Asko OM8437B Manuel utilisateur

Instructions for use

OVEN

OM8437S / BO4SM3I1-77

OM8437B / BO4SM3I1-77

OM8437A1 / BO4SM3I1-77

861486_en_naslovnica_drug_papir.indd EN1861486_en_naslovnica_drug_papir.indd EN1 14. 02. 2023 10:22:3914. 02. 2023 10:22:39

EN Instructions for use EN 3 - EN 27

Pictograms used

Important information

Tip

861486_en_naslovnica_drug_papir.indd EN2861486_en_naslovnica_drug_papir.indd EN2 14. 02. 2023 10:23:0014. 02. 2023 10:23:00

EN 3

CONTENTS

Your oven

Introduction 4

Description of the appliance 5

Guide rails/Telescopic guide rails 5

Accessories 6

Door 6

Cooling fan 6

Control panel 7

First use

Before using the appliance for the first time 8

Use

Switching on and settings 9

Choosing the cooking system 12

Description of functions 12

Choosing the settings 15

Selecting additional functions 17

Starting the cooking process 18

Switching off the oven 18

Operation

Microwaves 19

Guidelines for cookware 20

Using the appliance cooking functions 21

Maintenance

Cleaning the appliance 23

Cleaning function (with microwaves) 23

Removing and cleaning the guide rails 24

Replacing the oven lamp 24

Malfunctions

General 25

Environmental aspects

Disposal of the appliance and packaging 27

861486_en_naslovnica_drug_papir.indd EN3861486_en_naslovnica_drug_papir.indd EN3 14. 02. 2023 10:23:0014. 02. 2023 10:23:00

EN 4

YOUR OVEN

Introduction

Congratulations on choosing this oven. This product is designed with simple operation and

optimum comfort in mind.

This manual shows how you can best use this oven. In addition to information about operating

the appliance, you will also find background information that may be useful when using the

appliance.

Please read the separate safety instructions carefully before

using the appliance!

Read this manual before using the appliance and keep it in a safe place for future use.

The installation instructions are included separate.

861486_en_naslovnica_drug_papir.indd EN4861486_en_naslovnica_drug_papir.indd EN4 14. 02. 2023 10:23:0014. 02. 2023 10:23:00

EN 5

Description of the appliance

1. Control panel

2. Oven levels

3. Oven door

4. Door handle

Guide rails/Telescopic guide rails

• The oven has four or five guide rails (Level 1 to 4/5), depending on the model. Level 1 is

mainly used in combination with bottom heat. The two upper levels are mainly used for the

grill function.

• Place the oven rack, baking tray or steam dish in the gap between the guide rail sliders.

• A number of shelf levels can have fully-retractable telescopic guide rails, depending on the

model.

▷Pull the telescopic guide rails out of the oven cavity completely and place the oven rack

/ baking tray / steam dish on them. Then slide the oven rack / baking tray / steam dish

on the telescopic guide rails, back into the oven cavity.

▷Only close the oven door when the telescopic guide rails have been returned completely

back into the oven cavity.

YOUR OVEN

861486_en_naslovnica_drug_papir.indd EN5861486_en_naslovnica_drug_papir.indd EN5 14. 02. 2023 10:23:0014. 02. 2023 10:23:00

EN 6

Accessories

Your appliance is accompanied by a range of accessories, depending on the model. Only use

original accessories; they are specially suited toyour appliance. Be sure that all the accessories

that are being used are able to withstand the temperature settings of the chosen oven function.

Note: not all accessories are suitable/available for every appliance (itmay also differ by country).

When purchasing, always provide the exact identification number of your appliance. Please see

the sales brochures or check online for more details about optional accessories.

Note: never place an accessory on the bottom of the oven!

Accessories that can be supplied with your appliance (depending on the model)

Glass baking tray; for microwave and oven use.

• NOT suitable for pyrolysis cleaning.

Door

• The door switches interrupt the operation of the oven when the door is opened during use.

The oven continues operating when the door is closed.

Cooling fan

• The appliance is equipped with a cooling fan that cools the casing and control panel.

