ASROCK Fatality X370 Manuel utilisateur

Version 1.0

Published June 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I actually

played competitive billiards in professional tournaments and won four or ve games o guys

who played at the highest level. I actually thought of making a career of it, but at that young

age situations change rapidly. Because I’ve been blessed with great hand-eye coordination and

a grasp of mathematics (an important element in video gaming) I gravitated to that activity.

GOING PRO

I started professional gaming in 1999 when I entered the CPL (Cyberathlete Professional

League) tournament in Dallas and won $4,000 for coming in third place. Emerging as one

of the top players in the United States, a company interested in sponsoring me ew me to

Sweden to compete against the top 12 players in the world. I won 18 straight games, lost

none, and took rst place, becoming the number one ranked Quake III player in the world

in the process. Two months later I followed that success by traveling to Dallas and defending

my title as the world’s best Quake III player, winning the $40,000 grand prize. From there

I entered competitions all over the world, including Singapore, Korea, Germany, Australia,

Holland and Brazil in addition to Los Angeles, New York and St. Louis.

WINNING STREAK

I was excited to showcase my true gaming skills when defending my title as CPL

Champion of the year at the CPL Winter 2001 because I would be competing in a totally

dierent rst person shooter (fps) game, Alien vs. Predator II. I won that competition and

walked away with a new car. e next year I won the same title playing Unreal Tournament

2003, becoming the only three-time CPL champion of the year. And I did it playing a

different game each year, something no one else has ever done and a feat of which I am

extremely proud.

At QuakeCon 2002, I faced o against my rival ZeRo4 in one of the most highly

anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at Quakecon

2004, I became the World’s 1st Doom3 Champion by defeating Daler in a series of very

challenging matches and earning $25,000 for the victory.

Since then Fatal1ty has traveled the globe to compete against the best in the world, winning

prizes and acclaim, including the 2005 CPL World Tour Championship in New York City for

a $150,000 rst place triumph. In August 2007, Johnathan was awarded the rst ever Lifetime

Achievement Award in the four year history of the eSports-Award for “showing exceptional

sportsmanship, taking part in shaping eSports into what it is today and for being the prime

representative of this young sport. He has become the gurehead for eSports worldwide”.

Fatal1ty Story

LIVIN’ LARGE

Since my rst big tournament wins, I have been a “Professional Cyberathlete”, traveling the

world and livin’ large with lots of International media coverage on outlets such as MTV,

ESPN and a 60 Minutes segment on CBS to name only a few. It's unreal - it's crazy. I’m living

a dream by playing video games for a living. I’ve always been athletic and took sports like

hockey and football very seriously, working out and training hard. is discipline helps me

become a better gamer and my drive to be the best has opened the doors necessary to become

a professional.

A DREAM

Now, another dream is being realized – building the ultimate gaming computer, made

up of the best parts under my own brand. Quality hardware makes a huge difference in

competitions…a couple more frames per second and everything gets really nice. It’s all about

getting the computer processing faster and allowing more uid movement around the maps.

My vision for Fatal1ty hardware is to allow gamers to focus on the game without worrying

about their equipment, something I’ve preached since I began competing. I don’t want to

worry about my equipment. I want to be there – over and done with - so I can focus on

the game. I want it to be the fastest and most stable computer equipment on the face of the

planet, so quality is what Fatal1ty Brand products represent.

Johnathan “Fatal1ty” Wendel

e Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trademarks of Fatal1ty, Inc., and are used

