ASROCK A75M-HVS Manuel utilisateur

A75M-HVS

User Manual

Version 1.1

Published June 2011

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identi cation or explanation and to the owners’ bene t, without intent to infringe.

Disclaimer:

Speci cations and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, of cers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of pro ts, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction................................................................. 5

1.1 Package Contents ..................................................................... 5

1.2 Speci cations............................................................................. 6

1.3 Motherboard Layout ................................................................. 11

1.4 I/O Panel .................................................................................. 12

2. Installation................................................................... 13

Pre-installation Precautions ................................................................ 13

2.1 CPU Installation ......................................................................... 14

2.2 Installation of CPU Fan and Heatsink ...................................... 14

2.3 Installation of Memory Modules (DIMM) .................................... 15

2.4 Expansion Slots (PCI and PCI Express Slots)........................... 16

2.5 Dual Graphics Operation Guide ................................................ 17

2.6 Dual Monitor and Surround Display Features ........................... 19

2.7 ASRock Smart Remote Installation Guide................................. 22

2.8 Jumpers Setup........................................................................... 23

2.9 Onboard Headers and Connectors ....................................... 24

2.10 Serial ATA3 (SATA3) Hard Disks Installation ......................... 28

2.11 Hot Plug and Hot Swap Functions for SATA3 HDDs ................. 28

2.12 SATA3 HDD Hot Plug and Hot SwapFeature and Operation

Operation Guide ........................................................................ 29

2.13 Driver Installation Guide ............................................................ 31

2.14 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit With RAID Functions.................................................. 31

2.14.1 Installing Windows®XP / XP 64-bit With RAID

Functions ....................................................................... 31

2.14.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

With RAID Functions ..................................................... 32

2.15 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit Without RAID Functions............................................. 33

2.15.1 Installing Windows®XP / XP 64-bit Without RAID

Functions ....................................................................... 33

2.15.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

Without RAID Functions ................................................ 34

3. UEFI SETUP UTILITY.......................................................... 35

3.1 Introduction ................................................................................ 35

3.1.1 UEFI Menu Bar................................................................ 35

3.1.2 Navigation Keys............................................................... 36

3.2 Main Screen............................................................................... 36

3.3 OC Tweaker Screen................................................................... 37

3.4 Advanced Screen ...................................................................... 40

3.4.1 CPU Con guration........................................................... 41

3.4.2 North Bridge Con guration .............................................. 42

3.4.3 South Bridge Con guration ............................................. 43

3.4.4 Storage Con guration...................................................... 44

3.4.5 Super IO Con guration.................................................... 45

3.4.6 ACPI Con guration.......................................................... 46

3.4.7 USB Con guration........................................................... 48

3.5 Hardware Health Event Monitoring Screen ............................... 49

3.6 Boot Screen ............................................................................... 50

3.7 Security Screen ......................................................................... 51

3.8 Exit Screen ................................................................................ 52

4. Software Support......................................................... 53

4.1 Install Operating System............................................................ 53

4.2 Support CD Information ............................................................. 53

4.2.1 Running Support CD ....................................................... 53

4.2.2 Drivers Menu ................................................................... 53

4.2.3 Utilities Menu ................................................................... 53

4.2.4 Contact Information ......................................................... 53

1. Introduction

Thank you for purchasing ASRock A75M-HVS motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the con guration

guide to BIOS setup and information of the Support CD.

Because the motherboard speci cations and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modi cations of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

nd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock A75M-HVS Motherboard

(Micro ATX Form Factor: 8.9-in x 8.5-in, 22.6 cm x 21.6 cm)

ASRock A75M-HVS Quick Installation Guide

ASRock A75M-HVS Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®7 / 7 64-bit / VistaTM / VistaTM 64

bit, it is recommended to set the BIOS option in Storage Con guration

to AHCI mode. For the BIOS setup, please refer to the “User Manual” in

our support CD for details.

1.2 Specifications

Platform - Micro ATX Form Factor: 8.9-in x 8.5-in, 22.6 cm x 21.6 cm

- Solid Capacitor for CPU power

CPU - Support for Socket FM1 100W processors

- Supports AMD’s Cool ‘n’ QuietTM Technology

- UMI-Link GEN2

Chipset - AMD A75 FCH (Hudson-D3)

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 1)

- 2 x DDR3 DIMM slots

- Support DDR3 2400+(OC)/1866/1600/1333/

1066/800 non-ECC, un-buffered memory (see CAUTION 2)

- Max. capacity of system memory: 16GB (see CAUTION 3)

Expansion Slot - 1 x PCI Express 2.0 x16 slot

- 1 x PCI Express 2.0 x1 slot

- 1 x PCI slot

- Supports AMD Dual Graphics

Graphics - AMD Radeon HD 65XX/64XX graphics

- DirectX 11, Pixel Shader 5.0

- Max. shared memory 512MB (see CAUTION 4)

