ASROCK B760 PRO RS Manuel utilisateur

Contact Information

If you need to contact ASRock or want to know more about ASRock, you’re welcome

to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer

for further information. For technical questions, please submit a support request

form at https://event.asrock.com/tsd.asp

ASRock Incorporation

e-mail: info@asrock.com.tw

ASRock EUROPE B.V.

e-mail: sales@asrock.nl

ASRock America, Inc.

e-mail: sales@asrockamerica.com

Scan the QR code to view more manuals and documents.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 9

1.5 Block Diagram 10

Chapter 2 Installation 11

2.1 Installing the CPU 12

2.2 Installing the CPU Fan and Heatsink 14

2.3 Installing Memory Modules (DIMM) 15

2.4 Connecting the Front Panel Header 17

2.5 Installing the Motherboard 18

2.6 Installing SATA Drives 19

2.7 Installing a Graphics Card 21

2.8 Connecting Peripheral Devices 23

2.9 Connecting the Power Connectors 24

2.10 Power On 25

2.11 Jumpers Setup 26

2.12 Onboard Headers and Connectors 27

2.13 Post Status Checker 44

2.14 M.2 WiFi/BT PCIe WiFi Module and Intel® CNVi (Integrated

WiFi/BT) Installation Guide 45

2.15 M.2 SSD Module Installation Guide (M2_1) 47

2.16 M.2 SSD Module Installation Guide (M2_2 and M2_3) 51

2.17 Change Screen Brightness for eDP in Windows® 53

English

B760 Pro RS

Chapter 1 Introduction

ank you for purchasing ASRock B760 Pro RS motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

1.1 Package Contents

• ASRock B760 Pro RS Motherboard (ATX Form Factor)

• ASRock B760 Pro RS User Manual

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 4 x Screws for M.2 Sockets (Optional)

• 1 x Standofor M.2 Socket (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

CPU • Supports 13th Gen & 12th Gen Intel® CoreTM Processors

(LGA1700)

• Supports Intel® Hybrid Technology

• Supports Intel® Turbo Boost Max 3.0 Technology

• Supports Intel® ermal Velocity Boost (TVB)

• Supports Intel® Adaptive Boost Technology (ABT)

Chipset • Intel® B760

Memory • Dual Channel DDR5 Memory Technology

• 4 x DDR5 DIMM Slots

• Supports DDR5 non-ECC, un-buered memory up to

6800+(OC)*

• Max. capacity of system memory: 128GB

• Supports Intel® Extreme Memory Prole (XMP) 3.0

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

Expansion

Slot

CPU:

• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*

Chipset:

• 1 x PCIe 4.0 x16 Slot (PCIE3), supports x4 mode*

• 1 x PCIe 3.0 x16 Slot (PCIE4), supports x1 mode*

• 1 x PCIe 3.0 x1 Slot (PCIE2)*

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe

WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/

BT)

* Supports NVMe SSD as boot disks

• Supports AMD CrossFireTM

English

B760 Pro RS

Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Intel® XeGraphics Architecture (Gen 12)

• 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz

• 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and

max. resolution up to 4K 60Hz

• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP

2.3 and max. resolution up to 8K 60Hz / 5K 120Hz

Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

• Nahimic Audio

LAN • 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

• Dragon RTL8125BG

• Supports Dragon 2.5G LAN Soware

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and

Streaming Modes

- User Customized Priority Control

USB • 2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front)

• 1 x USB 3.2 Gen2 Type-A (Rear)

• 6 x USB 3.2 Gen1 (4 Rear, 2 Front)

• 4 x USB 2.0 (2 Rear, 2 Front)

* All USB ports support ESD Protection

Rear Panel

I/O

• 2 x Antenna Mounting Points

• 1 x HDMI Port

• 1 x DisplayPort 1.4

• 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)

• 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)

English

• 4 x USB 3.2 Gen1 Ports

• 2 x USB 2.0 Ports

• 1 x RJ-45 LAN Port

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage CPU:

• 1 x Hyper M.2 Socket (M2_1, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

Chipset:

• 1 x M.2 Socket (M2_2, Key M), supports type 2260/2280

PCIe Gen4x2 (32 Gb/s) mode*

• 1 x Hyper M.2 Socket (M2_3, Key M), supports type

2260/2280 PCIe Gen4x4 (64 Gb/s) mode*

• 4 x SATA3 6.0 Gb/s Connectors

* Supports Intel® Volume Management Device (VMD)

* Supports NVMe SSD as boot disks

RAID • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

storage devices

Connector • 1 x eDP Signal Connector

• 1 x SPI TPM Header

• 1 x Power LED and Speaker Header

• 2 x RGB LED Headers*

• 2 x Addressable LED Headers**

• 1 x CPU Fan Connector (4-pin)***

• 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan

Speed Control)****

• 5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan

Speed Control)*****

• 1 x 24 pin ATX Power Connector

• 2 x 8 pin 12V Power Connectors (Hi-Density Power Connec-

tor)

• 1 x Front Panel Audio Connector

English

B760 Pro RS

• 1 x underbolt AIC Connector (5-pin) (Supports ASRock

underbolt 4 AIC Card)

• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)

• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

• 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)

* Support in total up to 12V/3A, 36W LED Strip

** Support in total up to 5V/3A, 15W LED Strip

*** CPU_FAN1 supports the fan power up to 1A (12W).

**** CPU_FAN2/WP supports the fan power up to 2A (24W).

***** CHA_FAN1~5/WP support the fan power up to 2A (24W).

***** CPU_FAN2/WP and CHA_FAN1~5/WP can auto detect

if 3-pin or 4-pin fan is in use.

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

OS • Microso® Windows® 10 64-bit / 11 64-bit

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

English

PCIE1

PCIE3

HDLED RESET

PLE D PWRB TN

HD_AUDIO1

HDMI1

AUDIO

CODEC

CHA_FAN1/WP

CHA_FAN4/WP

CHA_FAN5/WP

CPU_FAN2/WP

SUPER

I/O

RoHS

RGB_LED1

RGB_LED2

USB_3_4 SPK_PLED1

PANEL1

SPI_TPM_J1

DP1

T B1

CPU

DRAM

VGA

BOOT

CPU_FAN1

PCIE2

Intel

B760

CLRMOS1

CHA_FAN2

/WP

M2_1

Top:

LINE IN

Center:

FRONT

Bottom:

MIC IN

M2_WIFI_CT1

M2_WIFI1

USB32_TC2

DDR5_A2 (64 bit, 288-pin module)

DDR5_A1 (64 bit, 288-pin module)

DDR5_B2 (64 bit, 288-pin module)

DDR5_B1 (64 bit, 288-pin module)

USB32_6_7

SATA3_0

SATA3_1

SATA3_2

SATA3_3

CHA_FAN3

/WP

ADDR_LED1

M2_2

M2_3

LAN

ATX12V1 ATX12V2

ATXPWR1

BIOS

ROM

Top:

RJ-45

USB 3.2 Gen1

T: USB32_4

B: USB32_5

USB 3.2 Gen1

T: USB32_2

B: USB32_3

USB 3.2 Gen 2

T:USB32_1

B: USB32_TC1

USB 2.0

T: USB_1

B: USB_2

CMOS

Battery

ADDR_LED2

PCIE4

1.3 Motherboard Layout

Top Side View
