Arregui FORMA B Manuel utilisateur

<ES>

<EN> Instruction manual and guarantee for the

electronic combination safe.

<ES> Manual de instrucciones y garantía de la caja

fuerte de combinación electrónica.

<PT> Manual de instruções e garantia da caixa

forte de combinação electrónica.

<IT> Manuale di istruzioni e garanzia della

cassaforte a combinazione elettronica.

<GR> Εγχειρίδιο οδηγιών και εγγύηση για το

χρηματοκιβώτιο με ηλεκτρονικό συνδυασμό.

FORMA B

stick the serial no.

<EN>

• In order to open the safe for the time, see point:

1. “Opening for the ﬁrst time”.

• For subsequent openings of the safe, enter an opening code and then

turn the key. Initially the programmed code is 1 2 3 4.

To discover how to open and close the safe, see point:

2. “Opening and closing the safe”.

• For security reasons, it is important to change the initial code and

introduce a personal number decided by you. The new code can have

1 to 12 digits.

To discover how to change the code, see point:

3. “Changing the opening code”.

• If any anomaly occurs, if the batteries go for example, the safe

has an emergency key.

See point: 4. “Emergency opening”

In any case, in order to avoid the batteries going see point:

6. “Condition of the battery indicator”.

• Do not remove the sticker with the safe number that

you will on the front of the safe and at the beginning of these

instructions, since you will need it in order to request emergency ope-

nings, spare parts etc.

INSTRUCTIONS

WARNING:

Each time a key is pressed, the safe emits a short beep, which

means that it was pressed correctly. If more than 15 seconds

pass between pressing two keys, the safe will close.

In this event, repeat the process.

123

456

789

1 2 3

4 5 6

7 8 9

<EN>

1. OPENING FOR THE FIRST TIME:

Every safe has 3pcs keys, one of them is the key marked with a red dot on

the key handle, and the other two keys are for normal use. To open the safe

time, insert the emergency key into the key hole and turn it clockwise

direction.

In order function, the safe needs 4 x 1.5 V alkaline batteries that are

placed in the battery holder located at the back of the door. In order to

insert them, open the cover of the battery holder and place the batteries

according to the diagram that is found on the inside. On completion of this

process the electronic system will be activated.

2. OPENING AND CLOSING THE SAFE:

• Press the key. A green light will begin to (if it is red, see point:

6. “Condition of the battery indicator”).

• Enter your personal opening code. The light will continue to

• Press the key and turn the key one half turn in the lock to the right

(clockwise). If the entered code is correct, the light will be illumi-

nated continuously for 3 seconds and a long beep for acceptance will

sound; you have this time to turn the key and open the safe. If the

entered code is incorrect, 4 short deep sounding beeps will sound

and the light will go out. In this event, repeat the process. The safe will

allow up to 5 incorrect code entries before becoming blocked for 15

minutes as a security measure, during which it will emit a beep every 5

seconds. During this time it is not possible to use the keypad.

To close the safe, simply turn the key 1 half turn to the left (anti-

clockwise).

To close the safe, simply turn the key 1 half turn to the left (anti-

clockwise).

<EN>

3. CHANGING THE OPENING CODE:

The initial opening code for the safe is 1 2 3 4. To change it, proceed in the

following manner:

• Open the safe and do not close it until the process has been concluded.

• Introduce a blunt object (e.g. a pen) into the circular hole that is on the

back of the door, until it reaches its limit. The safe emits a long beep at

the beginning of the changing process.

• Enter the new code that you have chosen. Remember that it must have

aminimum of 1 and a maximum of 12 digits.

• Press the key.

• Enter your new code for a second time. This way the system checks

that there was no involuntary error the time it was entered.

• Press the key again.

The safe will emit a continuous sound for acceptance, if the process

is completed correctly. If there has been an error it will emit four short

beeps. In this second case the opening code has not been changed and

you will have to repeat the process.

4. EMERGENCY OPENING:

Together with these instructions an envelope is provided which contains:

4.1. An emergency key:

For your convenience, this safe has an emergency key to open, which is

marked with a red dot on the key handle. If you forget your combination

code, insert the emergency key into the key hole and turn it clockwise

direction to open the safe.

This will manually open your safe at any time.

4.2. An emergency code:

In the event that you cannot remember your personal code, you can

open the safe by pressing this emergency code instead of your usual

one and following the steps indicated in part 2.

