ASROCK EPC612D8A-TB Manuel utilisateur

Version 1.0

Published January 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 7

1.5 I/O Panel 14

1.6 Block Diagram 17

Chapter 2 Installation 20

2.1 Screw Holes 20

2.2 Pre-installation Precautions 20

2.3 Installing the CPU 21

2.4 Installing the CPU Fan and Heatsink 24

2.5 Installation of Memory Modules (DIMM) 25

2.6 Expansion Slots (PCI and PCI Express Slots) 27

2.7 Jumper Setup 30

2.8 Onboard Headers and Connectors 33

2.9 Dr. Debug 41

2.10 Driver Installation Guide 42

2.11 Dual LAN and Teaming Operation Guide 44

2.12 M.2_SSD (NGFF) Module Installation Guide 45

Chapter 3 UEFI Setup Utility 48

3.1 Introduction 48

3.1.1 UEFI Menu Bar 48

3.1.2 Navigation Keys 49

3.2 Main Screen 50

3.3 OC Tweaker Screen 51

3.4 Advanced Screen 54

3.4.1 CPU Conguration 55

3.4.2 DRAM Conguration 58

3.4.3 ACPI Conguration 59

3.4.4 Congure Super IO Settings 61

3.4.5 Serial Port Console Redirection 62

3.4.6 USB Conguration 64

3.4.7 Chipset Conguration 65

3.4.8 Storage Conguration 68

3.4.9 H/W Monitor Screen 71

3.4.10 Intel ME Conguration 73

3.4.11 Easy RAID Installer 74

3.4.12 Instant Flash 75

3.5 Server Mgmt (Server Management) 76

3.6 Security Screen 78

3.7 Boot Screen 79

3.8 Event Logs 81

3.9 Exit Screen 83

Chapter 4 Software Support 84

4.1 Install Operating System 84

4.2 Support CD Information 84

4.2.1 Running The Support CD 84

4.2.2 Drivers Menu 84

4.2.3 Utilities Menu 84

4.2.4 Contact Information 84

Chapter 5 Troubleshooting 85

5.1 Troubleshooting Procedures 85

5.2 Technical Support Procedures 87

5.3 Returning Merchandise for Service 87

Chapter 6: Net Framework Installation Guide 88

6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 88

EPC612D8 Series

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack EPC612D8 Series motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

•ASRock Rack EPC612D8 / EPC612D8A / EPC612D8A-TB Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

•Support CD

•User Manual

•4 x SATA3 Cables (50cm)

•2 x SATA3 Cables (60cm)

•1 x I/O Shield

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

English

1.2 Specications

EPC612D8A / EPC612D8A-TB / EPC612D8

MB Physical Status

Form Factor ATX

Dimension 12'' x 9.6'' (30.5 cm x 24.4 cm)

Processor System

CPU Intel® Xeon processor E5-1600/2600 v3 series

Socket Single Socket LGA 2011 R3

Chipset Intel® C612

System Memory

Capacity 8 DIMM slots

Type - Quad Channel memory technology (see Caution 3)

- Supports DDR4 2133/1866/1600 ECC DIMM, R-DIMM,

LR-DIMM, NV-DIMM

Voltage 1.2V

Expansion Slot (Slot 7 is the closest to the CPU)

Slot 7 ME x16, EE x16 (x16/x0 or x8/x8 with slot 5)

Slot 6 ME x8, EE x8 (x8 if slot 4 mini PCIe is disabled)

Slot 5 ME x16, EE x8

Slot 4 mini PCIe x4 to support M.2 (Full and Half size support)

*e M.2 slot shares lanes with PCIe Slot 6.

Slot 3 ME x16, EE x16 (x16/x0 or x8/x8 with slot 1)

Slot 2 N/A

Slot 1 ME x16, EE x8

Storage

SATA

Controller

C612: 10 x SATA3 6Gb/s ( 1x SATA DOM)

Additional

SATA

Controller

Marvell 9172: 2 x SATA3 6Gbps

Ethernet

Interface 1000 /100 /10 Mbps

LAN Controller 2 x RJ45 by Intel® i210 + Intel® i217

1 x RJ45 Dedicated IPMI LAN port

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports Dual LAN with Teaming function*

*With the Intel i217LM LAN chip on board, the LAN Teaming function will

be limited to 3 modes as Intel® Active Management Technology (Intel® AMT)

Enabled: Adapter Fault Tolerance (AFT), Switch Fault Tolerance (SFT), and

Adaptive Load Balancing (ALB) teams.

- Supports PXE

EPC612D8 Series

English

Management

BMC Controller ASPEED AST2400

IPMI Dedicated

GLAN

- 1 x Realtek RTL8211E for dedicated management GLAN

Features - Watch Dog

- NMI

Gracphics

Controller ASPEED AST2400

VRAM DDR3 16MB

Audio

Audio code EPC612D8A-TB / EPC612D8A:

Realtek ALC1150

EPC612D8:

N/A

Rear Panel I/O

VGA Port 1 x D-Sub

USB 2.0 Port 2

USB 3.0 Port 2

Lan Port - 2 + 1 (IPMI) Lan port (RJ45)

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

Serial Port 1 (COM1)

underBolt EPC612D8A-TB:

1 with DP_IN

*e onboard underbolt port is only supported on Windows 8.1 / 8 / 7.

EPC612D8A / EPC612D8:

N/A

Audio Jack EPC612D8A-TB / EPC612D8A:

3 Jack

EPC612D8:

N/A

Internal Connector

Auxiliary Panel

Header

1 (include chassis intrusion , location button & LED , front

LAN LED , system fault LED)

TPM Header 1

IPMB Header 1

Buzzer 1

Fan Header 1x CPU Fan, 4x system Fan (4-pin)

ATX Power 1 (24-pin) + 1 (8-pin)

USB 3.0 Header 1 ( support 2 USB 3.0)

USB 2.0 Header 1 ( support 2 USB 2.0)

Type A USB 2.0

Port

Front Panel 1

4 pin 5V box

Connector

English

System BIOS

BIOS Ty pe 128Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8 Support

- ASRock Rack Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- System Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,

1.05V_PCH, +BAT, 3VSB, 5VSB

Support OS

OS Microso® Windows®

- Windows® 7 (32 / 64 bit)

- Windows® 8 (32 / 64 bit)

- Windows® 8.1 (32 / 64 bit)

- Server 2008 R2 SP1 (64 bit)

- Server 2012 (64 bit)

- Server 2012 R2 (64 bit)

Linux®

- RedHat Enterprise Linux Server 5.10/6.5 (32 / 64 bit)

- CentOS 5.10 / 6.5 (32 / 64 bit)

- SUSE Enterprise Linux Server 11 SP3 (32 / 64 bit)

- FreeBSD 9.2 (32 / 64 bit)

- Fedora core 19 (64 bit)

- Ubuntu 12.04.2 (64 bit) / 12.10 (64 bit)

Virtual

- VMWare® ESXi 5.5 (not supported for Marvell 9172)

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C
