PAUL

User Manual

Version 1.0

Published May 2022

Version 1.0

Published May 2022

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

Contents

Chapter 1 Introduction 1

1.1 Features 1

1.2 System Requirements 1

1.3 Package Contents 1

1.4 Specications 2

1.5 Motherboard Layout 3

1.6 Onboard LED Indicators 4

1.7 I/O Panel 5

Chapter 2 Installation 6

2.1 Installing the IPMI Card 6

2.2 Jumper Setup 7

2.3 Onboard Headers and Connectors 8

Chapter 3 Connection 11

3.1 Connections to MB for Power On/O & Reboot Features 11

Chapter 4 Management Interface 13

4.1 Web-based User Interface 13

4.1.1 Logging in the Utility 13

4.1.2 Using the Utility 14

4.2 Dashboard 15

4.3 Sensor 16

4.4 FRU Information 17

4.5 IPMI Event Log 18

4.6 Setting 19

4.6.1 Date & Time 19

4.6.2 KVM Mouse Setting 20

4.6.3 Services 20

4.7 Remote Control 21

4.7.1 Remote KVM Interface 21

4.8 Power Control 22

PAU L

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack PAUL , a reliable IPMI Card produced under

ASRock Rack’s consistently stringent quality control. It delivers excellent performance

with robust design conforming to ASRock Rack’s commitment to quality and

endurance.

1.1 Features

• KVM Mouse

• LAN interface (supports RMCP+)

• Serial Over LAN

• Universal Series Bus(USB)

• IPMI Serial Interface

• Field Replaceable Unit (FRU)

• IPMI Sensor

• IPMI Event Log

• Power control

• FAN Control

• Remote Control

• iKVM

• ADC Device Support (Customizable)

• GPIO Device Support (Customizable)

1.2 System Requirements

Before you install the PAUL Card, please check if the client device meets the following

requirements.

• Motherboard that supports PAUL Card

• LAN(RJ-45) port for server management

• Firefox (Windows and Linux), Chrome (Windows and Linux), Edge-Chromium

Version (Windows)

1.3 Package Contents

• ASRock Rack PAUL Motherboard

(Proprietary Form Factor: 6.7-in x 2.2-in, 16.85 cm x 5.62 cm)

If you require technical support related to this product, please visit our website for specic

information about the model you are using.

http://www.asrockrack.com/support/

2 3

English

1.4 Specications

PAUL

Type Low-Prole PCIe IPMI Card

Chipset ASPEED VIDEO PROCESSOR AST2500A2-GP

Onboard RAM System: 384MB

Video 1 (64MB)

Onboard ROM 64MB

Interface PCIe 3.0 x1 interface

VGA 1 x D-sub support max. resolution 1920 x 1200 @ 60Hz

External

connectors

1 x D-sub

1 x USB 2.0 Port

Internal

connectors

2x SPI Selection Jumper (SPI1_SEL1 / SPI1_SEL2)

1x TPM Header (TPMS1)

1x ROM Selection Jumper (D_ROM_SEL)

1x Intelligent Platform Management Bus Header (IPMB_1)

1x SD Card Slot (SD_CARD1)

1x PSU SMBus (PSU_SMB1)

1x COM Port Header (COM1)

1x USB 2.0 Type-A Port (USB2_B)

2x System Fan Connector (FAN1 / FAN2)

1x USB 2.0 Header (USB2_3_4)

2x Auxiliary Panel Header (AUX_PANEL1 / AUX_PANEL2)

1x VBIOS Selection Jumper (VBIOS_SEL1)

1x TPM Header (TPMS2)

1x Non Maskable Interrupt Button (NMI_BTN1)

2x BMC SMBus Header (BMC_SMB_1 / BMC_SMB_2)

Watchdog 32-bit Watchdog Timer

Main Features Compatible and supports IPMI 2.0 and supports KVM

Supports Web UI (Remote management)

Supports Virtual media

Supports Netwot Bonding

Operating

System

Windows 10 -64bit

Linux OS including Cent OS

Redhat

Ubuntu

Dimensions 168.45 * 68.9 mm

NOTE: Please refer to our website for the latest specications.

PAU L

2 3

English

1.5 Motherboard Layout

VGA1

5.62cm (2.2 in)

BMC_SMB_1

NMI_BTN1

TPMS2

TPMS1

SPI1_SEL2

IPMB_1

VBIOS_SEL1

D_ROM_SEL

FAN1

FAN2

USB2_3_4

COM1

USB2_B

PSU_SMB1

SD_CARD1

PCIE1

SPI1_SEL1

AUX_PENEL1

AUX_PENEL2

4576

16 14 13 12 10

1517

16.85cm (6.7in)

IPMI_LAN1

BMC_SMB_2

(PAUL only)

No. Description

1 SPI Selection Jumper (SPI_SEL1)

2 SPI Selection Jumper (SPI_SEL2)

3 TPM Header (TPMS1)

4 ROM Selection Jumper (D_ROM_SEL)

5 Intelligent Platform Management Bus Header (IPMB_1)

6 SD Card Slot (SD_CARD1)

7 PSU SMBus (PSU_SMB1)

8 COM Port Header (COM1)

9 USB 2.0 Type-A Port (USB2_B)

10 System Fan Connector (FAN1)

11 System Fan Connector (FAN2)

12 USB 2.0 Header (USB2_3_4)

13 Auxiliary Panel Header (AUX_PANEL1)

14 Auxiliary Panel Header (AUX_PANEL2)

15 VBIOS Selection Jumper (VBIOS_SEL1)

16 TPM Header (TPMS2)

17 Non Maskable Interrupt Button (NMI_BTN1)

18 BMC SMBus Header (BMC_SMB_2)

19 BMC SMBus Header (BMC_SMB_1)

4 5

English

1.6 Onboard LED Indicators

No. LED Status Description

1BMC_B_LED1 Yellow Using BMC ROM2

2LAN1_LED Red FAN1 failed

3FAN2_LED Red FAN2 failed

4BMC_A_LED1 Yel low Using BMC ROM1

5BMC_LED1 Green BMC heartbeat LED

6SYSTEM_ERR_LED Red STB PWR ready

7 SB_PWR1 Green SYSTEM error