For your security we recommend not changing this code.

If you need to change it, follow these instructions:

• Open the safe and do not shut it until the process has been concluded.

• Press the key and then key 8.

• Introduce the rod which is incorporated in the envelope into the circu-

lar hole that is on the back of the door, until it reaches its limit.

• Enter the valid emergency code (that which is in the envelope if it

is the change or that now programmed in if you have previously

changed it).

• Press the key.

• Enter the new emergency code that you have decided on. Remember

that it must have a minimum of 1 and a maximum of 12 digits.

• Press the key.

• For re-enter your new emergency code.

• Press the key again.

The safe will emit a long beep for acceptance if the process has been

completed correctly. If there has been an error it will emit four short

beeps. In this second case the opening code has not been changed and

you will have to repeat the process.

5. USE OF THE EXTERNAL BATTERY CHARGER:

In the event that the safe has batteries and you do not have the

emergency key, you can open the safe by using 1 external 9V battery.

Proceed in the following manner:

• Connect the 2 extremes of the battery to the 2 power points that are

on the keypad (+ y -).

• Open the safe in the normal way ( - code - ).

6. CONDITION OF THE BATTERY INDICATOR:

Each time that you use the safe, the electronic system the

condition of the batteries. If the condition is good, the safe uses the

green light during the opening process. If the batteries are low the safe

uses the red light.

Once you see that the safe is using the red light, you should change the

batteries that are found on the inside of the door. The safe is able to

carry out several openings after the appearance of the red light. Even

so, do not rely on this and change the batteries as soon as possible.

<EN>

REMEMBER:

Never keep the envelope containing the emergency key and

emergency code inside the safe, in case you need to use them.

<EN>

<< On pressing , the green

light ﬂashes; on keying in the

code a beep sounds with each

touch; but, on pressing

4 short beeps sound and the

light goes off.

<< You are pressing the keys

normally, but after a few

seconds, the light goes off and

the keys are not working.

<< You are carrying out the

opening process normally and,

when you press , the conti-

nuous green light comes on but

after a few seconds it turns off

and you cannot turn the key.

<< The safe is emitting a beep

every 5 seconds and, when you

try to press any key the safe

will not work.

<< On pressing , the red light

comes on ﬂashing.

<< After changing the batteries

thesafe continues with the red

light instead of the green.

< The entered code is incorrect,

try again.

< Too much time has passed bet-

ween pressing two keys. You have

a maximum of 15 seconds between

pressing two keys. After this time

the safe closes. Repeat the process.

< You have taken too long in tur-

ning the key or the handle. After

pressing you have 3 seconds to

turn the key or the handle.

< The safe is blocked, because

someone has keyed in an incorrect

opening code 5 times in a row.

Wait 15 minutes and the safe will

unblock automatically. Then you

can continue as normal.

< The safe is warning you that

the batteries are running out. The

safe is able to carry out several

openings after the appearance of

the red light. Even so, you should

not rely on this and should change

the batteries as soon as possible.

< It is usual that after opening

the safe for the two or three

times afterchanging the batteries

the safe continues using the red

light. Check that it returns to using

the green light bycarrying out

several consecutive openings. If

the problem persists check that

you have inserted the batteries

correctly.

BEFORE CALLING THE TECHNICAL SERVICE,

CHECK:

<EN>

Arregui guarantees this safe for a period of 24 months from the date

of purchase. This guarantee covers repair (labour and materials) of any

manufacturing defect that affects its working. Transport costs will be

paid by the user.

Breakdowns produced as a result of improper use or installation, excess

humidity or salinity, water or cement spillage, violence, handling of the

mechanisms by non-authorised persons, as well as natural disasters

blows and falls are excluded.

The replacement due to breakdown of any part does not imply an

extension of the Guarantee.

IMPORTANT:

• These details must be completed as clearly as possible and without delay

by the supplier, who will stamp and sign on behalf of his company in the

place indicated.

• The remains in the possession of the purchaser.

• The purchaser must keep the RECEIPT for the purchase of the safe, toge-

ther with the GUARANTEE CERTIFICATE to be able to accredit the date of

purchase. Both documents are necessary to use the guarantee.

GUARANTEE CERTIFICATE

Identity details

Name of the supplier ................................................................................................

Date of sale ..................................................................................................................

Name of purchaser ....................................................................................................

Address of purchaser ................................................................................................

Identifying details of the safe

Model ..............................................................................................................................