- Dual VGA Output: support HDMI and D-Sub ports by

independent display controllers

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1600 @

60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required) (see CAUTION 5)

- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a

- Supports AMD Steady VideoTM: New video post processing

capability for automatic jutter reduction on home/online

video

- Supports HDCP function with HDMI port

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with HDMI port

Audio - 5.1 CH HD Audio (VIA®VT1705 Audio Codec)

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef cient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x HDMI Port

- 2 x Ready-to-Use USB 2.0 Ports

- 4 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

SATA3 - 6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and “Hot Plug” functions

USB 3.0 - 4 x USB 3.0 ports, support USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 6 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x Print port header

- 1 x COM port header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, VDDP, SB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), AMD

Live! Explorer, AMD Fusion, CyberLink MediaEspresso 6.5

Trial, ASRock Software Suite (CyberLink DVD Suite - OEM

and Trial)

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 6)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 7)

- ASRock APP Charger (see CAUTION 8)

- ASRock SmartView (see CAUTION 9)

- ASRock XFast USB (see CAUTION 10)

- Hybrid Booster:

- ASRock U-COP (see CAUTION 11)

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP

SP3 / XP 64-bit compliant

Certiﬁcations - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 12)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting the

setting in the BIOS, applying Untied Overclocking Technology, or using the third-party over-

clocking tools. Overclocking may affect your system stability, or even cause damage to the

components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

CAUTION!

1. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 15 for proper installation.

2. Whether 2400/1866/1600MHz memory speed is supported depends on

the CPU you adopt. If you want to adopt DDR3 2400/1866/1600 memory

module on this motherboard, please refer to the memory support list on

our website for the compatible memory modules.

ASRock website http://www.asrock.com

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®64-bit OS with 64-bit CPU, there is no such

limitation.

4. The maximum shared memory size is de ned by the chipset vendor and

is subject to change. Please check AMD website for the latest informa-

tion.

5. xvYCC and Deep Color are only supported under Windows®7 64-bit /

7. Deep Color mode will be enabled only if the display supports 12bpc

in EDID. HBR is supported under Windows®7 64-bit / 7 / VistaTM 64-bit /

VistaTM.

6. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control and IES. In Hardware Monitor, it shows

the major readings of your system. In Fan Control, it shows the fan speed

and temperature for you to adjust. In IES (Intelligent Energy Saver), the

voltage regulator can reduce the number of output phases to improve

efficiency when the CPU cores are idle without sacrificing computing

performance. Please visit our website for the operation procedures of

ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

7. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems rst like MS-DOS or Windows®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS le to your USB ash drive, oppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional oppy diskette or other complicated ash utility. Please

be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

8. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply installing the APP Charger

driver, it makes your iPhone charged much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

9. SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your OS

version is Windows®7 / 7 64 bit / VistaTM / VistaTM 64 bit, and your browser

version is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

10. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

11. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

12. EuP, stands for Energy Using Product, was a provision regulated by Eu-

ropean Union to de ne the power consumption for the completed system.

According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to

Intel’s suggestion, the EuP ready power supply must meet the standard

of 5v standby power ef ciency is higher than 50% under 100 mA current

consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.

Autres manuels pour A75M-HVS

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK H67M Manuel utilisateur

ASROCK

ASROCK W480M WS Manuel utilisateur

ASROCK

ASROCK 4CORE1333-GLAN - V1.1 Manuel utilisateur

ASROCK

ASROCK G41M-GS3 Manuel utilisateur

ASROCK

ASROCK K10N7SLI Manuel utilisateur

ASROCK

ASROCK SuperAlloy Z170 Pro4S Manuel utilisateur

ASROCK

ASROCK X370M-HDV Manuel utilisateur

ASROCK

ASROCK H55M LE - V 1.0 - 01-2010 Manuel utilisateur

ASROCK

ASROCK 870iCafe Manuel utilisateur

ASROCK

ASROCK H67DE3 Manuel utilisateur

ASROCK

ASROCK H97M Pro4 Manuel utilisateur

ASROCK

ASROCK IMB-1712 Manuel de service

ASROCK

ASROCK ATW-HC2260 Manuel utilisateur

ASROCK

ASROCK P55 DELUXE3 - Manuel utilisateur

ASROCK

ASROCK K7S41GX2 Manuel utilisateur

ASROCK

ASROCK Z87iCafe4 Manuel utilisateur

ASROCK

ASROCK K8A780LM Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z87 Professional Manuel utilisateur

ASROCK

ASROCK B75M-GL R2.0 Manuel utilisateur

ASROCK

ASROCK H55M-GE Manuel utilisateur

ASROCK

ASROCK 90-MXB150-A0UAYZ Manuel utilisateur

ASROCK

ASROCK EPC612D4I Manuel utilisateur

ASROCK

ASROCK EP2C612D16FM Manuel utilisateur

ASROCK

ASROCK H77M-ITX Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
