ASROCK CREATOR X299 Manuel utilisateur

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock X299 Creator o

cerca il tuo prodotto tra le migliori offerte di Schede Madri

Version 1.0

Published October 2019

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

CE Warning

is device complies with directive 2014/53/EU issued by the Commision of the European

Community.

is equipment complies with EU radiation exposure limits set forth for an uncontrolled

environment.

is equipment should be installed and operated with minimum distance 20cm between

the radiator & your body.

Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Radio transmit power per transceiver type

Function Frequency Maximum Output Power (EIRP)

WiFi

2400-2483.5 MHz 18.5 + / -1.5 dbm

5150-5250 MHz 21.5 + / -1.5 dbm

5250-5350 MHz 18.5 + / -1.5 dbm (no TPC)

21.5 + / -1.5 dbm (TPC)

5470-5725 MHz 25.5 + / -1.5 dbm (no TPC)

28.5 + / -1.5 dbm (TPC)

Bluetooth 2400-2483.5 MHz 8.5 + / -1.5 dbm

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 8

1.4 I/O Panel 10

1.5 WiFi-802.11ax Module and ASRock WiFi 2.4/5 GHz

Antenna 12

1.6 ASRock Thunderbolt™ 3 Module 13

Chapter 2 Installation 17

2.1 Installing the CPU 18

2.2 Installing the CPU Fan and Heatsink 21

2.3 Installation of Memory Modules (DIMM) 22

2.4 Expansion Slots (PCI Express Slots) 24

2.5 Jumpers Setup 27

2.6 Onboard Headers and Connectors 28

2.7 Smart Switches 35

2.8 Dr. Debug 36

2.9 SLITM and 3-Way SLITMand Operation Guide 42

2.9.1 Installing Two SLITM-Ready Graphics Cards 42

2.9.2 Installing Three SLITM-Ready Graphics Cards 44

2.9.3 Driver Installation and Setup 46

2.10 CrossFireXTM and 3-Way CrossFireXTM Operation Guide 47

2.10.1 Installing Two CrossFireXTM-Ready Graphics Cards 47

2.10.2 Installing Three CrossFireXTM-Ready Graphics Cards 49

2.10.3 Driver Installation and Setup 50

2.11 M.2_SSD (NGFF) Module Installation Guide

(M2_1 and M2_2) 51

2.12 M.2_SSD (NGFF) Module Installation Guide (M2_3) 54

Chapter 3 Software and Utilities Operation 57

3.1 Installing Drivers 57

3.2 ASRock Motherboard Utility (A-Tuning) 58

3.2.1 Installing ASRock Motherboard Utility (A-Tuning) 58

3.2.2 Using ASRock Motherboard Utility (A-Tuning) 58

3.3 ASRock Live Update & APP Shop 61

3.3.1 UI Overview 61

3.3.2 Apps 62

3.3.3 BIOS & Drivers 65

3.3.4 Setting 66

3.4 ASRock Polychrome SYNC 67

Chapter 4 UEFI SETUP UTILITY 70

4.1 Introduction 70

4.2 EZ Mode 71

4.3 Advanced Mode 72

4.3.1 UEFI Menu Bar 72

4.3.2 Navigation Keys 73

4.4 Main Screen 74

4.5 OC Tweaker Screen 75

4.6 Advanced Screen 88

4.6.1 CPU Conguration 89

4.6.2 IIO Conguration 91

4.6.3 Chipset Conguration 92

4.6.4 Storage Conguration 95

4.6.5 Intel® Thunderbolt™ 97

4.6.6 ACPI Conguration 98

4.6.7 USB Conguration 99

4.6.8 Trusted Computing 100

4.7 Tools 101

4.8 Hardware Health Event Monitoring Screen 104

4.9 Security Screen 108

4.10 Boot Screen 109

4.11 Exit Screen 112

English

X299 Creator

Chapter 1 Introduction

ank you for purchasing ASRock X299 Creator motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock X299 Creator Motherboard (ATX Form Factor)

• ASRock X299 Creator Quick Installation Guide

• ASRock X299 Creator Support CD

• 1 x ASRock SLI_HB_Bridge_2S Card (Optional)

• 1 x ASRock WiFi 2.4/5 GHz Antenna (Optional)

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 3 x Screws for M.2 Sockets (Optional)

• 3 x Standos for M.2 Sockets (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• 8 Layer PCB

• 2oz Copper PCB

CPU • Supports Intel® CoreTM X-Series Processor Family for the

LGA 2066 Socket (Cascade Lake-X, Skylake X Refresh and

Skylake X)

• Digi Power design

• 13 Power Phase design

• Supports Intel® Turbo Boost Max Technology 3.0

Chipset • Intel® X299

Memory • Quad Channel DDR4 Memory Technology

• 8 x DDR4 DIMM Slots

• Supports DDR4 4200+(OC)*/4000(OC)/3800(OC)/

3733(OC)/3600(OC)/3200(OC)/2933(OC)/2800

(OC)/2666/2400/2133 non-ECC, un-buered memory

* e maximum memory frequency supported may vary by

processor type.

