ASROCK Rack C236M WS Manuel utilisateur

C236M WS

User Manual

Version 1.0

Published November 2017

Version 1.1

Published May 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Rack Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished

for informational use only and subject to change without notice, and should not

be constructed as a commitment by ASRock Rack. ASRock Rack assumes no

responsibility for any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock Rack does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable

for any indirect, special, incidental, or consequential damages (including damages

for loss of prots, loss of business, loss of data, interruption of business and the

like), even if ASRock Rack has been advised of the possibility of such damages

arising from any defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Rack’s Website: www.ASRockRack.com

Contact Information

If you need to contact ASRock Rack or want to know more about ASRock Rack,

you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you

may contact your dealer for further information.

ASRock Rack Incorporation

6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,

Taipei City 112, Taiwan (R.O.C.)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 5

1.4 Motherboard Layout 6

1.5 Onboard LED Indicators 9

1.6 I/O Panel 10

1.7 Block Diagram 11

Chapter 2 Installation 12

2.1 Screw Holes 12

2.2 Pre-installation Precautions 12

2.3 Installing the CPU 13

2.4 Installing the CPU Fan and Heatsink 15

2.5 Installation of Memory Modules (DIMM) 16

2.6 Expansion Slots (PCI Express Slots) 18

2.7 Jumper Setup 19

2.8 Onboard Headers and Connectors 20

2.9 Dr. Debug 27

2.10 Driver Installation Guide 28

2.11 M.2_SSD (NGFF) Module Installation Guide 29

Chapter 3 UEFI Setup Utility 31

3.1 Introduction 31

3.1.1 UEFI Menu Bar 31

3.1.2 Navigation Keys 32

3.2 Main Screen 33

3.3 Advanced Screen 34

3.3.1 CPU Conguration 35

3.3.2 Memory Conguration 38

3.3.3 Chipset Conguration 39

3.3.4 Storage Conguration 41

3.3.5 NVMe Conguration 42

3.3.6 ACPI Conguration 43

3.3.7 USB Conguration 45

3.3.8 WHEA Conguration 46

3.3.9 Super IO Conguration 47

3.3.10 Serial Port Console Redirection 48

3.3.11 H/W Monitor 51

3.3.12 Trusted Computing 53

3.3.13 Instant Flash 55

3.4 Boot Screen 56

3.4.1 CSM Parameters 58

3.5 Security 60

3.6 Event Logs 61

3.7 Exit Screen 63

Chapter 4 Software Support 65

4.1 Install Operating System 65

4.2 Support CD Information 65

4.2.1 Running The Support CD 65

4.2.2 Drivers Menu 65

4.2.3 Utilities Menu 65

4.2.4 Contact Information 65

Chapter 5 Troubleshooting 66

5.1 Troubleshooting Procedures 66

5.2 Technical Support Procedures 68

5.3 Returning Merchandise for Service 68

Chapter 6 Net Framework Installation Guide 69

6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2) 69

C236M WS

PB 1

English

Chapter 1 Introduction

ank you for purchasing ASRock Rack C236M WS motherboard, a reliable

motherboard produced under ASRock Rack’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock Rack’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration

guide to BIOS setup and information of the Support CD.

1.1 Package Contents

• ASRock Rack C236M WS Motherboard

(Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x24.4 cm)

• Support CD

• User Manual

• 4 x SATA3 Cables (50cm)

• 2 x SATA3 Cables (60cm)

• 1 x I/O Shield

• 1 x Screw for M.2 Socket

If any items are missing or appear damaged, contact your authorized dealer.

Because the motherboard specications and the BIOS soware might be updated, the con-

tent of this manual will be subject to change without notice. In case any modications of

this manual occur, the updated version will be available on ASRock Rack website without

further notice. You may nd the latest memory and CPU support lists on ASRock Rack

website as well. ASRock Rack’s Website: www.ASRockRack.com

If you require technical support related to this motherboard, please visit our website for

specic information about the model you are using.

http://www.asrockrack.com/support/

2 3

English

1.2 Specications

C236M WS

MB Physical Status

Form Factor Micro ATX

Dimension 9.6'' x 9.6'' (24.4 cm x24.4 cm)

Processor System

CPU Intel® Xeon® E3-1200 v5/v6 Series Processors*

*BIOS version 2.0 or above is required for v4 series.

Socket Single Socket H4 (LGA1151)

Chipset Intel® C236

System Memory

Capacity 4 DIMM slots

Type - Dual Channel memory technology

- Supports DDR4 2400*/2133/1866/1600 ECC/non-ECC**

UDIMM memory

*Only E3-1200 v6 CPUs can support DDR4 2400.

**Non-ECC UDIMM support Client OS only.

DIMM Size Per

DIMM

ECC and non-ECC UDIMM : 16GB, 8GB, 4GB

Voltage 1.2V

Expansion Slot

PCIe 3.0 x 16 1 slot (PCIE6/4: single at x16 (PCIE6); dual at x8 (PCIE6) / x8

(PCIE4)

PCIe 3.0 x 8 1 slot (PCIE4)

PCIe 3.0 x 4 1 slot (PCIE7: shared with M.2)

PCIe 3.0 x 1 1 slot (PCIE5)

M.2 1 slot

Storage

SATA

Controller

Intel® C236 : 8 x SATA3 6.0 Gb/s, support RAID 0, 1, 5, 10

Ethernet

On Board 1 x RJ45 GLAN by Intel® i219LM

1 x RJ45 GLAN by Intel® i210

- Supports Wake-On-LAN

- Supports Energy Ecient Ethernet 802.3az

- Supports PXE

Graphics

Controller Intel CPU GFX

C236M WS

2 3

English

Rear Panel I/O

PS/2 1

USB 3.0 Port 4

VGA Port 1 x D-Sub

DVI Port 1

HDMI Port 1

LAN Port - RJ45: 2x GLAN(by Intel® i210+ Intel® i219)

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

Audio 1 (5+1 jack)

Internal Connector

Auxiliary Panel

Header

1 (includes chassis intrusion, front LAN LED)

TPM Header 1

Fan Header 1x CPU Fan, 3x Front Fan, 2xRear Fan (4-pin)

ATX Power 1 (24-pin) + 4 (8-pin)

USB 3.0 Header 2 (support 4 USB 3.0)

USB 2.0 Header 1 (supports 2 USB 2.0)

Type A USB 3.0

Port

M.2 1

SATADOM 1

Buzzer 1

ClearCMOS 1 (short pin)

NMI button 1

SGPIO 2

Front Panel 1

Audio 1

System BIOS

BIOS Ty pe 128 Mb AMI UEFI Legal BIOS

BIOS Features - Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8.0 Support

- ASRock Rack Instant Flash

Hardware Monitor

Temperature - CPU Temperature Sensing

- MB/Card Side/TR Temperature Sensing

Fan - CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

CPU Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage Voltage Monitoring: +12V, +5V, +3V, CPU Vcore, GT_CPU,

+VCCSA, +V1.0M, +VCCIO, VCCST_SFR, VBAT, 3VSB

4 5

English

Support OS

OS Microso® Windows®

- Windows 7 ( 32 / 64 bit)

- Windows 8.1 ( 64 bit)

- Windows 10 (64 bit)

* Please refer to our website for the latest OS support list.

Environment

Temperature Operation temperature: 10°C ~ 35°C / Non operation

temperature: -40°C ~ 70°C

NOTE: Please refer to our website for the latest specications.

is motherboard supports Wake from on Board LAN. To use this function, please make

sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager

> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is

enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard

LAN1&2 can wake up S5 under OS.

If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-

dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it

will pass the WHQL tests.