YOUR OVEN

861486_en_naslovnica_drug_papir.indd EN6861486_en_naslovnica_drug_papir.indd EN6 14. 02. 2023 10:23:0114. 02. 2023 10:23:01

EN 7

YOUR OVEN

Control panel

10 1112 1413

15 16 17 18 19

1. Function knob (in the »off« position)

2.–7. Microwave oven power

8. Cleaning with microwaves

9. Reheating liquids

10. Reheating a meal

11. Defrosting bread

12. Defrosting

Symbols of cooking systems may be located on the knob or on the front panel

(depending on the appliance model).

The keys will respond better if you touch them with a larger area of your fingertip. Each

time you press a key, a short acoustic signal will be sounded.

861486_en_naslovnica_drug_papir.indd EN7861486_en_naslovnica_drug_papir.indd EN7 14. 02. 2023 10:23:0114. 02. 2023 10:23:01

EN 8

FIRST USE

Before using the appliance for the first time

• Upon receiving the appliance, remove all parts, including any transport equipment, from the

oven. Clean all accessories and utensils with warm water and regular detergent. Do not use

any abrasive cleaners.

• When the oven heats up for the first time, the characteristic smell of a new appliance will be

emitted. Ventilate the room thoroughly during the first use.

Microwave function

Microwaves are used for cooking, roasting, and defrosting of food. They allow quick and efficient

cooking without changing the colour or shape of the food.

Microwaves are a type of electromagnetic radiation. Such radiation is commonly found in our

environment in the form of radio-electric waves, light or infrared rays. Their frequency is in the

2,450 MHz range.

Their behaviour:

• They are reflected by metals.

• They travel through all other materials.

• They are absorbed by water, fat and sugar molecules.

When food is exposed to microwaves, the molecules begin to move rapidly, thereby generating

heat.

The microwaves penetrate approximately 2.5 centimeters deep into the food. If the food is thicker,

the core of the food will be cooked by conduction, as in conventional cooking.

Never use or activate a microwave system if the oven is empty.

861486_en_naslovnica_drug_papir.indd EN8861486_en_naslovnica_drug_papir.indd EN8 14. 02. 2023 10:23:0114. 02. 2023 10:23:01

EN 9

USE

Switching on and settings

After connecting your appliance or after an extended power outage, 12:00 will flash on the display

and the symbol will light up.

All the settings as follows:

SETTING THE CLOCK

Rotate the SETTINGS KNOB (-/+) and first set the minutes; then, the cursor will switch to hours.

After three seconds, the settings will be saved.

Turning the knob farther to the right or to the left will change the settings more quickly.

Confirm by pressing START/ STOP. If nothing is pressed within the next three seconds, the setting

will be stored automatically.

The oven will also work if the clock is not set. However, timer functions are not available

in this case (see chapter: SETTING THE TIMER FUNCTIONS).

After a few minutes of idling, the appliance will switch to standby mode.

CHANGING THE CLOCK SETTING

Clock settings may be changed when no timer function is activated.

Press the key to set the current time. Confirm by pressing START/ STOP.

861486_en_naslovnica_drug_papir.indd EN9861486_en_naslovnica_drug_papir.indd EN9 14. 02. 2023 10:23:0214. 02. 2023 10:23:02

EN 10

USE

SETTINGS

To change the settings, rotate the setting knob to the right and hold it for three seconds. Press the

start/sop icon to scroll through respective settings or parameters. To change a parameter, rotate

the setting knob to the right or to the left.

BRIGHTNESS LEVEL

Select between three different options of brightness levels. Mid level is pre-set. Levels can be set

by rotate knob.

Brightness level low Brightness level mid

Brightness level max

SOUND LEVEL

Mid level is pre-selected. Sound levels can be set by rotate knob.

Volume level low Pre-set mid sound level

Volume level max Volume level off

861486_en_naslovnica_drug_papir.indd EN10861486_en_naslovnica_drug_papir.indd EN10 14. 02. 2023 10:23:0214. 02. 2023 10:23:02