owners.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 9

1.5 WiFi-802.11ac Module and ASRock WiFi 2.4/5 GHz

Antenna 11

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (DIMM) 24

2.4 Expansion Slot (PCI Express Slot) 26

2.5 Jumpers Setup 27

2.6 Onboard Headers and Connectors 28

Chapter 3 Software and Utilities Operation 32

3.1 Installing Drivers 32

3.2 F-Stream 33

3.2.1 Installing F-Stream 33

3.2.2 Using F-Stream 33

3.3 ASRock Live Update & APP Shop 36

3.3.1 UI Overview 36

3.3.2 Apps 37

3.3.3 BIOS & Drivers 40

3.3.4 Setting 41

3.4 Creative SoundBlaster Cinema3 42

3.5 ASRock RGB LED Utility 43

Chapter 4 UEFI SETUP UTILITY 44

4.1 Introduction 44

4.1.1 UEFI Menu Bar 44

4.1.2 Navigation Keys 45

4.2 Main Screen 46

4.3 OC Tweaker Screen 47

4.4 Advanced Screen 49

4.4.1 CPU Conguration 50

4.4.2 North Bridge Conguration 51

4.4.3 South Bridge Conguration 52

4.4.4 Storage Conguration 53

4.4.5 Super IO Conguration 54

4.4.6 ACPI Conguration 55

4.4.7 Trusted Computing 56

4.4.8 AMD PBS 57

4.5 Tools 58

4.6 Hardware Health Event Monitoring Screen 60

4.7 Security Screen 62

4.8 Boot Screen 63

4.9 Exit Screen 66

Fatal1ty X370 Gaming-ITX/ac Series

English

Chapter 1 Introduction

ank you for purchasing ASRock Fatal1ty X370 Gaming-ITX/ac Series

motherboard, a reliable motherboard produced under ASRock’s consistently

stringent quality control. It delivers excellent performance with robust design

conforming to ASRock’s commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock Fatal1ty X370 Gaming-ITX/ac Series Motherboard (Mini-ITX Form Factor)

• ASRock Fatal1ty X370 Gaming-ITX/ac Series Quick Installation Guide

• ASRock Fatal1ty X370 Gaming-ITX/ac Series Support CD

• 1 x I/O Panel Shield

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x ASRock WiFi 2.4/5 GHz Antenna (Optional)

• 1 x Screw for M.2 Socket (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard,

please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well.

ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Mini-ITX Form Factor

• 2oz Copper PCB

CPU • Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)

and Ryzen Series CPUs (Summit Ridge)

• Digi Power design

• 8 Power Phase design

• Supports 95W Water Cooling

Chipset • AMD Promontory X370

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 DIMM Slots

• AMD Ryzen series CPUs support DDR4 3200+(OC)/2933

(OC)/2667/2400/2133 ECC & non-ECC, un-buered memo-

ry*

• AMD 7th Gen A-Series APUs support DDR4 2400/2133 ECC

& non-ECC, un-buered memory*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 24 for DDR4 UDIMM maximum frequency

support.

• Max. capacity of system memory: 32GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

AMD Ryzen series CPUs

• 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*

AMD 7th A-Series APUs

• 1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*

* Supports NVMe SSD as boot disks

• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-

802.11ac module (on the rear I/O)

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RadeonTM R-Series Graphics in A-series

APU*

Fatal1ty X370 Gaming-ITX/ac Series

English

* Actual support may vary by CPU

• DirectX 12, Pixel Shader 5.0

• Max. shared memory 2GB

• Supports 2 x HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Ports (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI Ports

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC1220

Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection

• Nichicon Fine Gold Series Audio Caps

• 120dB SNR DAC with Dierential Amplier

• Pure Power-In

• Direct Drive Technology

• PCB Isolate Shielding

• Impedance Sensing on Line Out port

• Individual PCB Layers for R/L Audio Channel

• Gold Audio Jacks

• Supports Creative SoundBlaster Cinema3

LAN • Gigabit LAN 10/100/1000 Mb/s

• GigaLAN Intel® I211AT

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Wireless

LAN

• Supports IEEE 802.11a/b/g/n/ac

• Supports Dual-Band (2.4/5 GHz)

• Supports high speed wireless connections up to 867Mbps

• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity

technology

• Supports Bluetooth 4.0 / 3.0 + High speed class II

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P4V88-M Manuel utilisateur

ASROCK

ASROCK J4125B-ITX Manuel utilisateur

ASROCK

ASROCK Z77 WS Manuel utilisateur

ASROCK

ASROCK STX-1000B Manuel utilisateur

ASROCK

ASROCK H110M-I Manuel utilisateur

ASROCK

ASROCK A75 Pro4-M Manuel utilisateur

ASROCK

ASROCK B560M-HDV R3.0 Manuel utilisateur

ASROCK

ASROCK A7785GM Manuel utilisateur

ASROCK

ASROCK 4U4G Series Manuel utilisateur

ASROCK

ASROCK H55 EXTREME3 Manuel utilisateur

ASROCK

ASROCK H67M-GE Manuel utilisateur

ASROCK

ASROCK B360M-ITX Manuel utilisateur

ASROCK

ASROCK A790GXH128M - Manuel utilisateur

ASROCK

ASROCK Q1900-ITX Manuel utilisateur

ASROCK

ASROCK A780GMH128M_846 - Manuel utilisateur

ASROCK

ASROCK FM2A88X Pro Manuel utilisateur

ASROCK

ASROCK Fatal1ty X470 Gaming K4 Series Manuel utilisateur

ASROCK

ASROCK 845GV-M Manuel utilisateur

ASROCK

ASROCK ADLD4-P1 Manuel utilisateur

ASROCK

ASROCK DN2800MT Manuel utilisateur

ASROCK

ASROCK Z68M/USB3 Manuel utilisateur

ASROCK

ASROCK H61M-VS R2.0 Manuel utilisateur

ASROCK

ASROCK Fatal1ty B85 Killer Manuel utilisateur

ASROCK

ASROCK IMB-1214 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