Series number .............................................................................................................

SUPPLIER’S STAMP

<ES>

• Para abrir la caja fuerte por primera vez, vea el punto:

1. “Primera apertura”.

• Para aperturas posteriores de la caja fuerte, teclee un código de apertu-

ra y gire después la llave. Inicialmente, el código programado es 1 2 3 4.

Para saber cómo abrir y cerrar la caja, vea el punto:

2. “Apertura y cierre de la caja fuerte”.

• Por seguridad, es importante que cambie el código inicial y ponga el

número personal que usted decida. El nuevo código puede tener de 1 a

12 dígitos.

Para saber cómo cambiar el código, vea el punto:

3. “Cambio del código de apertura”.

• Si ocurre cualquier anomalía, como por ejemplo la descarga de las pilas,

la caja dispone de una llave de emergencia.

Vea los puntos: 4. “Apertura de emergencia”

En cualquier caso, para evitar que las pilas se agoten, vea el punto:

6.”Indicación del estado de la batería”.

• No retire el adhesivo de de su número de caja que en-

contrará en el frontal de la caja y en la portada de estas instrucciones,

ya que lo necesitará para solicitar aperturas de emergencia, repuestos,

etc.

INSTRUCCIONES

ATENCIÓN:

Cada vez que pulse una tecla, la caja emitirá un pitido corto, que

que la pulsación ha sido correcta. Si transcurren más de

15 segundos entre dos pulsaciones de tecla, la caja se apagará.

En ese caso, empiece de nuevo el proceso.

123

456

789

1 2 3

4 5 6

7 8 9

<ES>

1. PRIMERA APERTURA:

Cada caja fuerte cuenta con tres llaves. La llave de emergencia está mar-

cada con un punto rojo y las otras dos llaves son para la apertura habitual

de la caja. Para abrir la caja fuerte por primera vez, introduzca la llave de

emergencia en la cerradura, y gírela en el sentido de las agujas del reloj. De

este modo, la caja fuerte se abrirá.

Para su funcionamiento, la caja fuerte necesita 4 pilas alcalinas de 1,5 V,

que se colocan en el portapilas situado en la parte trasera de la puerta.

Para colocarlas, abra la tapa del portapilas e introduzca las pilas según el

dibujo que encontrará en su interior. Completado el proceso, el sistema

electrónico se activará.

Para cerrar la caja, simplemente gire la llave 1 media vuelta hacia la izquier-

da (sentido contrario a las agujas del reloj).

2. APERTURA Y CIERRE DE LA CAJA FUERTE:

• Pulse la tecla . Empezará a parpadear una luz verde (si es roja, vea el

punto: 6. “Indicación del estado de la batería”).

• Teclee su código personal de apertura. La luz seguirá parpadeando.

• Pulse la tecla y gire la llave en la cerradura 1 media vuelta hacia

la derecha (sentido de las agujas del reloj). Si el código tecleado es

correcto, durante 3 segundos la luz se iluminará y sonará un pitido

largo de aceptación; dispone de ese tiempo para girar la llave y abrir la

caja. Si el código es incorrecto, sonarán 4 pitidos cortos con sonido

grave y la luz se apagará. En ese caso, empiece de nuevo el proceso.

La caja permite hasta 5 introducciones erróneas de código antes de

bloquearse durante 15 minutos como medida de seguridad, durante

los que emitirá un pitido cada 5 segundos. Durante ese período, no es

posible utilizar el teclado.

Para cerrar la caja, simplemente gire la llave 1 media vuelta hacia la

izquierda (sentido contrario a las agujas del reloj).

<ES>

3. CAMBIO DEL CÓDIGO DE APERTURA:

El código inicial de apertura de la caja es 1 2 3 4. Para cambiarlo proceda

de la siguiente manera:

• Abra la caja y no la cierre hasta que haya concluido el proceso.

• Introduzca un objeto no punzante (ej. un bolígrafo) por el agujero circular

que se encuentra en la parte trasera de la puerta, hasta hacer tope.

La caja emitirá un pitido largo de comienzo del proceso de cambio.

• Introduzca el nuevo código que ha decidido. Recuerde que debe tener

un máximo de 12 dígitos y un mínimo de 1.

• Pulse la tecla .

• Vuelva a introducir su nuevo código por segunda vez. De esta manera,

el sistema comprueba que no se ha producido un error involuntario en

la primera introducción.

