

GPIO 8-bit 4 x GPI + 4 x GPO

SATA PWR

Output Con 0

Speaker

Header 0

Watchdog

Timer

Output Output from super I/O to drag RESETCON#

Interval 256 Segments, 0,1,2…255 Sec/Min

Power

Requirements

Input PWR ATX PWR (24+4 pin)

Power On

AT/ATX Supported

-AT : Directly PWR on as power input ready

-ATX : Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.3 Specifications (IMB-171-L)

Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU Socket LGA1155 for Intel®Core i7/i5/i3/Celeron

(Sandy Bridge and Ivy Bridge)

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L3 Cache (By CPU)

Chipset Q77

BIOS UEFI

Expansion

Slot

PCI 0

Mini-PCIe 1 (Half Size)

mSATA 0

PCIe 1 (x16) (IVY Bridge: Gen3; Sandy Bridge: Gen2)

CFast Card

Socket 0

Memory

Technology Dual Channel DDR3 1066/1333/1600 MHz

SDRAM

Max. 16GB

Socket 2 x SO-DIMM

Graphics

Controller Intel® HD Graphics (By CPU)

VRAM Shared Memory

VGA Supports max resolution 2048x1536

LVDS Dual Channel 24-bit, support max resolution

1920x1200

HDMI Supports HDMI 1.4a, max resolution 1920x1200

DVI No

Display Port No

Multi Display Yes

Ethernet

Ethernet 10/100/1000 Mbps

Controller GbE LAN1:Intel®82583V, LAN2: Intel®82579LM

Connector RJ-45 x 2 w/ LED

SATA

Max Data

Transfer

Rate

2 x SATA2 (3.0Gb/S), 2 x SATA3 (6.0Gb/S),

Supports RAID0/1/5/10

Rear I/O

VGA 1

DVI 1

HDMI 1

DisplayPort 0

Ethernet 2

USB 6 (2 x USB 2.0 compliant, 4 x USB 3.0

compliant)

Audio 2 (Mic-in, Line-out)

Serial 2 (RS-232/422/485)

PS/2 1 (Combo)

Internal

Connector

USB 4 (USB 2.0 compliant)

LVDS/

Inverter 1/1

VGA 0

Serial 4 (RS-232)

SATA 2 x SATA2 (3.0Gb/s), 2 x SATA3 (6.0Gb/s),

Supports RAID0/1/5/10

mPCIe 1

Parallel 0

mSATA 0

IrDA 0

GPIO 8-bit 4 x GPI + 4 x GPO

SATA PWR

Output Con 0

Speaker

Header 1

Watchdog

Timer

Output Output from super I/O to drag RESETCON#

Interval 256 Segments, 0,1,2…255 Sec/Min

Power

Requirements

Input PWR ATX PWR (24+4 pin)

Power On

AT/ATX Supported

-AT : Directly PWR on as power input ready

-ATX : Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.4 Specifications (IMB-161-D)

Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU Socket LGA1155 for Intel®Core i7/i5/i3/Celeron

(Sandy Bridge and Ivy Bridge)

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L3 Cache (By CPU)

Chipset H61

BIOS UEFI

Expansion

Slot

PCI 0

Mini-PCIe 1 (Half Size)

mSATA 0

PCIe 1 (x16) (IVY Bridge: Gen3; Sandy Bridge: Gen2)

CFast Card

Socket 0

Memory

Technology Dual Channel DDR3 1066/1333/1600 MHz

SDRAM

Max. 16GB

Socket 2 x SO-DIMM

Graphics

Controller Intel® HD Graphics (By CPU)

VRAM Shared Memory

VGA No

LVDS No

HDMI Supports HDMI 1.4a, max resolution 1920x1200

DVI Support max resolution 1920x1200

Display Port Supports max resolution 2560x1600

Multi Display Yes

Ethernet

Ethernet 10/100/1000 Mbps

Controller GbE LAN1:Intel®82583V, LAN2: Intel®82579V

Connector RJ-45 x 2 w/ LED

SATA

Max Data

Transfer

Rate

4 x SATA2 (3.0Gb/S)

Rear I/O

VGA 0

DVI 1 (DVI-I)

HDMI 1

DisplayPort 1

Ethernet 2

Autres manuels pour IMB-171-D

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P55M PRO - Manuel utilisateur

ASROCK

ASROCK Z790 Series Manuel utilisateur

ASROCK

ASROCK WOLFDALE1333-GLAN/M2 Manuel utilisateur

ASROCK

ASROCK CONROE1333-DVI/H Manuel utilisateur

ASROCK

ASROCK 890GMH/USB3 Manuel utilisateur

ASROCK

ASROCK E350M1-USB3 - Manuel utilisateur

ASROCK

ASROCK B450M/ac Manuel utilisateur

ASROCK

ASROCK A520M/ac Manuel utilisateur

ASROCK

ASROCK B550M-ITX/AC Manuel utilisateur

ASROCK

ASROCK 775i45GV Manuel utilisateur

ASROCK

ASROCK H110M-DVS/D3 Manuel utilisateur

ASROCK

ASROCK H81M-HG4 Manuel utilisateur

ASROCK

ASROCK CONROE945G-DVI Manuel utilisateur

ASROCK

ASROCK G43TWINS-FULLHD Manuel utilisateur

ASROCK

ASROCK 785G Pro Manuel utilisateur

ASROCK

ASROCK FM2A75M-DGS R2.0 Manuel utilisateur

ASROCK

ASROCK P67 Extreme4 Gen3 Manuel utilisateur

ASROCK

ASROCK K10N750SLI-110DB Manuel utilisateur

ASROCK

ASROCK 775Dual-VSTA Manuel utilisateur

ASROCK

ASROCK Z77 Extreme4 Manuel utilisateur

ASROCK

ASROCK H81M-ITX Manuel utilisateur

ASROCK

ASROCK A770DE Manuel utilisateur

ASROCK

ASROCK H81M-DGS Manuel utilisateur

ASROCK

ASROCK FM2A75M-ITX R2.0 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
