6. TECHNICAL SPECIFICATIONS
6.1 Recomme ded values for 3.3 V applicatio
Power supply, 3.3 V VCC3 min. 3.1 V max. 3.6 V
Power consumption, +3V3 ICC3 max. 180 mA
Input voltage log.1 VIH min. 2.2 V max. . V
Input voltage log.0 VIL max. 1 V
Output voltage log.1, 3.3 V VOH3 min. VCC3-0.7
Output voltage log.0, 3.3 V VOL3 max. 0.4 V
Output pin current, 3.3 V Iout3 max. 4 mA
6.2 Recomme ded values for 5 V applicatio
Power supply, V VCC min. 4, V max. , V
Power consumption, + V ICC max. 200 mA
Input voltage log.1 VIH min. 2,2 V max. . V
Input voltage log.0 VIL max. 1 V
Output voltage log.1, V VOH min. 4,4 V
Output voltage log.0, V VOL max. 0,1 V
Output pin current, V Iout max. 2 mA
Values for use in other than typical environment are available in datasheets for
ENC28J60, 74AHCT 41 and LF33.