• Vuelva a pulsar la tecla .

La caja emitirá un pitido largo de aceptación, si se ha completado el

proceso correctamente. Si se ha producido algún error, emitirá cuatro

pitidos cortos. En este segundo caso, el código de apertura no habrá

cambiado y tendría que volver a empezar el proceso.

4. APERTURA DE EMERGENCIA:

Junto con estas instrucciones se suministra un sobre que contiene:

4.1. Una llave de emergencia:

Para su seguridad, la caja dispone de una llave de emergencia para su

apertura, marcada con un punto rojo. Si usted ha olvidado la contraseña,

introduzca la llave de emergencia en la cerradura y gírela en el sentido

de las agujas del reloj. Esta operación abrirá la caja de manera manual

en cualquier momento.

4.2. Un código de emergencia:

En el caso de que no recuerde su código personal de apertura, puede

abrir la caja tecleando este código de emergencia en lugar del suyo

habitual y siguiendo los pasos indicados en el apartado 2.

Por su seguridad, recomendamos no cambiar este código.

Si necesita cambiarlo siga estas indicaciones:

• Abra la caja y no la cierre hasta que haya concluido el proceso.

• Pulse la tecla y a continuación, la tecla 8.

• Introduzca la varilla que se incorpora en el sobre por el agujero circular

que se encuentra en la parte trasera de la puerta, hasta hacer tope.

• Introduzca el código de emergencia vigente (el del interior del sobre

si es el primer cambio y el programado previamente si ya lo había

cambiado anteriormente).

• Pulse la tecla .

Table des matières

Langues :

Autres manuels Arregui Sûr

Arregui

Arregui Premier 16501-S0 Mode d’emploi

Arregui

Arregui FORZA Mode d’emploi

Arregui

Arregui Supra 240090 Manuel utilisateur

Arregui

Arregui IGNUM 41010 Mode d’emploi

Arregui

Arregui PREMIER Manuel utilisateur

Arregui

Arregui SUMA Manuel utilisateur

Arregui

Arregui IGNUM Series Mode d’emploi

Arregui

Arregui AWA Manuel utilisateur

Arregui

Arregui BE Manuel utilisateur

Arregui

Arregui BASA 20000-S7 Manuel utilisateur

Arregui

Arregui PERFECT 44240 Manuel utilisateur

Arregui

Arregui FORMA C Mode d’emploi

Arregui

Arregui Supra Manuel utilisateur

Arregui

Arregui INTACT 17000 Mode d’emploi

Arregui

Arregui PLUS C Manuel utilisateur

Arregui

Arregui FORMA EVOLUTION Mode d’emploi

Arregui

Arregui COVER Mode d’emploi

Arregui

Arregui PLUS C Manuel utilisateur

Arregui

Arregui GRID Manuel utilisateur

Arregui

Arregui ALKA Manuel utilisateur

Arregui

Arregui Domus DL Manuel utilisateur

Arregui

Arregui TITAN 12000-S1 Mode d’emploi

Arregui

Arregui Supra Manuel utilisateur

Arregui

Arregui COVER Manuel utilisateur

Manuels Sûr populaires d'autres marques

Squire

Squire Stronghold Keysafe Manuel utilisateur

Phoenix

Phoenix FS0352C Fiche d'information produit

Phoenix

Phoenix KS0030E Series Manuel utilisateur

Vaultek

Vaultek 10 Series Fiche technique

Beaumont

Beaumont SMART KEYBOX Manuel utilisateur

Honeywell

Honeywell 2077D - 1.21 Cubic Foot Anti-Theft Safe Manuel utilisateur

Hornady

Hornady SnapSafe Trunk Safe II Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD5-BIO Manuel utilisateur

Honeywell

Honeywell 5912 Manuel utilisateur

Phoenix

Phoenix FS1280F Manuel utilisateur

Phoenix

Phoenix SS0992K Fiche d'information produit

Technomax

Technomax Trony Series Manuel

SPORTS AFIELD

SPORTS AFIELD INSTINCT BIOMETRIC Series Manuel utilisateur

RICHTER CZECH

RICHTER CZECH LA Manuel d'utilisation

Olymp

Olymp GOsafe 110 Manuel utilisateur

Phoenix

Phoenix SS0100E Fiche d'information produit

Clarke

Clarke Strong-Arm CS1000K Mode d’emploi

Ankaro

Ankaro ANK EZ I Manuel utilisateur