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

• Max. capacity of system memory: 256GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 4 x PCI Express 3.0 x16 Slots*

* If you install CPU with 48 lanes, PCIE1/PCIE2/PCIE3/PCIE5

will run at x16/x8/x16/x8.

If a M.2 PCI Express module is installed on M2_1 or M2_2,

PCIE2 will downgrade to x4 mode.

If M.2 PCI Express modules are installed on M2_1 and M2_2,

PCIE2 will be disabled.

* If you install CPU with 44 lanes, PCIE1/PCIE2/PCIE3/PCIE5

will run at x16/x4/x16/x8.

If a M.2 PCI Express module is installed on M2_1, PCIE2 will

be disabled.

English

X299 Creator

* If you install CPU with 28 lanes, PCIE1/PCIE2/PCIE3/PCIE5

will run at x16/x4/x8/x0.

If a M.2 PCI Express module is installed on M2_1, PCIE2 will

be disabled.

* Supports NVMe SSD as boot disks

• 1 x PCI Express 3.0 x1 Slot

• Supports AMD 3-Way CrossFireXTM and CrossFireXTM **

• Supports NVIDIA® 3-Way SLITM and SLITM**

• Supports NVIDIA® NVLinkTM with dual NVIDIA® GeForce®

RTX series graphics cards***

• Support NVIDIA® SLITM with NVIDIA® Quadro graphics

cards

** 3-Way CrossFireXTM and 3-Way SLITM are only supported

with CPU with 48 lanes or 44 lanes.

*** NVIDIA NVLink Bridge does not come with the package.

Please purchase it from NVIDIA® if necessary.

• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-

802.11ax module (on the rear I/O)

• 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE3)

Thunder-

boltTM

• Intel® JHL7540 underboltTM 3 Controller (Titan Ridge)

• Supports underboltTM 3 interface with max. resolution of

5K (5120 x 2880) @ 60Hz for one display over a single cable

connection

• Supports underboltTM 3 interface with max. resolution of

4K x 2K (4096x2160) @ 60Hz for dual displays over a single

cable connection

• Supports up to two streams (eight lanes) of DisplayPort video

bandwidth; supports daisy-chaining of multiple DisplayPort

monitors

Audio • 7.1 CH HD Audio with Content Protection (Realtek

ALC1220 Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• Supports Purity SoundTM 4

- Nichicon Fine Gold Series Audio Caps

- 120dB SNR DAC with Dierential Amplier

- NE5532 Premium Headset Amplier for Front Panel

Audio Connector (Supports up to 600 Ohm headsets)

- Pure Power-In

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK X79 Extreme4 Manuel utilisateur

ASROCK

ASROCK B150M Pro4/D3 Manuel utilisateur

ASROCK

ASROCK N68-GS - V1.1 Manuel utilisateur

ASROCK

ASROCK K8NF6P-VSTA Manuel utilisateur

ASROCK

ASROCK NUC-1165G7 Manuel utilisateur

ASROCK

ASROCK B760 Pro RS/D4 Manuel utilisateur

ASROCK

ASROCK B85M-HDS Manuel utilisateur

ASROCK

ASROCK A780GM-LE 128M - V1.0 Manuel utilisateur

ASROCK

ASROCK iBOX-155B Manuel utilisateur

ASROCK

ASROCK 770iCafe Manuel utilisateur

ASROCK

ASROCK 2CORE1066-2.13G - V1.0 Manuel utilisateur

ASROCK

ASROCK K8UPGRADE-PCIE Manuel utilisateur

ASROCK

ASROCK IMB-380-L Manuel de service

ASROCK

ASROCK FM2A55M-VG3 Manuel utilisateur

ASROCK

ASROCK H77M-ITX Manuel utilisateur

ASROCK

ASROCK Z77E-ITX Manuel utilisateur

ASROCK

ASROCK N68-S3 FX Manuel utilisateur

ASROCK

ASROCK K7VT4A PRO Manuel utilisateur

ASROCK

ASROCK B75 Pro3 Manuel utilisateur

ASROCK

ASROCK IMB-170 Manuel utilisateur

ASROCK

ASROCK FM2A55M-HD Manuel utilisateur

ASROCK

ASROCK P67 EXTREME4 - Manuel utilisateur

ASROCK

ASROCK A520M-ITX/ac Manuel utilisateur

ASROCK

ASROCK Q87M vPro Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
